AudioCodes M800-2B-12L-P Data Networking

Part Number: M800-2B-12L-P
Model: Mediant 800
Add to My Shopping List Add to Compare
Discontinued Need Assistance?

Price Match Guarantee - We'll match any authorized retailer's price

Quantity:

Product Highlights

View All
PoE (RJ-45) Port
Yes
USB
Yes
Management Port
Yes
Number of PoE (RJ-45) Ports
12

Product Description:

  AudioCodes Mediant 800 Multi-Service Business Gateway - 4 x RJ-45 - USB - PoE Ports - Management Port - 1U High
Explore all AudioCodes Mediant 800 Data Networkings
Add to Quote
AudioCodes M800-2B-12L-P Data Networking
AudioCodes M800-2B-12L-P Data Networking
AudioCodes M800-2B-12L-P Data Networking AudioCodes M800-2B-12L-P Data Networking
Full specifications (PDF)

AudioCodes Mediant 800 Data Networking Model Overview

The AudioCodes Mediant™ 800 Multi-Service Business Gateway (MSBG) is an all-in-one solution designed for small to mid-sized businesses (SMBs), providing seamless voice and data connectivity. Thanks to its advanced VolPerfectHD™ technology, this device incorporates VoIP mediation, data routing, and robust security features, making it an ideal choice for service providers looking to enhance their offerings. With integrated survivability and the option to host value-added applications, the Mediant 800 MSBG ensures reliable communication in any environment, allowing businesses to leverage cloud services with confidence.

Key Features
  • All-in-one solution: Combines VoIP, security, and access management.
  • Flexible connectivity: Supports various WAN access options, including DSL, T1, and 4G.
  • Enterprise Session Border Controller: Enhances network security for SIP trunking.
  • Integrated LAN switch: Offers up to 12 PoE LAN ports for IP devices.
  • Stand Alone Survivability: Ensures internal communications during WAN failures.
  • Open platform: Hosts third-party applications like IP-PBX and conferencing solutions.


Specifications
  • Dimensions: 320mm x 345mm x 1U
  • Power Supply: Universal 90-260 V AC
  • PSTN Capacity: Up to 12 analog interfaces, 4 BRI, and single E1/T1/J1 span
  • WAN Interfaces: Supports optical Gigabit Ethernet, T1 WAN, SHDSL, ADSL2+, VDSL
  • LAN Interfaces: 10/100/1000 Base-T Copper, with optional PoE
  • WiFi: 802.11 a/b/g/n access point
  • CPU: Intel Atom 1.6 GHz
  • Memory: 1G RAM, SATA storage
  • Security: Supports IPsec, encryption, authentication, and DDoS protection
AudioCodes M800-2B-12L-P Data Networking Overview

The Mediant 800 MSBG is an all-in-one, Multi-Service Business Gateway solution, designed to provide converged Voice & Data services for small-to-mid size business (SMB) customers, and to form a well-managed point of demarcation for service providers. The Mediant 800 MSBG is based on AudioCodes' VoIPerfectHD best-of-breed Media Gateway technology, integrating a variety of communication functions into a single platform to support fundamental services, such as VoIP mediation, Data Routing, WAN access, Voice & Data security, survivability, and third party value-added services applications. These services allow smooth connectivity to cloud services.

Full specifications (PDF)
Interfaces/Ports
PoE (RJ-45) Port:
Yes
USB:
Yes
Management Port:
Yes
Number of PoE (RJ-45) Ports:
12
Number of Network (RJ-45) Ports:
4
Network & Communication
Carrier Supported:
ISDN
Ethernet Technology:
Gigabit Ethernet
Network Standard:
10/100/1000Base-T
Management & Protocols
Voice Codec:
  • T.38
  • G.165
  • G.168
  • G.711
  • G.722
  • G.723.1
  • G.729a
Physical Characteristics
Form Factor:
  • Rack-mountable
  • Desktop
Compatible Rack Unit:
1U
Width:
12.6"
Depth:
13.6"
Weight (Approximate):
5.51 lb
Item Numbers
UNSPSC: 43222605
Get help from a Barcoding Expert!

What type of Barcode are you scanning?

The AudioCodes M800-2B-12L-P Data Networking is also known as AUC-M800-2B-12L-P
