Cisco AIR-AP1252AG-N-K9 Wireless Access Points

Part Number: AIR-AP1252AG-N-K9
Model: Aironet 1250 Series
Add to My Shopping List Add to Compare
Discontinued Need Assistance?

Price Match Guarantee - We'll match any authorized retailer's price

Quantity:

Product Highlights

View All
Wireless LAN Standard
IEEE 802.11n
ISM Band
Yes
UNII Band
Yes
ISM Minimum Frequency
2.41 GHz

Product Description:

  Cisco Aironet 1252 Wireless Access Point - 600Mbps
Explore all Cisco Aironet 1250 Series Access Points
Add to Quote
Cisco AIR-AP1252AG-N-K9 Wireless Access Points
Cisco AIR-AP1252AG-N-K9 Wireless Access Points
Cisco AIR-AP1252AG-N-K9 Wireless Access Points
Cisco AIR-AP1252AG-N-K9 Wireless Access Points
Cisco AIR-AP1252AG-N-K9 Wireless Access Points
Cisco AIR-AP1252AG-N-K9 Wireless Access Points Cisco AIR-AP1252AG-N-K9 Wireless Access Points Cisco AIR-AP1252AG-N-K9 Wireless Access Points Cisco AIR-AP1252AG-N-K9 Wireless Access Points Cisco AIR-AP1252AG-N-K9 Wireless Access Points
Full specifications (PDF)

Cisco Aironet 1250 Series Access Point Model Overview

Cisco Aironet 1250 Series wireless access points are the first business-class access points to be Wi-Fi 802.11n draft 2.0 certified. These modular wireless access points provide reliable and predictable WLAN coverage to improve the end user's experience with both existing 802.11a/b/g clients and new 802.11n clients. With the Aironet 1250 Series wireless access points you can augment throughput for high-bandwidth wireless applications, protect your investment in wireless networking, and increase network reliability for mission-critical applications.
Cisco AIR-AP1252AG-N-K9 Wireless Access Points Overview

The Cisco Aironet 1252 Wireless Access Point is the first enterprise-class access point to support the IEEE 802.11n draft 2.0 standard. 802.11n offers combined data rates of up to 600 Mbps to provide users with mobile access to high-bandwidth data, voice, and video applications regardless of their location.

Full specifications (PDF)
Technical Information
Wireless LAN Standard:
IEEE 802.11n
ISM Band:
Yes
UNII Band:
Yes
ISM Minimum Frequency:
2.41 GHz
ISM Maximum Frequency:
2.46 GHz
UNII Minimum Frequency:
5.15 GHz
UNII Maximum Frequency:
5.83 GHz
Total Number of Antennas:
6
Antenna Connector:
RP-TNC Connector
Wireless Transmission Speed:
600 Mbit/s
Wireless Security:
  • WPA (Enterprise, Personal)
  • WPA2 (Enterprise, Personal)
Interfaces/Ports
Ethernet Technology:
Gigabit Ethernet
Number of Network (RJ-45) Ports:
1
Management Port:
Yes
Management & Protocols
Management:
  • CLI
  • Browser based management
  • DHCP
  • SNMP
Power Description
Input Voltage:
  • 110 V AC
  • 220 V AC
Physical Characteristics
Form Factor:
  • Ceiling Mountable
  • Wall Mountable
Height:
8.1"
Depth:
2.4"
Weight (Approximate):
5.10 lb
Miscellaneous
Package Contents:
  • Aironet 1252 Wireless Access Point
  • Power Supply Not Shipped (AIR-NO-PWR-SUPPLY)
  • Cisco 1250 Series IOS Wireless LAN (S125W7K9-12410JA)
Additional Information:

Non-FCC configuration

Certifications & Standards:

Safety:

  • UL 60950-1
  • CAN/CSA-C22.2 No. 60950-1
  • UL 2043
  • IEC 60950-1
  • EN 60950-1

Radio approvals:

  • FCC Part 15.247, 15.407
  • RSS-210
  • EN 300.328, EN 301.893
  • ARIB-STD 33
  • ARIB-STD 66
  • ARIB-STD T71
  • AS/NZS 4268.2003
  • EMI and susceptibility (Class B)
  • FCC Part 15.107 and 15.109
  • ICES-003
  • VCCI
  • EN 301.489-1 and -17
  • EN 60601-1-2

IEEE Standard:

  • IEEE 802.11a
  • IEEE 802.11b
  • IEEE 802.11g
  • IEEE 802.11n (draft 2.0)
  • IEEE 802.11h
  • IEEE 802.11d

Other:

  • FCC Bulletin OET-65C
  • RSS-102
  • Wi-Fi
Warranty
Limited Warranty:
90 Day
Item Numbers
GTIN: 0882658140785
UPC: 882658140785
EAN: 0882658140785
UNSPSC: 43222631
