Datalogic Magellan 9800i Barcode Scanner Model Overview
The Magellan™ 9800i scanner/scale by Datalogic offers unmatched performance in barcode scanning, capable of seamlessly reading both 1D and 2D barcodes without the need for item orientation. Its ergonomic design features a low bonnet height for enhanced accessibility, ideal for diverse customer needs, including ADA compliance. The integrated customer-facing mobile device reader streamlines mobile commerce, significantly reducing transaction times. Empower your checkout experience with advanced imaging technology and loss prevention features that help minimize shrinkage, making the Magellan 9800i the ultimate choice for retailers seeking efficiency and effectiveness at the point of sale.
Key Features
Advanced digital imaging in all reading planes
Seamless reading of 1D and 2D codes
Optional Top Down Reader for enhanced field-of-view
The largest All-Weighs™ scale platter for accurate weighing
ScaleSentry™ Shrink Monitoring technology
Illumix™ Intelligent Illumination Technology
Remote Management support for easy operations
Specifications
Decoding Capability:
1D/Linear Codes
Stacked Codes
2D Codes
Digital Watermarks
Electrical:
AC Power Requirements: 100-240 VAC, 50-60 Hz
Power Consumption: 12 Watts operating / 11 Watts sleep mode
Environmental:
Operating Temperature: 10 to 40 °C / 50 to 104 °F
Humidity: 5-95% Non-Condensing
Ambient Light: 0-86,080 lux
Physical Characteristics:
Dimensions: 35.2 - 50.7 cm in length, 29.2 cm in width
Table Height: Above Counter - 6.8 cm / Below Counter - 10.6 cm
Datalogic, the global leader in high volume retail checkout scanning, has created the next generation scanner for high volume checkouts. The new Magellan 9800i scanner is the world's first bar code scanner driven completely by high performance digital imaging, resulting in the ability to increase checkout performance in the world's busiest checkout environments.
Corded In-Counter Barcode Scanner, Datalogic Magellan 9800i, 2D Imager, General Purpose, Embedded Scale, USB Connection, Retail USB Cable Included, Black/Silver, Long Platter/Sapphire Glass Glass, English Scale/Display, Single Interval, TDR Tall, Power Brick Not Included
Item on backorder — chat for lead time
$2,693.64
Top Best Barcode Scanner Purchased With Datalogic 98201030122-014251
Corded In-Counter Barcode Scanner, Datalogic Magellan 9800i, 2D Imager, General Purpose, Embedded Scale, USB Connection, Retail USB Cable Included, Black/Silver, Long Platter/Sapphire Glass Glass, English Scale/Display, Single Interval, TDR Tall, Power Brick Not Included
Item on backorder — chat for lead time
$2,693.64
Top Cables, Connectors, and Adapters Purchased With Datalogic 98201030122-014251
Corded In-Counter Barcode Scanner, Datalogic Magellan 9800i, 2D Imager, General Purpose, Embedded Scale, USB Connection, Retail USB Cable Included, Black/Silver, Long Platter/Sapphire Glass Glass, English Scale/Display, Single Interval, TDR Tall, Power Brick Not Included
Item on backorder — chat for lead time
$2,693.64
Top Grocery Barcode Scanner Purchased With Datalogic 98201030122-014251
Corded In-Counter Barcode Scanner, Datalogic Magellan 9800i, 2D Imager, General Purpose, Embedded Scale, USB Connection, Retail USB Cable Included, Black/Silver, Long Platter/Sapphire Glass Glass, English Scale/Display, Single Interval, TDR Tall, Power Brick Not Included
Item on backorder — chat for lead time
$2,693.64
Top Imager Barcode Scanner Purchased With Datalogic 98201030122-014251
Corded In-Counter Barcode Scanner, Datalogic Magellan 9800i, 2D Imager, General Purpose, Embedded Scale, USB Connection, Retail USB Cable Included, Black/Silver, Long Platter/Sapphire Glass Glass, English Scale/Display, Single Interval, TDR Tall, Power Brick Not Included
Item on backorder — chat for lead time
$2,693.64
Top In-counter Barcode Scanner Purchased With Datalogic 98201030122-014251
Corded In-Counter Barcode Scanner, Datalogic Magellan 9800i, 2D Imager, General Purpose, Embedded Scale, USB Connection, Retail USB Cable Included, Black/Silver, Long Platter/Sapphire Glass Glass, English Scale/Display, Single Interval, TDR Tall, Power Brick Not Included
Item on backorder — chat for lead time
$2,693.64
Top Miscellaneous Purchased With Datalogic 98201030122-014251
Corded In-Counter Barcode Scanner, Datalogic Magellan 9800i, 2D Imager, General Purpose, Embedded Scale, USB Connection, Retail USB Cable Included, Black/Silver, Long Platter/Sapphire Glass Glass, English Scale/Display, Single Interval, TDR Tall, Power Brick Not Included
Item on backorder — chat for lead time
$2,693.64
Top Scale Accessories Purchased With Datalogic 98201030122-014251
What barcode types can the Datalogic Magellan 9800i scanner read?
The Magellan 9800i is a 2D imaging scanner that reads all standard 1D linear codes including GS1 DataBar codes, as well as 2D codes such as Aztec Code, Data Matrix, QR Code, and Micro QR. It also decodes stacked codes including EAN/JAN Composites, GS1 DataBar Composites, PDF417, and MicroPDF417, making it ideal for high-throughput retail and grocery environments.
Is the Datalogic 9800i scanner suitable for high-volume checkout environments?
Yes, the Magellan 9800i is specifically designed for maximum throughput in the world's busiest checkout environments. As the first barcode scanner driven completely by high-performance digital imaging technology, it delivers state-of-the-art performance with high reliability for both 1D and 2D codes in demanding retail settings.
What connectivity options does the Magellan 9800i provide?
The 9800i offers multiple interface options including RS-232, USB, and IBM 46XX connectivity, with powered RS-232 and powered USB Host (Type A) ports available. It supports both scanner-only and integrated scanner/scale configurations with single-cable RS-232 or OEM USB Plus Power connections for flexible deployment.
Does the Magellan 9800i have an integrated scale?
Yes, the Magellan 9800i is available as a scanner/scale combination unit with an integrated all-weighs scale platter that increases active weighing surface. The scale supports both single interval and dual interval configurations, making it suitable for produce and general merchandise scanning in retail environments.
What are the environmental operating specifications for the Datalogic 9800i?
The Magellan 9800i operates reliably in temperatures from 10 to 40°C (50 to 104°F) and humidity levels of 5-95% non-condensing. It features 25kV EAS protection (air discharge) and operates in ambient light conditions up to 86,080 lux, making it suitable for various retail environments including brightly lit checkout areas.
What loss prevention features does the Magellan 9800i include?
The 9800i includes integrated Electronic Article Surveillance (EAS) capability with support for both Checkpoint Systems and Sensormatic EAS controllers. It features an integrated EAS antenna in both vertical and horizontal planes, good read acknowledgement, and compatibility with Sensormatic SmartSentry firmware for comprehensive loss prevention integration in retail settings. Contact us today to learn more about EAS configuration options available from us.
The Datalogic 98201030122-014251 Barcode Scanner is also known as
DTL-9820103012201425
or 98201030122014251.
Full specifications (PDF)
