Bogen M450 Public Address Equipment

Bogen M-Class - 450W per channel, 20-20 kHz +/- 0.25 dB, Electronically balanced input, Sleep Mode, Back-Slope regulation, Toroidal Power Transformer

Need a different version? See all Bogen M-Class Public Address Equipments

$1,799.43
Add to Quote
Add to My Shopping List Add to Compare
Bogen M450 Public Address Equipment
Bogen M450 Public Address Equipment Bogen M450 Public Address Equipment Bogen M450 Public Address Equipment
Bogen M450 Public Address Equipment
Bogen M450 Public Address Equipment

Full specifications (PDF)
Bogen M-Class Public Address Equipment Model Overview
Bogen's M-Class Amplifier provides three modes of operation, namely 70V Mono, Dual Mono and Stereo. M-Class Amplifier features massive power toroid and heat sinks, heavy 14-gauge chassis, Back-Slope AC voltage stabilization, Clip limiters, DC voltage, over-current and thermal protection circuits. 2 modular input bays for a variety of prioritized input types further increase its flexibility. The M-Class Amplifier delivers up to 600 watt/channel stereo or 1200W of 70V mono power with low distortion and a high slew rate. It also features Normal, Sleep Mode Protect mode operation.
Bogen M450 Public Address Equipment Overview

Bogen's M-Class amplifiers deliver on what professional sound installers need most: Flexibility, Power, and Reliability.

The M-Class allows for the installation of up to 2 input modules, accepting inputs from microphones, telephone systems, stereo sources, mono sources, or daisy-chaining of amplifiers. Each M-Class model comes standard with a single, professional-quality, stereo, high-impedance balanced input module.

Full specifications (PDF)
Physical Characteristics
Material:
Aluminum
Height:
3.5"
Width:
17"
Depth:
16"
Weight (Approximate):
44 lb
Miscellaneous
Package Contents:
  • M450 Signal Amplifier
  • 2 x Rack Ears
  • 2 x Filters and Grilles
  • Instruction Manual
  • Control Knob Cover
  • Balanced Input Module
  • 4 x Rubber Feet & Screws
Additional Information:
  • 3 selectable low-frequency roll-off choices
  • 2 x 1 mixer function when in mono modes
  • Prioritized inputs when in mono modes
  • Insert connectors for outboard equipment (in mono modes)
  • Post- and Pre-EQ Output Feeds (in mono mode)
  • DC, overload, and thermal protection circuits
  • Clip detection and limiting circuits for speaker protection
  • Power-saving sleep mode for intermittent use applications
  • Signal, clip, sleep mode, and protect indicators
  • Back-slope AC voltage stabilization for depend- able performance over varying AC line voltages
  • Heavy 14-gauge steel chassis with cast aluminum front panel
  • Recessed volume control knobs with snap-on, protective cover
  • Material: Aluminum
Warranty
Limited Warranty:
2 Year
Item Numbers
GTIN: 0765368391084
UPC: 765368391084
EAN: 0765368391084
UNSPSC: 32101514
