Bogen M450 Public Address Equipment

Bogen M-Class - 450W per channel, 20-20 kHz +/- 0.25 dB, Electronically balanced input, Sleep Mode, Back-Slope regulation, Toroidal Power Transformer

Need a different version? See all Bogen M-Class Public Address Equipments

$1,799.43

Chat Now for Qty Discount

Add to Quote

Overview

Full specifications (PDF)

Bogen M-Class Public Address Equipment Model Overview

Bogen's M-Class Amplifier provides three modes of operation, namely 70V Mono, Dual Mono and Stereo. M-Class Amplifier features massive power toroid and heat sinks, heavy 14-gauge chassis, Back-Slope AC voltage stabilization, Clip limiters, DC voltage, over-current and thermal protection circuits. 2 modular input bays for a variety of prioritized input types further increase its flexibility. The M-Class Amplifier delivers up to 600 watt/channel stereo or 1200W of 70V mono power with low distortion and a high slew rate. It also features Normal, Sleep Mode Protect mode operation.

Bogen M450 Public Address Equipment Overview

Bogen's M-Class amplifiers deliver on what professional sound installers need most: Flexibility, Power, and Reliability.

The M-Class allows for the installation of up to 2 input modules, accepting inputs from microphones, telephone systems, stereo sources, mono sources, or daisy-chaining of amplifiers. Each M-Class model comes standard with a single, professional-quality, stereo, high-impedance balanced input module.

Detailed Specs

Full specifications (PDF)

Physical Characteristics

Material:

Aluminum

Height:

3.5"

Width:

17"

Depth:

16"

Weight (Approximate):

44 lb

Miscellaneous

Package Contents:

M450 Signal Amplifier
2 x Rack Ears
2 x Filters and Grilles
Instruction Manual
Control Knob Cover
Balanced Input Module
4 x Rubber Feet & Screws

Additional Information:

3 selectable low-frequency roll-off choices
2 x 1 mixer function when in mono modes
Prioritized inputs when in mono modes
Insert connectors for outboard equipment (in mono modes)
Post- and Pre-EQ Output Feeds (in mono mode)
DC, overload, and thermal protection circuits
Clip detection and limiting circuits for speaker protection
Power-saving sleep mode for intermittent use applications
Signal, clip, sleep mode, and protect indicators
Back-slope AC voltage stabilization for depend- able performance over varying AC line voltages
Heavy 14-gauge steel chassis with cast aluminum front panel
Recessed volume control knobs with snap-on, protective cover
Material: Aluminum

Warranty

Limited Warranty:

2 Year

Item Numbers

GTIN: 0765368391084

UPC: 765368391084

EAN: 0765368391084

UNSPSC: 32101514

Reviews

Q&A

Questions? Get help from a
Printer Expert!

The Bogen M450 Public Address Equipment is also known as BOG-M450
