Connectivity Technology:
Cable
Scanning Capability:
- 1D
- 2D
Barcode Symbology Supported:
1D:
- Autodiscriminates all standard 1D codes including GS1 DataBar linear codes.
2D:
- Aztec Code
- China Han Xin Code
- Data Matrix
- MaxiCode
- Micro QR Code
- QR Code
3D:
- Australian Post
- China Post; IMB
- Japanese Post
- KIX Post
- Planet Code
- Portuguese Post
- Postnet
- Royal Mail Code (RM4SCC)
- Swedish Post
Stacked Codes:
- EAN/JAN Composites
- GS1 DataBar Composites
- GS1 DataBar Expanded Stacked
- GS1 DataBar Stacked
- GS1 DataBar Stacked Omnidirectional
- MacroPDF
- MicroPDF417
- PDF417
- UPC A/E Composites
Light Source:
LED
Image Sensor Type:
Imager
Scan Pattern:
Omni-directional
Scanner Range:
Auto Range
Scanning Distance:
33.40"
Reading Angle (Skew):
40°
Reading Angle (Pitch):
40°
Reading Angle (Roll):
360°
Image Formats:
- BMP
- JPEG
- TIFF
Maximum Ambient Light:
100000 lux
Drop Specification:
- Cradle: Withstands 50 drops from 1.2 m / 3.9 ft onto a concrete surface
- PBT9501: Withstands 50 drops from 2 m / 6.6 ft onto a concrete surface
Minimum Print Contrast:
15%
Minimum Element Resolution (DataMatrix):
7.5 mil
Maximum Element Resolution (DataMatrix):
10 mil
Maximum Element Resolution (PDF417):
10 mil
Illumination Type:
LED
Illumination Color:
White
