Bixolon XD5-40t – Barcode Label Printer

Part Number: XD5-43TCEBK

Model: XD5-40

$712.45

Price Match Guarantee - We'll match any authorized retailer's price i

Quantity:

Product Highlights

View All

Recommended Use

Label Print

Print Color Capability

Monochrome

Maximum Mono Print Speed

4 in/s

Maximum Print Resolution (dpi)

300

Product Description:

Barcode Label Printers, Bixolon XD5-43, Black, Auto Cutter, Built In USB, USB Host, Ethernet, Bluetooth, Serial, 4 ips Printing Speed, Thermal Transfer, 300 dpi, Power Supply/US Power Cord, Warranty: Limited 2 Years, TPH 1 Year

Explore all Bixolon XD5-40 Barcode Label Printers

Add to Quote

Bixolon XD5-43TCEBK Barcode Label Printer

Overview

Full specifications (PDF)

Bixolon XD5-40 Barcode Label Printer Model Overview

The XD5 series printers are available in Direct Thermal or Thermal Transfer model, fully compatible with a market-leading programming language such as SLCS, BPL-Z and BPL-E, while supporting Smart Switch Programming Language. The XD5 series supports UHF RFID encode and print capability, easy installation and maintenance with exceptional print quality at 300 dpi. The XD5 series can connect to a wired or wireless network - 10/100 Ethernet or WLAN 802.11a/b/g/n. The long-lasting print head, auto cutter and platen rollers with tool-less removable design minimize operation and maintenance costs. The XD5 series offers easy integration with the availability of Windows, OPOS, Linux and MAC drivers, plus the development of your own applications via a suite of SDKs, and is backed by class-leading reliability.

Detailed Specs

Full specifications (PDF)

Technical Information

Recommended Use:

Label Print

Print Color Capability:

Monochrome

Maximum Mono Print Speed:

4 in/s

Maximum Print Resolution (dpi):

300

Maximum Print Length:

39.37"

Maximum Print Width:

4.16"

Barcode Symbology Supported:

Codabar
Code 11
Code 39
Code 93
Code 128
EAN-13
EAN-8
Industrial 2 of 5
Interleaved 2 of 5
LOGMARS
MSI
Plessey
POSTNET
GS1 DataBar
Standard 2 of 5
UPC/EAN
UPC-A
UPC-E
IMB
Aztec Code
Codablock
Code 49
Data Matrix
Maxi Code
Micro PDF-417
PDF417
QR Code
TLC 39

Application/Usage:

Desktop

Features:

Compact
LCD Display
Auto-cutter

Connectivity Technology:

Wired

Optional Connectivity:

Wireless LAN

Fonts Included:

10 SLCS
One SLCS
16 BPL-Z
One BPL-Z
5 BPL-E
23 Code Page
Unicode supported
UTF-8
UTF-16LE
UTF-16BE

Memory

Standard Memory:

64 MB

Interfaces/Ports

Serial Port:

Yes

USB Host:

Yes

USB:

Yes

Network & Communication

Ethernet:

Yes

Ethernet Technology:

Ethernet

Bluetooth:

Yes

Display & Graphics

Display Screen:

Yes

Display Screen Type:

LCD

Cutter

Cutter:

Yes

Cutting Method:

Automatic

Media Types & Handling

Media Type:

Label
Gap
Black Mark
Notch
Fanfold
Continuous Label

Media Sensor:

Transmissive Media Sensor
Reflective Media Sensor

Media Thickness:

7.87 mil

Maximum Roll Diameter:

Maximum Label Width:

4.65"

Fonts & Emulation

Language Emulation:

SLCS
BPL-Z
ZPL II
BPL-E
EPL

Power Description

Power Source:

AC Supply
Power Adapter

Input Voltage:

120 V AC
230 V AC

Environmental Conditions

Operating Relative Humidity:

10% - 80%

Storage Temperature:

-4°F (-20°C) - 140°F (60°C)

Storage Relative Humidity:

10% - 90%

Physical Characteristics

Product Color:

Black

Miscellaneous

Power Cable Localization:

Platform Supported:

PC
Android
iOS
Mac

Energy Star:

Yes

Item Numbers

UNSPSC: 43212108
