Equinox Optimum L4250 Payment Terminal

Equinox Optimum L4250  -  The Equinox Optimum L4250 terminal is the first PCI PED approved multi-lane payment terminal that supply out-of-the-box, plug-and-play secure PIN entry without the need for add-on components. The Optimum L4250 terminal is a high-performance signature capture payment device with a 220x80 pixel 16-greyscale LCD touchscreen that is suited to retail branding. It also features a recessed 13-key keypad with an integrated privacy shield to safeguard consumer data during PIN entry, EMV-approved smart card reader and an optional integrated contactless RF reader that supports cards and key fobs from American Express, MasterCard PayPass and Visa Contactless payment programs.
Full specifications (PDF)

Price Match Guarantee

Found a better price? We'll match it within 60 days of your purchase.

Chat Now for Qty Discount
Add to Quote
Add to My Shopping List Add to Compare
Please Call
Questions? Get help from
a POS Expert!

What is your POS application?

Equinox Optimum L4250 Payment Terminal
Equinox Optimum L4250 Payment Terminal
Accessories For Equinox Optimum L4250 Payment Terminal

Manufacturer

Category

Equinox Optimum L4250 Payment Terminal Options

Full specifications (PDF)

Equinox Optimum L4250 Payment Terminal Model Overview

The Optimum L4250 is a cutting-edge multi-lane payment terminal designed for efficiency and sleek style. With a compact footprint and advanced technology, it ensures smooth transaction processes and excellent customer experiences. The dual-sided bi-directional magnetic stripe reader achieves a remarkable 99.99% first-read rate, minimizing delays at the checkout. Additionally, its easy-to-read LCD screen not only enhances signature capture but also allows for customizable branding messages. The Intel XScale® 32-bit processor accelerates transaction speeds, making every lane a fast lane, while robust security features keep cardholder information safe and sound.


Key Features:

  • 99.99% First-Read Rate: Dual-sided, bi-directional magnetic stripe reader for seamless transactions.
  • Fast Processing: Intel XScale® 32-bit processor for rapid data transmission.
  • Enhanced Security: DUKPT key management and DES/Triple DES encryption for maximum protection.
  • Customizable Branding: LCD screen for displaying marketing messages and promotional content.
  • ADA Compliance: Keypad and screen designed for users with disabilities.

Specifications:

  • Processor: Intel XScale 200 MHz, 32-bit
  • Keypad: 13 color-coded keys, water splash-resistant
  • Display: LCD 220 x 80 pixels, 16-shade grayscale, backlit
  • Card Reader: Dual-head bi-directional magnetic stripe, optional chip and contactless payment
  • Memory: 4MB Flash / 8MB SDRAM
  • Power: AC 100-240 V, 50/60 Hz; DC 12 V @ 500mA
  • Weight: 1.29 lbs / 0.59 kg
  • Footprint: 8.22 in x 6.06 in x 2.36 in
  • Environment: Operating temperature 0-45°C, humidity max 85%
