Elo E679434 Touchscreen

Elo E649473 Touchscreen A newer version of this item is available.
It is replaced by the Elo E649473 Touchscreen.
Elo 1717L - Elo 1717L Rev B 17" LCD Touchscreen Monitor - 5:4 - 5 ms - 17" Class - 5-wire Resistive - 1280 x 1024 - SXGA - 16.7 Million Colors - 800:1 - 250 Nit - LED Backlight - USB - VGA - White - RoHS, China RoHS - 3 Year
  • Experience an energetic display of colors, contrast and pictures with the sxga lcd touchscreen monitor
  • Features 5-wire Resistive touch technology which is made of a glass panel and a film screen, each covered with a thin metallic layer, isolated by a narrow gap
  • The SXGA touchscreen highlights SXGA display with the resolution of up to 1280 x 1024 pixels
  • The 800:1 contrast ratio produces enhanced sharpness and shading accuracy in each picture
  • LED backlight technology provides for industry-leading low power consumption and less hazardous materials
  • Enjoy crisp content and energetic hues with the 250 Nit brightness
Read More
Discontinued See Replacement
Add to Quote
Elo 1717L Touchscreen Model Overview
The 1717L touchmonitor is built to withstand the rigors of continuous public use with a rugged "built for touch" design. Its stylish, thin and modern look is coupled with a retail-focused feature set and is an attractive solution for commercial touchmonitor needs. It is well suited for high use public venues where point-of-sale, point-of-information, point-of-service, shelf-level and countertop interactive digital signage and loyalty systems systems are found.
Elo E679434 Touchscreen Overview

The 1717L touchmonitor is built to withstand the rigors of continuous public use with a rugged "built for touch" design. Its stylish, thin and modern look is coupled with a retail-focused feature set and is an attractive solution for commercial touchmonitor needs. It is well suited for high use public venues where point-of-sale, point-of-information, point-of-service, shelf-level and countertop interactive digital signage and loyalty systems systems are found.

The 1717L is offered with AccuTouch five-wire resistive technology, IntelliTouch surface acoustic wave, or iTouch pure glass surface acoustic wave technology. AccuTouch is widely used in retail and hospitality environments based on its proven ability to survive splashing liquids, food and grease. IntelliTouch and iTouch pure glass surface acoustic wave technology delivers the ultimate in optical quality for dry retail and hospitality applications.

The optional 3-track magnetic stripe reader (MSR), programmable to either HID or Keyboard Emulation, is easily installed by the user, providing an elegant, integrated solution and eliminating the need for external brackets or attachments.

The 1717L touchmonitor is environmentally friendly, lightweight and uses less power with state-of-the-art LED backlights in the display panel.

Technical Information
Screen Size Class:
17"
Viewable Screen Size:
17"
Screen Mode:
SXGA
Screen Surface:
Anti-glare
Response Time:
5 ms
Aspect Ratio:
5:4
Horizontal Viewing Angle:
170°
Vertical Viewing Angle:
160°
Backlight Technology:
LED
Features:
Security Lock
Video
Maximum Resolution:
1280 x 1024
Standard Refresh Rate:
75 Hz
Color Supported:
16.7 Million Colors
Contrast Ratio:
800:1
Brightness:
250 Nit
Touchscreen Information
Touchscreen:
Yes
Touchscreen Type:
5-wire Resistive
Interfaces/Ports
USB:
Yes
VGA:
Yes
Serial Port:
Yes
Built-in Devices
Built-in Devices:
USB Hub
Power Description
Input Voltage:
  • 110 V AC
  • 220 V AC
Operating Power Consumption:
20 W
Standby Power Consumption:
1.80 W
Off-Mode Power Consumption:
1.40 W
Physical Characteristics
Product Color:
White
Height with Stand:
14.20"
Width with Stand:
15.40"
Depth with Stand:
7.80"
Weight (Approximate):
11.90 lb
Miscellaneous
Package Contents:
  • 1717L Rev B 17-inch Multifunction Desktop
  • Detachable Touch Cable
  • Video cable
Certifications & Standards:
  • Argentinian S-Mark
  • Australia C-Tick
  • Canada cUL
  • IC
  • China CCC
  • Europe CE
  • Japan VCCI
  • Korea KCC
  • e-Standby
  • Mexico CoC
  • Taiwan BSMI Mark
  • United States UL
  • FCC
  • International CB
  • IMERC
Environmentally Friendly:
Yes
Environmental Certification:
  • RoHS
  • China RoHS
  • WEEE
Warranty
Limited Warranty:
3 Year
Item Numbers
GTIN: 0834619001307, 7411493348464
UPC: 834619001307
EAN: 0834619001307, 7411493348464
UNSPSC: 43211903
Questions? Get help from
a POS Expert!

What is your POS application?

The Elo E679434 Touchscreen is also known as ELO-E679434 or E679434.
