Datalogic QD2130-BKK1S Barcode Scanner

Datalogic QuickScan I QD2100 - QuickScan QD2110 Barcode Reader - Wired - Imager
  • Wired connectivity makes this scanner ideal for retail and desktop applications
  • Laser-free design provides high-performance scanning without the risk of eye injury
  • Scan barcodes with a staggering speed of 270 scan/s
Read More

Full specifications (PDF)

Two multiple interface options support the most popular interface combinations
The Datalogic QuickScan I QD2100 linear imaging reader is an entry level product perfect for use in retail and office environments plus activities associated with couriers and postal services. The QuickScan I QD2100 is small, lightweight and its ergonomic design is comfortable to use during daily operations. It offers snappy reading performance especially on hard to read barcodes and is capable of reading a wide range of symbologies including the majority of 1D codes plus GS1 DataBar linearcodes. The Datalogic QuickScan I QD2100 reader features Datalogic's exclusive patented 'Green Spot' for good read feedback directly on the code. When in Stand Mode, the Green Spot remains on to show the operator where to position the code for quick and intuitive reading.
Datalogic QD2130-BKK1S Overview

The QD2110 is small, lightweight and its ergonomic design is comfortable to use during daily operations. It offers snappy reading performance especially on hard to read bar codes and is capable of reading a wide range of symbologies including the majority of 1D codes plus GS1 DataBar linear codes. The QD2110 reader features Datalogic's exclusive patented 'Green Spot' for good read feed back directly on the code. When in Stand Mode, the Green Spot remains on to show the operator where to position the code for quick and intuitive reading.

Full specifications (PDF)

Technical Information
Connectivity Technology:
Cable
Barcode Symbology Supported:
1D / Linear Codes:
  • Autodiscriminates all standard 1D codes including GS1 DataBar linear codes
  • Postal Codes:
  • China Post
  • Stacked Codes:
  • GS1 DataBar Expanded Stacked
  • GS1 DataBar Stacked
  • GS1 DataBar Stacked Omnidirectional
Light Source:
LED
Image Sensor Type:
Imager
Scan Rate:
270 scan/s
Maximum Scan Resolution:
4 mil
Depth of Field:
  • 0.8" - 4.3"@4mil
  • 0.6" - 6"@5mil
  • 0.3" - 10.0"@7.5mil
  • 0.3" - 15.0"@10mil
  • 0.7" - 18.0"@13mil
  • 1" - 26.0"@20mil
Scan Pattern:
Linear
Cable Type Included:
USB
Stand Included:
Yes
Interfaces/Ports
Host Interface:
USB
Physical Characteristics
Color:
Black
Height:
6.7"
Width:
2.6"
Depth:
2.8"
Weight (Approximate):
4.30 oz
Miscellaneous
Package Contents:
  • QuickScan QD2110 Bar Code Reader
  • Stand
  • USB Cable
Additional Information:

USB Cable separate

Environmentally Friendly:
Yes
Environmental Certification:
  • RoHS
  • China RoHS
Warranty
Limited Warranty:
5 Year
Item Numbers
GTIN: 0783555087824, 0853585468228, 5052179251405
UPC: 783555087824, 853585468228
EAN: 0783555087824, 0853585468228, 5052179251405
UNSPSC: 43211701
