CAEN RFID WA941MEOXAAA RFID Reader
Part Number:
WA941MEOXAAA
Model:
Tau A941M
Full specifications (PDF)
CAEN RFID Tau A941M RFID Reader Model Overview
The Tau A941M embedded UHF RFID reader is engineered for long-range applications, making it a perfect choice for vehicle access control systems, industrial control, and RFID tunnels. With programmable output power up to 32 dBm and up to four external antenna connectors, this OEM reader provides exceptional versatility and performance. Its compact design allows for easy integration into various infrastructures, delivering reliable data management and enhancing operational efficiency wherever RFID solutions are required.
Key Features
Specifications
Key Features
- ETSI EN 302 208 Compliant
- EPC C1 G2, ISO 18000-6C Compliant
- Programmable output power up to 1.5W (32dBm)
- Up to 4 External Antenna Connectors
- Supports long-range tag detection up to 10m
Specifications
- Frequency Range: 865.6÷867.6 MHz (ETSI EN 302 208)
- RF Power: SW programmable Max.: 1.5 W (32 dBm) conducted
- Antenna Connector: 5 SMA type female (4 read points + 1 LBT)
- Frequency Tolerance: ±10 ppm over the entire temp. range
- Channels: 4 channels compliant to ETSI EN 302 208
- Compliance: ISO 18000-6B, Philips UCODE EPC 1.19, EPC C1G2
- Digital I/O: Five I/O lines 3.3 V out, 5 V tolerant
- Connectivity: RS232 (9.6÷115 kbit/s data rate)
- Dimensions: (W)187 x (L)101 x (H)18 mm³ (7.4 x 4.0 x 0.7 inch³)
- Power Consumption: - 1 A @ 15 V (TX/RX mode); - 260 mA @ 15 V (idle mode)
- DC Power: 15±5% VDC
- Operating Temp: -20 °C to 70°C
- Weight: 330 g
Brand
CAEN RFID
Model
Tau A941M
Frequency
UHF
