Full specifications (PDF)
Connectivity Technology:
Cable
Scanning Capability:
- 1D
- 2D
Barcode Symbology Supported:
1D / Linear Codes:
- Autodiscriminates all Standard 1D Codes
- GS1 DataBar Linear Codes
2D Codes:
- Aztec Code
- China Han Xin Code
- Data Matrix
- MaxiCode
- Micro QR Code
- QR Code
Postal Codes:
- Australian Post
- British Post
- China Post
- IMB
- Japanese Post
- KIX Post
- Korea Post
- Planet Code
- Postnet
- Royal Mail Code (RM4SCC)
Stacked Codes:
- EAN/JAN Composites
- GS1 DataBar Composites
- GS1 DataBar Expanded Stacked
- GS1 DataBar Stacked
- GS1 DataBar Stacked Omnidirectional
- MacroPDF
- MicroPDF417
- PDF417
- UPC A/E Composites
Image Sensor Type:
Imager
Depth of Field:
- 4.7cm - 17.7cm@5mil - Code 39
- 1.7cm - 33.2cm@10mil - Code 39
- 2.7cm - 17.1cm@10mil - Data Matrix
- 1.2cm - 24.6cm@15mil - Data Matrix
- 2.5cm - 41.9cm@13mil - EAN
- 2.2cm - 23.9cm@10mil - PDF417
- 3.5cm - 16.0cm@10mil - QR Code
Scan Pattern:
Omni-directional
Scanning Distance:
16.50"
Cable Type Included:
USB
Reading Angle (Skew):
40°
Reading Angle (Pitch):
40°
Reading Angle (Roll):
180°
Image Formats:
- BMP
- JPEG
- TIFF
Maximum Ambient Light:
100000 lux
Drop Specification:
Withstands repeated drops from 0.76 m / 2.50 ft onto a concrete surface
Minimum Print Contrast:
25%
Minimum Element Resolution (Code 39):
5 mil
Maximum Element Resolution (Code 39):
10 mil
Minimum Element Resolution (DataMatrix):
10 mil
Maximum Element Resolution (DataMatrix):
25 mil
Minimum Element Resolution (PDF417):
4 mil
Maximum Element Resolution (PDF417):
10 mil
