AudioCodes Mediant 800 Data Networking
AudioCodes Mediant 800 -
The Mediant 800 is an all-in-one, Multi-Service Business Gateway solution, designed to provide converged Voice & Data services for small-to-mid size business (SMB) customers, and to form a well-managed point of demarcation for service providers. The Mediant 800 is based on AudioCodes' VoIPerfectHD best-of-breed Media Gateway technology, integrating a variety of communication functions into a single platform to support fundamental services, such as VoIP mediation, Data Routing, WAN access, Voice & Data security, survivability, and third party value-added services applications. These services allow smooth connectivity to cloud services.
Full specifications (PDF)
Price Match Guarantee
Found a better price? We'll match it within 60 days of your purchase.
for Qty Discount
Add to Quote
Starting at:
$141.40
Get help from a Barcoding Expert!
Accessories For AudioCodes Mediant 800 Data Networking
AudioCodes Mediant 800 Data Networking Options
-
AudioCodes M800-MRK Data Networking
Rackmount Kit (10 Sets of Brackets) for the Mediant 800$141.40 -
AudioCodes M800-4S4O-4L Data Networking
AudioCodes Mediant 800 Data/Voice Gateway - 3 x RJ-45 - 4 x FXS - 4 x FXO - USB - Gigabit Ethernet - ADSL2+ - Wireless LAN - IEEE 802.11n - 1U High -
AudioCodes M800-12S-2L-P-2U12 Data Networking
Mediant 800 VoIP Media Gateway (M800-12S-2L-P-2U12) -
AudioCodes M800-V-1B-12L-P Data Networking
MEDIANT 800 W/1 BRI VOICE INTE AND 6 ACTIVE/STANDBY -
AudioCodes M800-ESBC-25 Data Networking
AudioCodes Mediant 800 Data/Voice Gateway - 13 x RJ-45 - USB - Gigabit Ethernet - ADSL2+ - Wireless LAN - IEEE 802.11n - 1U High -
AudioCodes M800-ESBC-5 Data Networking
AudioCodes Mediant 800 Data/Voice Gateway - USB - Wireless LAN - IEEE 802.11n - 1U High -
AudioCodes M800-V-1ET4S-4L Data Networking
AudioCodes Mediant 800 Data/Voice Gateway - 5 x RJ-45 - 4 x FXS - USB - Gigabit Ethernet - ADSL2+ - Wireless LAN - IEEE 802.11n - 1U High -
AudioCodes M800-V-4S4O-4L Data Networking
AudioCodes Mediant 800 Data/Voice Gateway - 5 x RJ-45 - 4 x FXS - 4 x FXO - USB - Gigabit Ethernet - ADSL2+ - Wireless LAN - IEEE 802.11n - 1U High -
AudioCodes M800-V-12S-12L-P Data Networking
MEDIANT 800 W/12 FXS VOICE INT AND 6 ACTIVE/STANDBY -
AudioCodes M800-1ET4S-SBA-SPS Data Networking
M800-1ET4S-SBA-SPS -
AudioCodes M800-12S-12L-P Data Networking
AudioCodes Mediant 800 Multi-Service Business Gateway - 1 x RJ-45 - 4 x FXS - 4 x FXO - USB - PoE Ports - Gigabit Ethernet - 1U High -
AudioCodes M800-4O-2L-X1 Data Networking
AudioCodes Mediant 800 Multi-Service Business Gateway - 3 x RJ-45 - 4 x FXO - USB - Gigabit Ethernet - 1U High -
AudioCodes M800-1ET4S-SBA Data Networking
AudioCodes Mediant 800 Data/Voice Gateway - 13 x RJ-45 - 4 x FXS - USB - PoE Ports - Gigabit Ethernet - ADSL2+ - Wireless LAN - IEEE 802.11n - 1U High -
AudioCodes M800-1B-12L-P Data Networking
MEDIANT 800 MSBG W/1BRI VOICE INT AND 1000 BASE-TWAN -
AudioCodes M800-V-1ET-12L-P Data Networking
AudioCodes Mediant 800 Multi-Service Business Gateway - 1 x RJ-45 - 4 x FXS - 4 x FXO - USB - PoE Ports - Gigabit Ethernet - 1U High
AudioCodes Mediant 800 Data Networking Model Overview
The AudioCodes Mediant™ 800 Multi-Service Business Gateway (MSBG) is an all-in-one solution designed for small to mid-sized businesses (SMBs), providing seamless voice and data connectivity. Thanks to its advanced VolPerfectHD™ technology, this device incorporates VoIP mediation, data routing, and robust security features, making it an ideal choice for service providers looking to enhance their offerings. With integrated survivability and the option to host value-added applications, the Mediant 800 MSBG ensures reliable communication in any environment, allowing businesses to leverage cloud services with confidence.
Key Features
Specifications
Key Features
- All-in-one solution: Combines VoIP, security, and access management.
- Flexible connectivity: Supports various WAN access options, including DSL, T1, and 4G.
- Enterprise Session Border Controller: Enhances network security for SIP trunking.
- Integrated LAN switch: Offers up to 12 PoE LAN ports for IP devices.
- Stand Alone Survivability: Ensures internal communications during WAN failures.
- Open platform: Hosts third-party applications like IP-PBX and conferencing solutions.
Specifications
- Dimensions: 320mm x 345mm x 1U
- Power Supply: Universal 90-260 V AC
- PSTN Capacity: Up to 12 analog interfaces, 4 BRI, and single E1/T1/J1 span
- WAN Interfaces: Supports optical Gigabit Ethernet, T1 WAN, SHDSL, ADSL2+, VDSL
- LAN Interfaces: 10/100/1000 Base-T Copper, with optional PoE
- WiFi: 802.11 a/b/g/n access point
- CPU: Intel Atom 1.6 GHz
- Memory: 1G RAM, SATA storage
- Security: Supports IPsec, encryption, authentication, and DDoS protection
