Denso BHT-420BW-CE Accessory

The Denso BHT-420BW-CE Accessory has been discontinued.
No direct replacement is available.
Please contact us for a suitable substitute.
Denso BHT-400 Series - SOFTWARE, APPLICATION PROGRAM CODE GENERATING FILE
  • Wireless connectivity option lets you transmit data instantly from your handheld terminal to your network while keeping you up to date
  • 64 MB RAM / 64 MB flash memory increases business esteem significantly by guaranteeing greatest user efficiency
  • Expand your data storage option with the CompactFlash card slot
  • 2.8" LCD screen is ideal for scan intensive applications
  • Touch panel gives your workforce ease, along with familiar and flexible operation, thus improving overall efficiency on a daily basis
  • Features numeric keypad to meet different client and application needs
  • Experience the versatility of Bluetooth connectivity with your DENSO TD Scan Handheld Terminal
  • Windows CE .NET 5.0 has impressive features to offer along with a comfortable interface to work on
Read More
Technical Information
Connectivity Technology:
Wireless
Image Sensor Type:
CCD
Barcode Symbology Supported:
  • EAN-13/8(JAN-13/8)
  • UPC-A/E(with add-on codes)
  • CODABAR (NW -7)
  • CODE 39
  • CODE 93
  • Interleaved 2 of 5 (ITF)
  • CODE 128 (EAN -128)
  • Standard 2 of 5 (STF)
  • MSI
  • RSS
Drop Specification:
60" To Concrete
Processor & Chipset
Processor Manufacturer:
Intel
Processor Type:
XScale
Processor Speed:
520 MHz
Memory
Standard Memory:
64 MB
Flash Memory:
64 MB
Memory Card Slot:
Yes
Memory Card Supported:
CompactFlash
Display & Graphics
Screen Size:
2.8"
Screen Mode:
QVGA
Screen Resolution:
240 x 320
Display Color:
Color
Display Screen Type:
LCD
Touchscreen Information
Touchscreen:
Yes
Keyboard/Keypad
Number of Keys:
31
Keyboard Type:
Numeric
Network & Communication
Wireless LAN:
Yes
Wireless LAN Standard:
IEEE 802.11b/g
Bluetooth:
Yes
Wireless Security:
  • WEP
  • WPA
  • PEAP
  • EAP-TLS
  • WPA-PSK
Software
Operating System:
Windows CE .NET 5.0
Battery Information
Battery Capacity:
1700 mAh
Battery Chemistry:
Lithium Ion (Li-Ion)
Battery Included:
Yes
Physical Characteristics
Height:
2.1"
Width:
3.1"
Depth:
1.2"
Length:
8.8"
Weight (Approximate):
12.70 oz
Miscellaneous
Package Contents:
  • BHT-420BW-CE Handheld Computer
  • Stylus
  • Battery
Additional Information:

2 Trigger Keys

Certifications & Standards:

IP 54

Warranty
Limited Warranty:
3 Year
Item Numbers
UNSPSC: 43211715
Get help from a Barcoding Expert!

What type of Barcode are you scanning?

The Denso BHT-420BW-CE Accessory is also known as BHT-420BW-CE
