Bosch CAM940C Surveillance Camera


(No reviews)

Be the first to

Write a Review
Bosch CAM940C - Color, NTSC, 12VDC Only, 3.6PH Lens
Automatically activate the camera with a motion detector!

With small, easy to mount, attractive sensors, the Bosch CAM940C offers selectable sensitivity for installation versatility. The integrated camera is complete with timer and relay outputs for alarm and VCR control. The CAM940C features include full-function PIR & Motion Analyzer II PIR signal processing, a 40 ft. x 40 ft. PIR coverage area with sensitivity adjustment. The CAM940C comes with a color camera with 3.4 Lux light sensitivity that can shoot in NTSC or PAL video format at 330 lines of horizontal resolution, plus the CAM940C's camera can be left on full-time or can be activated via the PIR detector.

General Information

  • Product Type: Surveillance Camera
  • Brand Name: Bosch
  • Manufacturer: The Bosch Group
  • Product Model: CAM940C
  • Product Name: CAM940C Surveillance Camera

Physical Characteristics

  • Height: 3.7"
  • Width: 2.2"
  • Depth: 1.5"


  • Package Contents:
    • CAM940C Surveillance Camera
    • Video cable with BNC connector
    • B335-3 Low Profile Mount Bracket
    • CAM940C Surveillance Camera
    • Video cable with BNC connector
    • B335-3 Low Profile Mount Bracket
  • Additional Information:
    • Full function PIR
    • Motion Analyzer II processing
    • Intelligent camera control (camera can be left on or controlled by the PIR)
    • 12 m x 12 m (40 ft x 40 ft) PIR coverage

Display & Graphics

  • Image Sensor Type: CCD
  • Color Supported: Color
  • Illumination: Minimum 3.4 Lux


  • Focal Length: 3.60 mm to 3.60 mm

Network & Communication

  • Connectivity Technology: Cable

Full specifications (PDF)

Full specifications (PDF)

Brand Bosch
Model CAM940C
Connection Analog
Features Color
Environment Indoor

Customer Review Summary

Recommended Accessories for Model: Bosch CAM940C Surveillance Camera
Protect Your Product

The Bosch CAM940C is also known as BOS-CAM940C .
