Datalogic QD2131-BKK1 Barcode Scanner

Datalogic QuickScan QD2131 - Corded Barcode scanner, Datalogic QuickScan QD2131, 1D Linear Imager, General Purpose, Handheld, USB Kit with 90A052258 Cable, Black, 270 Scans/Second
  • Perfect for applications that require direct association with a workstation or a notebook
  • Scan barcodes with a staggering speed of 270 scan/s
Read More
$138.78
In Stock
Recommended TrueSupport Coverage ($1.38/mo.)
x

Are you sure you don't need TrueSupport?

The average internal IT
cost for device support is over $325 per year!

With TrueSupport you're
covered - and for way less!
  • Hardware Helpdesk Support
  • RMA Repair Facilitation
  • OEM Service Contract Management
  • Premium Phone & Email Support
  • Billed annually per device
$16.50
Only $1.38/month
Subtotal ( items)

Full specifications (PDF)

Perfect for Retail Scanning and Document Processing
The QuickScan QD2131 imager by Datalogic is the next generation of the QuickScan 2100 series. It features an extra-wide field of view and an extra-long scan line which allows users to read longer barcodes from a closer distance. Additionally, the QD2131 has an extended reading range which exceeds the requirements of most general purpose scanning applications. The highly visible scan line makes the QD2131 more user-friendly.
Datalogic QD2131-BKK1 Overview
The QuickScan reader series is Datalogic ADC's value line of general purpose handheld data collection products. The QuickScan I QD2100 linear imaging reader is an entry level product that is perfect for use in retail and office environments plus activities associated with couriers and postal services.

The QD2100 is small, lightweight and its ergonomic design is comfortable to use during daily operations. It offers snappy reading performance especially on hard to read bar codes and is capable of reading a wide range of symbologies including the majority of 1D codes plus GS1 DataBar™ linear codes. The QD2100 reader features Datalogic's exclusive patented 'Green Spot' for good read feedback directly on the code. When in Stand Mode, the Green Spot remains on to show the operator where to position the code for quick and intuitive reading.

Like the QuickScan L reader, the QD2100 has been designed with durability in mind. One of the most vulnerable features of any scanner is damage to the scan window. When such incidents happen, the scanner may have to be replaced. The QD2100 was specifically designed so that a replacement window pack can be ordered to replace damaged or scratched windows without having to send the scanner away for repairs. This helps to reduce the total cost of ownership during the life of the scanner and helps to ensure that it is always available for use.
Loading...

Full specifications (PDF)

Technical Information
Connectivity Technology:
Cable
Scanning Capability:
1D
Barcode Symbology Supported:
1D / LINEAR CODES
  • Autodiscriminates all standard 1D codes including GS1 DataBar linear codes.
POSTAL CODES
  • China Post
STACKED CODES
  • GS1 DataBar Expanded Stacked
  • GS1 DataBar Stacked
  • GS1 DataBar Stacked Omnidirectional
Image Sensor Type:
Imager
Scan Rate:
270 scan/s
Scanner Range:
Extended Range
Scanning Distance:
29.53"
Cable Type Included:
USB
Reading Angle (Skew):
70°
Reading Angle (Pitch):
65°
Reading Angle (Roll):
45°
Maximum Ambient Light:
120000 lux
Drop Specification:
Withstands repeated drops from 1.5 m / 5.0 ft onto a concrete surface.
Minimum Print Contrast:
25%
Minimum Element Resolution (Code 39):
4 mil
Maximum Element Resolution (Code 39):
20 mil
Interfaces/Ports
Host Interface:
USB
Physical Characteristics
Color:
Black
Weight (Approximate):
4.30 oz
Miscellaneous
Additional Information:

USB Cable separate

Application/Usage:
  • Industrial
  • Retail
  • Inventory
Item Numbers
GTIN: 0028592322218, 0783555115206, 4250389269390, 5712505724668
UPC: 028592322218, 783555115206
EAN: 0028592322218, 0783555115206, 4250389269390, 5712505724668
UNSPSC: 43211701

Loading...

The Datalogic QD2131-BKK1 is also known as Data Logic DTL-QD2131BKK1 or QD2131BKK1 .
