Zebra ZT22042-T11100FZ Barcode Label Printer

The Zebra ZT22042-T11100FZ Barcode Label Printer has been discontinued.
No direct replacement is available.
Please contact us for a suitable substitute.

Zebra ZT220 - 4In, 203Dpi, Thermal Transfer, Peel, Power Cord With Us Plug, Serial,Usb,Parallel Zpl

Print Resolution

203 dpi

Direct Thermal/Thermal Transfer Printer offers reliable performance with outstanding printing quality
203 maximum print resolution (dpi) offers great dependability with added efficiency
The printer is capable of printing sharp and detailed monochrome documents quickly
Enjoy maximum efficiency with label print printing
4.50" maximum label width to easily accommodate your needs with added productivity
39" maximum label length for dependable, desired results
Supports continuous label media type for dependable, efficient results with maximum productivity
Direct Thermal/Thermal Transfer Printer with industrial application/usage provides reliable, feasible printing solution
Comes with 128 MB standard memory for timely printing with added reliability

Need a different version? See all Zebra ZT220 Barcode Label Printers

Discontinued Need Assistance?

Add to Quote

Zebra ZT22042-T11100FZ Barcode Label Printer

Overview

Full specifications (PDF)

Zebra ZT220 Barcode Label Printer Model Overview

Zebra's ZT220 Industrial Printers are Zebra's most affordable industrial printers that incorporate extensive customer feedback and the learnings from legacy printers—creating innovative printers with a space-saving design. Featuring Zebra's Link-OS environment, the ZT220 provides users with effortless setup, intuitive operation and easy service and maintenance. Whether you are adopting barcode technology for the first time or upgrading existing printer models, the ZT220 is the right choice for a variety of labeling applications. These innovative printers provide many user benefits, and they are ENERGY STAR qualified to save you money throughout their lifecycle. The ZT220 has a durable high-impact polymer case for long-lasting use, and a simple single-use three-button user interface. The ZT220 is ideal for barcode-labeling applications where minimal formal or printer setting changes are required.

Zebra ZT22042-T11100FZ Barcode Label Printer Overview

Zebra incorporated extensive customer feedback, as well as the legacy of our industry leading Stripe and S4M printers, to create the new ZT200 Series family of printers with elegant space saving design, effortless setup, intuitive user operation, and ease of service and maintenance.

Detailed Specs

Full specifications (PDF)

Technical Information

Recommended Use:

Label Print

Print Color Capability:

Monochrome

Maximum Mono Print Speed:

6 in/s

Maximum Print Resolution (dpi):

203

Maximum Print Width:

4.09"

Barcode Symbology Supported:

Code 11
Code 39
Code 93
Code 128-A
Code 128-B
Code 128-C
UCC Case Codes
ISBT-128
UPC-A
UPC-E
EAN-13
EAN-8
EAN With 2 or 5 Digit Extension
UPC 2 or 5 Digit Extension
Plessey
POSTNET
Standard 2 of 5
Industrial 2 of 5
Interleaved 2 of 5
LOGMARS
MSI
RSS Composite
Planet Code
Codablock
PDF-417
Code 49
Data Matrix
Maxi Code
QR Code
TLC 39
Micro PDF
RSS-14
Aztec Code
Micro PDF-417

Peel Facility:

Yes

Application/Usage:

Industrial

Features:

Clear Bi-fold Media Side Door
Element Energy Equalizer
Bi-color LED

Memory

Standard Memory:

128 MB

Memory Technology:

DRAM

Flash Memory:

128 MB

Interfaces/Ports

Parallel Port:

Yes

Serial Port:

Yes

USB:

Yes

Media Types & Handling

Media Type:

Continuous Label
Die-cut Label
Notch
Black Mark

Media Sensor:

Transmissive Media Sensor
Reflective Media Sensor

Media Thickness:

10 mil

Maximum Roll Diameter:

Maximum Label Width:

4.50"

Maximum Label Length:

39"

Label Core Size:

Ribbon Core Size:

Fonts & Emulation

Language Emulation:

ZPL
ZPL 1
ZPL II

Power Description

Power Source:

AC Supply

Input Voltage:

110 V AC
220 V AC

Physical Characteristics

Height:

10.9"

Width:

9.5"

Depth:

17"

Weight (Approximate):

20 lb

Miscellaneous

Package Contents:

ZT220 Industrial Printer
Power Cord with US Plug

Platform Supported:

Certifications & Standards:

IEC 60950
EN 55022 Class B
EN55024
EN 61000-3-2
EN 61000-3-3
UL
CE Marking
FCC-B
ICES-003
VCCI
C-Tick
NOM
IRAM
CCC
GOST-R
Unicode
KCC
BSMI
UkrSepro

Energy Star:

Yes

Environmentally Friendly:

Yes

Item Numbers

GTIN: 0032017065611, 0650005767097

UPC: 032017065611, 650005767097

EAN: 0032017065611, 0650005767097

UNSPSC: 43212108

Q&A

Questions? Get help from a
Printer Expert!

The Zebra ZT22042-T11100FZ Barcode Label Printer is also known as ZEB-ZT22042T11100FZ or ZT22042T11100FZ.
