Full specifications (PDF)
Connectivity Technology:
Cable
Scanning Capability:
- 1D
- 2D
Barcode Symbology Supported:
1D:
- Auto discriminates all standard 1D codes including GS1 DataBar linear codes.
2D:
- Aztec Code
- China Han Xin Code
- Data Matrix
- MaxiCode
- Micro QR Code
- QR Code
- Dot Code
- Dot Matrix
Postal Codes:
- Australian Post
- British Post
- China Post
- IMB
- Japanese Post
- KIX Post
- Planet Code
- Postnet
- Royal Mail Code (RM4SCC)
Stacked Codes:
- EAN/JAN Composites
- GS1 DataBar Composites
- GS1 DataBar Expanded Stacked
- GS1 DataBar Stacked
- GS1 DataBar Stacked Omnidirectional
- MacroPDF
- MicroPDF417
- PDF417
- UPC A/E Composites
Light Source:
LED
Image Sensor Type:
Imager
Scan Mode:
Trigger
Depth of Field:
- 4 to 30.0 cm / 0.16 to 11.8 in @ 5 mil Code 39
- 1.7 to 53.5 cm / 0.6 to 21.0 in @ 10 mil Code 39
- 3.5 to 23.5 cm / 1.3 to 9.6 in @ 10 mil Data Matrix
- 3.0 to 35.0 cm / 1.2 to 13.7 in @ 15 mil Data Matrix
- 4.0 to 82.0 cm / 1.6 to 32.3 in @ 13 mil EAN/UPC
- 3.5 to 22.0 cm / 1.4 to 8.7 in @ 10 mil QR Code
Scan Pattern:
- Area
- Omni-directional
Scanner Range:
Standard Range
Scanning Distance:
32.30"
Features:
- Beep
- Notification LED
- Grayscale Image Capture
Cable Type Included:
USB
Field of View (Horizontal):
51°
Field of View (Vertical):
32°
Reading Angle (Skew):
60°
Reading Angle (Pitch):
60°
Reading Angle (Roll):
180°
Motion Tolerance:
70 in/s
Image Formats:
- BMP
- JPEG
- TIFF
Maximum Ambient Light:
120000 lux
Drop Specification:
- Withstands repeated drops from 1.5 m / 5 ft onto a concrete surface
Minimum Print Contrast:
15%
Minimum Element Resolution (Code 39):
5 mil
Maximum Element Resolution (Code 39):
10 mil
Minimum Element Resolution (DataMatrix):
10 mil
Maximum Element Resolution (DataMatrix):
15 mil
Minimum Element Resolution (PDF417):
10 mil
Image Sensor Resolution:
1280 x 800
Illumination Type:
LED
Illumination Color:
Red
