Brocade ICX6430-24 Wireless Controller

Part Number: ICX6430-24
Model: Network Switches
Add to My Shopping List Add to Compare
Discontinued Need Assistance?

Price Match Guarantee - We'll match any authorized retailer's price

Quantity:

Product Highlights

View All
Total Number of Network Ports
24
Token Ring Port
No
LRE Port
No
Bypass
No

Product Description:

  Brocade ICX 6430-24 - Switch - managed - 24 x 10/100/1000 - desktop, rack-mountable, wall-mountable
Explore all Brocade Network Switches Network Switches
Add to Quote
Brocade ICX6430-24 Wireless Controller
Brocade ICX6430-24 Wireless Controller
Interfaces/Ports
Total Number of Network Ports:
24
Token Ring Port:
No
LRE Port:
No
Bypass:
No
Modular:
No
Management Port:
Yes
Number of PoE+ (RJ-45) Ports:
24
Stack Port:
Yes
Media & Performance
Media Type Supported:
Twisted Pair
Ethernet Technology:
  • Gigabit Ethernet
  • Fast Ethernet
Network Technology:
10/100/1000Base-T
I/O Expansions
Number of Total Expansion Slots:
4
Number of SFP Slots:
4
Network & Communication
Layer Supported:
2
Management & Protocols
Manageable:
Yes
Management:
  • VLAN
  • IGMP v2/v3
  • SNMP v1/2c
  • DHCP
  • Syslog
  • RMON
  • TELNET
  • MIB
  • CLI
  • GUI
  • QoS
Reliability
MTBF:
505469 Hour
Power Description
PoE (RJ-45) Port:
Yes
Input Voltage:
  • 110 V AC
  • 220 V AC
Power Source:
Power Supply
Redundant Power Supply Supported:
Yes
Physical Characteristics
Form Factor:
Desktop
Height:
1.7"
Width:
17.4"
Depth:
9.5"
Weight (Approximate):
10.08 lb
Miscellaneous
Certifications & Standards:
  • FCC Part 15, Subpart B, Class A
  • ICES-003: 2004
  • VCCI-Technical Requirement (V-3/2011.04)/Class A
  • EN 55022: 2006+A1: 2007 Class A
  • EN 61000-3-2: 2006+A1:2009+A2:2009 Class A
  • EN 61000-3-3: 2008
  • EN 61000-6-1: 2007
  • EN 61000-6-3: 2007
  • EN 55024: 1998+A1:2001+A2:2003
  • EN 300 386 (V1.4.1): 2008
  • IEC 61000-4-2: 2008 ED. 2.0
  • IEC 61000-4-3: 2006+A1:2007+A2:2010 ED. 3.2
  • IEC 61000-4-4: 2004+A1:2010 ED. 2.0
  • IEC 61000-4-5: 2005 ED. 2.0
  • IEC 61000-4-6: 2008 ED. 3.0
  • IEC 61000-4-8: 2009 ED. 2.0
  • IEC 61000-4-11: 2004 ED. 2.0
  • CAN/CSA-C22.2 NO. 60950-1-07
  • UL 60950-1
  • IEC 60950-1
  • EN 60950-1
  • EN 60825-1
  • EN 60825-2
  • IEEE 802.1AB
  • IEEE 802.1D
  • IEEE 802.1p
  • IEEE 802.1Q
  • IEEE 802.1s
  • IEEE 802.1w
  • IEEE 802.1x
  • IEEE 802.3ab
  • IEEE 802.3ad
  • IEEE 802.3ae
  • IEEE 802.3af
  • IEEE 802.3at
  • IEEE 802.3u
  • IEEE 802.3x
  • IEEE 802.3z
  • IEEE 802.3
  • IEEE 802.1AE
  • IEEE 802.3az
Environmentally Friendly:
Yes
Environmental Certification:
  • RoHS-6
  • WEEE
Warranty
Limited Warranty:
1 Year
Additional Warranty Information:
  • Product does not ship from original manufacturer and not recommended for Fed Gov't
  • Product may not be eligible for original manufacturer warranty, rebates, or programs
  • Product condition subject to availability
  • One year direct replacement warranty provided by Ingram Micro
  • Product ships from IMBuyback facility within 2-3 days or from stock
  • Product may ship in non-standard packaging
  • All returns processed directly from IMBuyback
  • Where applicable, -IM indicates an Ingram Micro Certified Pre-Owned product
Item Numbers
UNSPSC: 43222612
The Brocade ICX6430-24 Wireless Controller is also known as BRC-ICX643024
