Zebra ZM400-2011-0100T Barcode Label Printer

The Zebra ZM400-2011-0100T Barcode Label Printer has been discontinued.
No direct replacement is available.
Please contact us for a suitable substitute.

Zebra ZM400 - Thermal Transfer printing, 203 dpi, 4" print width, USB, Parallel, Serial, and Ethernet Interfaces, 64MB Flash Expanded. Includes US Power cord. Cables sold separately.

Printer Type

Industrial

Printing Technology

Thermal Transfer

Interface Options

Ethernet, Parallel, Serial (RS-232), USB

Print Resolution

203 dpi

Max Print Width

4.5 inch

Ribbon Core Size

1 inch

A smart choice for carrying out high volume label printing in multiple areas with reduced cost of ownership
203 maximum print resolution (dpi) for better reliance and added usability
Produce high-quality documents with this monochrome printer to increase your productivity
Delivers high-speed, hassle-free labeling solution for your business needs
Save time and money for your business by using one printer for all your employees
4.25" maximum label width for dependable, desired results
39" maximum label length for your convenience and feasible usability
Supports black mark media type for maximum feasibility and better accommodation of your requirements
Direct Thermal/Thermal Transfer Printer with desktop application/usage provides dependable printing solution with added productivity
Liner Take Up Spindle feature for maximum productivity with added dependability

Need a different version? See all Zebra ZM400 Barcode Label Printers

Discontinued Need Assistance?

Add to Quote

Zebra ZM400-2011-0100T Barcode Label Printer

Overview

Full specifications (PDF)

Zebra ZM400 Barcode Label Printer Model Overview

Zebra's best-in-class Z Series printers just got better! The Zebra ZM400 includes additional productivity-enhancing features and modern, flexible network connectivity for easy system integration in most manufacturing, warehousing and business applications. This industrial/commercial workhorse also delivers efficient 4-inch-wide labeling thanks to its quick throughput and 10 inches-per-second print speed. Built RFID Ready and offering a multitude of options including 600-dpi (24 dots/mm) resolution, the ZM400 is upgradeable to grow with changing needs. Plus, design enhancements make this new-generation Z Series printer even easier to operate, load, and maintain.

Zebra ZM400-2011-0100T Barcode Label Printer Overview

The ZM400 includes additional productivity-enhancing features and modern, flexible network connectivity for easy system integration in most manufacturing, warehousing and business applications. This industrial/commercial workhorse also delivers efficient 4-inch-wide labeling thanks to its quick throughput the ZM400 is upgradeable to grow with changing needs.

Detailed Specs

Full specifications (PDF)

Technical Information

Recommended Use:

Label Print

Print Color Capability:

Monochrome

Maximum Mono Print Speed:

10 in/s

Maximum Print Resolution (dpi):

203

Maximum Print Width:

4.09"

Barcode Symbology Supported:

Codabar
Code 11
Code 128-A
Code 128-B
Code 128-C
UCC Case Codes
Code 39
Code 93
EAN-13
EAN-8
Industrial 2 of 5
Interleaved 2 of 5
LOGMARS
MSI
Planet Code
Plessey
POSTNET
RSS
Standard 2 of 5
UPC
EAN With 2 or 5 Digit Extension
UPC-A
UPC-E
Aztec Code
Codablock
Code 49
Data Matrix
Maxi Code
QR Code
PDF-417
Micro PDF-417

Real Time Clock:

Yes

Application/Usage:

Desktop

Features:

Liner Take Up Spindle
Element Energy Equalizer

Memory

Standard Memory:

16 MB

Memory Technology:

DRAM

Flash Memory:

64 MB

Interfaces/Ports

Parallel Port:

Yes

Serial Port:

Yes

USB:

Yes

Network & Communication

Ethernet:

Yes

Ethernet Technology:

Fast Ethernet

Media Types & Handling

Media Type:

Black Mark
Continuous Form
Die-cut Label
Fanfold
Notched
Perforated Label
Tag Stock

Media Sensor:

Reflective Media Sensor
Transmissive Media Sensor

Media Thickness:

9.84 mil

Maximum Roll Diameter:

Maximum Label Width:

4.25"

Maximum Label Length:

39"

Label Core Size:

Ribbon Core Size:

Fonts & Emulation

Language Emulation:

ZPL II
EPL
XML
APL-I
APL-D
ZBI 2.0

Software

Operating System Supported:

Windows XP
Windows Vista
Windows 7
Windows 8

Power Description

Power Source:

AC Supply

Input Voltage:

120 V AC
230 V AC

Physical Characteristics

Product Color:

Charcoal
Gray

Height:

13.3"

Width:

10.9"

Depth:

18.7"

Weight (Approximate):

33.07 lb

Miscellaneous

Package Contents:

ZM400 Label Printer
Safety Guide
User's Cd
Power Cord with US plug

Cables Included:

Additional Information:

Ribbon Coated out Spindal
RFID Ready
Real Time Clock
Unicode -Compliant
Color Coded Operator cues
Quick Change Printhead and Platen
Transmissive and Reflective Media Sensors
Multi-lingual Backlit 240x128 pixel Graphic Display

Platform Supported:

Certifications & Standards:

IEC 60950-1 EN 55022 Class B
EN 55024
EN 61000-3-2
EN 61000-3-3
cTUVus
CE
FCC-B
ICES-003
VCCI
C-Tick
NOM
CCC
GOST-R
BSMI
S-Mark
SABS
MIC
ZIK
PFC

Environmentally Friendly:

Yes

Environmental Certification:

RoHS
WEEE

Warranty

Limited Warranty:

1 Year

Item Numbers

GTIN: 0087944055464, 0778889969311

UPC: 087944055464, 778889969311

EAN: 0087944055464, 0778889969311

UNSPSC: 43212108
