Elo 5554L Touchscreen Signage
Full specifications (PDF)
Price Match Guarantee
Found a better price? We'll match it within 60 days of your purchase.
Display Type
- Projected Capacity (2)
- Infrared (1)
Elo 5554L Touchscreen Signage Options
-
Elo E104520 Touchscreen Signage
Touchscreen Signage, Elo 5554L, 55-inch wide LCD Monitor, 4K UHD, HDMI 2.0 & DisplayPort 1.4, Infrared 20-Touch, Anti-Glare Glass, USB, GrayIn Stock$2,867.47 -
Elo E104131 Touchscreen Signage
Touchscreen Signage, Elo 5554L, 55-inch wide LCD Monitor, 4K UHD, HDMI 2.0 & DisplayPort 1.4, Projected Capacitive 40-Touch, Clear Anti-friction Glass, USB, GrayIn Stock$3,112.24 -
Elo E104315 Touchscreen Signage
Touchscreen Signage, Elo 5554L, 55-inch wide LCD Monitor, 4K UHD, HDMI 2.0 & DisplayPort 1.4, Projected Capacitive 40-Touch, Anti-Glare Glass, USB, GrayIn Stock$3,157.89
Frequently Asked Questions
What touch technology does the Elo 5554L use and how many simultaneous touches can it handle?
The Elo 5554L features TouchPro PCAP (Capacitive) touch technology with support for up to 40 simultaneous touches and built-in palm rejection. This advanced multi-touch capability ensures precise interaction whether you're using gloves or your fingers, making it ideal for high-traffic retail and hospitality environments.
What is the display resolution and brightness of the Elo 5554L?
The Elo 5554L offers a stunning 4K native resolution of 3840 x 2160 pixels at 60Hz with 500 nits brightness. This brilliant display delivers exceptional visual clarity and vibrant colors across its 47.62" x 26.79" active display area, perfect for engaging customers in any lighting condition.
What connectivity options are available on the Elo 5554L?
The Elo 5554L includes multiple I/O ports for flexible integration, featuring two HDMI inputs, USB-C, and DisplayPort connectivity. It also includes RS232C serial control input for advanced system integration and supports built-in IoT control for seamless management within your business operations.
Is the Elo 5554L suitable for dusty or wet environments?
Yes, the Elo 5554L features a sealed touchscreen design that provides enhanced protection against dust and moisture. This durability makes it well-suited for challenging retail, warehouse, and hospitality environments where environmental protection is essential.
What are the viewing angles and response time of the Elo 5554L?
The Elo 5554L delivers wide viewing angles of ±89° horizontal and vertical (178° total), ensuring clear visibility from multiple positions. With an 8 millisecond response time, the display provides fast, responsive touch interaction for demanding interactive applications.
What warranty and power consumption specifications does the Elo 5554L include?
The Elo 5554L comes with a standard 3-year warranty for peace of mind. Power consumption is efficient at 111.87W when operating, 1.52W in sleep mode, and just 0.38W when powered off, helping reduce operational costs in 24/7 signage environments. Visit barcodesinc.com or contact us today for warranty details and deployment support.
Elo 5554L Touchscreen Signage Model Overview
The Elo 5554L 55" Touchscreen Signage offers an exceptional visual experience with its stunning 4K native resolution and large active display area, making it ideal for high-traffic environments. This versatile touchscreen display supports advanced multi-touch technology, ensuring precise interaction whether you're using gloves or your fingers. With robust connectivity options and built-in IoT control, it's designed for seamless integration into your business operations, enhancing customer engagement and operational efficiency.
Key Features
- Touch Technology: TouchPro PCAP with up to 40 simultaneous touches and palm rejection.
- Brilliant Display: 3840 x 2160 resolution with 500 nits brightness.
- Connectivity: Multiple I/O ports including two HDMI, USB-C, and DisplayPort.
- Built-in IoT Control: For easy management and operation.
- Durability: Sealed touchscreen for enhanced protection against dust and moisture.
Specifications
- Bezel Color: Black
- Active Display Area: 47.62" x 26.79"
- Aspect Ratio: 16:9
- Response Time: 8 msec
- Viewing Angle: ±89° horizontal/vertical
- Contrast Ratio: 1100:1
- Power Consumption: 111.87 W (on), 1.52 W (sleep), 0.38 W (off)
- Operating Temperature: 0° C to 40° C
- Dimensions (Unpackaged): 50.07" x 29.24" x 2.37"
- Weight (Unpackaged): 81.1 lbs
- Warranty: 3 years standard
