Zebra ZT22043-T01000FZ Barcode Label Printer

Zebra ZT11143-T01000FZ Barcode Label Printer A newer version of this item is available.
It is replaced by the Zebra ZT11143-T01000FZ Barcode Label Printer.
Zebra ZT220 - Industrial Label Printer, Zebra ZT220, Thermal Transfer, 300 dpi, 6ips, Serial/USB, 4-inch Print Width, Includes US Power Cord with US Plug, Cables Sold Separately
Printer Type
Industrial
Printing Technology
Thermal Transfer
Interface Options
Serial (RS-232), USB
Print Resolution
300 dpi
Max Print Width
4.5 inch
Ribbon Core Size
1 inch
  • Direct Thermal/Thermal Transfer Printer offers reliable performance with outstanding printing quality
  • 300 maximum print resolution (dpi) for better reliance and added usability
  • Produce high-quality documents with this monochrome printer to increase your productivity
  • Label Print gives dependable results with maximum productivity
  • 4.50" maximum label width to easily accommodate your needs with added productivity
  • 39" maximum label length to easily accommodate your needs with added productivity
  • Supports continuous label media type for maximum feasibility and better accommodation of your requirements
  • Direct Thermal/Thermal Transfer Printer with industrial application/usage provides dependable printing solution with added productivity
  • Tear-off feature for maximum efficiency and convenience
  • Comes with 128 MB standard memory to make you productive with the direct thermal/thermal transfer printer smooth performance
Read More
Discontinued See Replacement
Recommended TrueSupport Coverage (/mo.)

x

Are you sure you don't need TrueSupport?

The average internal IT
cost for device support is over per year!

With TrueSupport you're
covered - and for way less!
  • Hardware Helpdesk Support
  • RMA Repair Facilitation
  • OEM Service Contract Management
  • Premium Phone & Email Support
  • Billed annually per device

Only /month
Subtotal ( items)

x
You've just added this product to the cart:

Go To Cart
Add to Quote
Zebra ZT220 Barcode Label Printer Model Overview
Zebra's ZT220 Industrial Printers are Zebra's most affordable industrial printers that incorporate extensive customer feedback and the learnings from legacy printers—creating innovative printers with a space-saving design. Featuring Zebra's Link-OS environment, the ZT220 provides users with effortless setup, intuitive operation and easy service and maintenance. Whether you are adopting barcode technology for the first time or upgrading existing printer models, the ZT220 is the right choice for a variety of labeling applications. These innovative printers provide many user benefits, and they are ENERGY STAR qualified to save you money throughout their lifecycle. The ZT220 has a durable high-impact polymer case for long-lasting use, and a simple single-use three-button user interface. The ZT220 is ideal for barcode-labeling applications where minimal formal or printer setting changes are required.
Zebra ZT22043-T01000FZ Barcode Label Printer Overview

Zebra incorporated extensive customer feedback, as well as the legacy of our industry leading Stripe and S4M printers, to create the new ZT200 Series family of printers with elegant space saving design, effortless setup, intuitive user operation, and ease of service and maintenance.

Technical Information
Recommended Use:
Label Print
Print Color Capability:
Monochrome
Maximum Mono Print Speed:
6 in/s
Maximum Print Resolution (dpi):
300
Maximum Print Width:
4.09"
Barcode Symbology Supported:
  • Code 11
  • Code 39
  • Code 93
  • Code 128-A
  • Code 128-B
  • Code 128-C
  • UCC Case Codes
  • ISBT-128
  • UPC-A
  • UPC-E
  • EAN-13
  • EAN-8
  • EAN With 2 or 5 Digit Extension
  • UPC 2 or 5 Digit Extension
  • Plessey
  • POSTNET
  • Standard 2 of 5
  • Industrial 2 of 5
  • Interleaved 2 of 5
  • LOGMARS
  • MSI
  • Codabar
  • Planet Code
  • Codablock
  • PDF-417
  • Code 49
  • Data Matrix
  • Maxi Code
  • QR Code
  • TLC 39
  • Micro PDF
  • RSS-14
  • Aztec Code
  • Micro PDF-417
Application/Usage:
Industrial
Features:
  • Tear-off
  • Element Energy Equalizer
  • Clear Bi-fold Media Side Door
  • Bi-color LED
Memory
Standard Memory:
128 MB
Memory Technology:
DRAM
Flash Memory:
128 MB
Interfaces/Ports
Serial Port:
Yes
USB:
Yes
Media Types & Handling
Media Type:
  • Continuous Label
  • Die-cut Label
  • Notch
  • Black Mark
  • Label
  • Linered Label
Media Sensor:
  • Transmissive Media Sensor
  • Reflective Media Sensor
Media Thickness:
10 mil
Maximum Roll Diameter:
8"
Maximum Label Width:
4.50"
Maximum Label Length:
39"
Label Core Size:
3"
Ribbon Core Size:
1"
Fonts & Emulation
Language Emulation:
ZPL
Power Description
Power Source:
AC Supply
Input Voltage:
  • 110 V AC
  • 220 V AC
Physical Characteristics
Height:
11"
Width:
9.4"
Depth:
17"
Weight (Approximate):
17 lb
Miscellaneous
Package Contents:
  • ZT220 Industrial Printer
  • Power Cord with US Plug
Platform Supported:
PC
Certifications & Standards:
  • IEC 60950
  • EN 55022 Class B
  • EN55024
  • EN 61000-3-2
  • EN 61000-3-3
  • UL
  • CE Marking
  • FCC-B
  • ICES-003
  • VCCI
  • C-Tick
  • NOM
  • IRAM
  • CCC
  • GOST-R
  • PFC
  • Unicode
Energy Star:
Yes
Environmentally Friendly:
Yes
Country of Origin:
China
Warranty
Limited Warranty:
1 Year
Item Numbers
GTIN: 0032017023796, 0682017484457
UPC: 032017023796, 682017484457
EAN: 0032017023796, 0682017484457
UNSPSC: 43212108
Questions? Get help from a
Printer Expert!

How many labels will you print per day?

The Zebra ZT22043-T01000FZ Barcode Label Printer is also known as ZEB-ZT22043T01000FZ or ZT22043T01000FZ.
