Datalogic Heron HD3130 – Barcode Scanner – Corded – 1D

Part Number: HD3130-WH
Model: Heron HD3100
Add to My Shopping List Add to Compare
Discontinued Need Assistance?

Price Match Guarantee - We'll match any authorized retailer's price

Quantity:

Product Highlights

View All
Connectivity
Corded
Form Factor
Handheld
Interface Options
USB
Scanner Capability
1D

Product Description:

  Corded Barcode Scanner, Datalogic Heron HD3130, 1D CCD, General Purpose, Handheld, USB Connection, SCANNER ONLY, White, 270 Scans/Second
Explore all Datalogic Heron HD3100 Barcode Scanners
Add to Quote
Datalogic HD3130-WH Barcode Scanner
Datalogic HD3130-WH Barcode Scanner
Datalogic HD3130-WH Barcode Scanner
Datalogic HD3130-WH Barcode Scanner
Datalogic HD3130-WH Barcode Scanner
Datalogic HD3130-WH Barcode Scanner
Datalogic HD3130-WH Barcode Scanner
Datalogic HD3130-WH Barcode Scanner Datalogic HD3130-WH Barcode Scanner Datalogic HD3130-WH Barcode Scanner Datalogic HD3130-WH Barcode Scanner Datalogic HD3130-WH Barcode Scanner Datalogic HD3130-WH Barcode Scanner Datalogic HD3130-WH Barcode Scanner
Full specifications (PDF)

Datalogic Heron HD3100 Barcode Scanner Model Overview

The HERON™ HD3100 from Datalogic elevates your point of sale experience through its innovative blend of style and functionality. Designed to impress, this elegant linear imager not only enhances your checkout aesthetics but also solidifies your brand presence at the final interaction point with customers. Its customizable features—including a choice of top cover colors and logos—combined with advanced scanning capabilities like Datalogic's patented 'Green Spot' technology, makes the HD3100 a productive powerhouse ideal for retail settings.

Key features:
  • Unique Design: Innovative and stylish aesthetics to enhance your POS.
  • Custom Branding: Personalize with logo and color feedback options.
  • Performance: 270 reads/sec with seamless handheld and hands-free operation.
  • Audio Feedback: Polyphonic speaker for versatile sound choices.
  • Durability: Drop resistant and robust, built for demanding environments.
  • 5-Year Warranty: Comprehensive protection for your investment.

Specifications:
  • Decoding Capability: 1D/Linear Codes, Postal Codes, Stacked Codes
  • Electrical:
    • Input Voltage: 5 VDC +/- 5%
    • Current: Operating (Typical): <300 mA @ 5 VDC
  • Environmental:
    • Drop Resistance: Withstands drops from 1.5 m / 5.0 ft
    • Temperature: Operating (0 to 50 °C) / Storage (-20 to 70 °C)
    • Humidity: 5-90% (Non-Condensing)
    • Sealing: IP40
  • Interfaces: RS-232 / USB / Keyboard Wedge Multi-Interface
  • Physical Characteristics:
    • Colors Available: Black, White, Customized Options
    • Dimensions: 15.2 x 15.3 x 6.8 cm / 6.0 x 6.0 x 2.7 in
    • Weight: 150.0 g / 5.3 oz
  • Reading Performance:
    • Read Rate: 270 reads/sec.
    • Resolution: Maximum 0.100 mm / 4 mils
    • Reading Ranges: Up to 60.0 cm / 23.6 in
  • Warranty: 5-Year Factory Warranty
Datalogic HD3130-WH Barcode Scanner Overview

The Heron&trade; HD3100 linear imager brings unmatched elegance along with the latest advanced technology to the modern point-of-sale. The stylish silhouette of the new imager enriched with multiple color changing lights, innovative and modern design material, together with the audio speaker, amplifies the customer's brand experience at the point-of-sale.

The Heron HD3100 imager differs from the usual color scheme of handheld devices by providing a stunning 'black' or 'white' color option, emphasizing the curving lines of the new enclosure. Additionally, the Heron imager features in-mold decorated top covers with a choice of 'Carbon Fiber' or 'Silver' design. This imager also offers opportunities to incorporate a company brand identity by allowing customers to compose the perfect blend: combining a company logo with the top cover color with customized visual and audio feedback in order to reinforce the value of the customer's brand.

Full specifications (PDF)
Technical Information
Connectivity Technology:
Cable
Scanning Capability:
1D
Barcode Symbology Supported:
1D / Linear Codes:
  • Autodiscriminates all standard 1D codes including GS1 DataBar&trade; linear codes
Postal Codes:
  • China Post
Stacked Codes:
  • GS1 DataBar Expanded Stacked
  • GS1 DataBar Stacked
  • GS1 DataBar Stacked Omnidirectional
Image Sensor Type:
CCD
Scan Rate:
270 scan/s
Interfaces/Ports
Host Interface:
USB
Physical Characteristics
Form Factor:
Handheld
Product Color:
White
Weight (Approximate):
5.29 oz
Miscellaneous
Additional Information:

USB Cable separate

Country of Origin:
Vietnam
Item Numbers
GTIN: 5712505761380
EAN: 5712505761380
UNSPSC: 43211701
