Symbol LS2208-1AZR0100D Barcode Scanner

Zebra LS2208-1AZR0100DR Barcode Scanner A newer version of this item is available.
It is replaced by the Zebra LS2208-1AZR0100DR Barcode Scanner.
Symbol LS2208 - RS-232 kit, White. Includes RS-232 cable, power supply, gooseneck stand, & product reference guide.
  • Minimizes your manual entry and provides reliable scanning in a durable form factor
  • Wired connectivity makes this scanner ideal for retail and desktop applications
  • Powerful laser scan source provides 100 scan/s decode rate
  • Scan barcodes with a staggering speed of 100 scan/s
Read More
Discontinued See Replacement
Add to Quote
Symbol LS2208 Barcode Scanner Model Overview
With over eight million sold, the LS2208 remains Zebra's best selling handheld laser scanner. The LS2208 has it all ? enterprise class scanning in a very ergonomic and durable lightweight design that delivers all day comfort, an extra-long read range for easy scanning, plus support for everyday 1D bar codes, including high-density. With multiple interfaces, a universal cable and support for keyboards in 97 languages, the LS2208 delivers plug-and-play simplicity in virtually every corner of the world. The LS2208 ? the well-proven scanner powering the checkout lines all around the world.
Symbol LS2208-1AZR0100D Barcode Scanner Overview

The innovative LS 2208 hand-held Bar Code Reader delivers performance features at an affordable price to make your buying decision easier than ever. If you're seeking investment protection and great value in a small, light scanner that assures maximum productivity, then the LS 2208 is the ideal scanner for you. From the checkout line to the back room, the LS 2208 helps you make the most of your application-specific solution in a variety of ways.

Technical Information
Connectivity Technology:
Cable
Barcode Symbology Supported:
  • UPC/EAN
  • UPC/EAN with Supplementals
  • UCC/EAN 128
  • Code 39
  • Code 39 Full ASCII
  • Code 39 TriOptic
  • Code 128
  • Code 128 Full ASCII
  • Codabar
  • Interleaved 2 of 5
  • Discrete 2 of 5
  • Code 93
  • Code 11
  • IATA
  • RSS Variants
  • China Post 2 of 5
Light Source:
Laser
Image Sensor Type:
Linear
Scan Rate:
100 scan/s
Maximum Scan Resolution:
5 mil
Depth of Field:
  • 2.5" - 6"@5mil
  • 1.5" - 10"@7.5mil
  • 1" - 14.5"@10mil
  • 0" - 17"@100% UPC
  • 0" - 23"@20mil
Scan Pattern:
Bi-directional
Stand Included:
Yes
Interfaces/Ports
Host Interface:
Multi-interface
Power Description
Input Voltage:
110 V AC
Power Supply Included:
Yes
Physical Characteristics
Color:
White
Height:
6"
Width:
2.5"
Depth:
3.3"
Weight (Approximate):
5.15 oz
Miscellaneous
Package Contents:
  • Symbol LS2208 Bar Code Reader
  • RS232 (Std Cable) (25-32465-20) (DB9 Female, TxD on 2, 6 ft. Straight)
  • 110V Power Supply (50-14000-008)
  • Stand (20-61019-01)
  • CD ROM (SW-61077-02)
Additional Information:

Supported Interfaces:

  • Serial
  • Keyboard Wedge
  • Wand Emulation
  • IBM 468X/469X
  • USB
  • Synapse
  • Platform Supported:
    PC
    Certifications & Standards:

    Electrical Safety:

    • UL1950
    • CSA C22.2 No. 950
    • EN60950/IEC950

    EMI/RFI:

    • FCC Part 15 Class B
    • ICES-003 Class B
    • European Union EMC Directive
    • Australian SMA
    • Taiwan EMC
    • Japan VCCI/MITI/Dentori

    Laser Safety:

    • CDRH Class II
    • IEC Class 2
    Warranty
    Limited Warranty:
    5 Year
    Item Numbers
    UNSPSC: 43211701
    Get help from a Barcoding Expert!

    What type of Barcode are you scanning?

    The Symbol LS2208-1AZR0100D Barcode Scanner is also known as SYM-LS2208AZR or LS22081AZR0100D.
