Zebra ZD62143-T01L01EZ Barcode Label Printer

Zebra ZD6A143-301L01EZ Barcode Label Printer A newer version of this item is available.
It is replaced by the Zebra ZD6A143-301L01EZ Barcode Label Printer.
Zebra ZD620t - Desktop Label Printer, Zebra ZD620t, Thermal Transfer, 300 dpi, 6ips, USB/USB Host/Serial/Ethernet/Bluetooth/Wi-Fi, LCD User Interface, 4-inch Print Width
Printer Type
Desktop
Printing Technology
Thermal Transfer
Interface Options
Bluetooth, Ethernet, Serial (RS-232), USB, USB Host, Wi-Fi
Print Resolution
300 dpi
Max Print Width
4.75 inch
Ribbon Core Size
1 inch
  • Thermal Transfer print method
  • ZPL and EPL programming languages
  • 5 status icon, 3 button user interface
  • USB 2.0, USB Host, Serial, Ethernet, BTLE
  • Media dancer
  • OpenACCESS™ for easy media loading
  • Dual-wall frame construction
  • ENERGY STAR qualified
  • Real Time Clock
Read More
Discontinued See Replacement
Add to Quote
Zebra ZD620 Barcode Label Printer Model Overview
Zebra's ZD620 4-Inch Performance Desktop Printers provide maximum print quality, efficiency and mangeability. The next generation in Zebra's desktop printer line, the ZD620 replaces Zebra's popular GX Series and ZD500 printers, rising above conventional desktop printers with premium print quality and state of the art features. Available in direct thermal, thermal transfer and healthcare models, the ZD620 meets a wide variety of application requirements. The ZD620 is easy to set up and configure and has an option 10-button user interface and color LCD. The display changes color when the printer is paused or in an error state, so users can instantly identify and resolve an issue before productivity is impacted. You can connect the ZD620 to your existing wired and wireless networks, or directly to any PC. Every ZD620 comes with Ethernet, Serial, USB 2.0 and USB Host.
Zebra ZD62143-T01L01EZ Barcode Label Printer Overview
ZD620 4-Inch Performance Desktop Thermal Transfer Printer

MAXIMUM PRINT QUALITY, EFFICIENCY AND MANAGEABILITY

When print quality, productivity, application flexibility and management simplicity matter, the Zebra ZD620 delivers. As the next generation in Zebra's thermal transfer desktop line, the ZD620 replaces Zebra's popular GX Series and ZD500 printers, rising above conventional desktop printers with premium print quality and state of the art features. Offering the most standard features of any Zebra desktop printer, the ZD620 is designed to meet a wide variety of application requirements. An optional 10-button user interface with a color LCD takes all the guesswork out of printer setup and status. The ZD620 runs Link-OS® and is supported by our powerful Print DNA suite of applications, utilities and developer tools that deliver a superior printing experience through better performance, simplified remote manageability and easier integration. The Zebra ZD620 - delivering the print speed, print quality and printer manageability you need to keep your operations moving forward. PREMIER PRINTING PERFORMANCE Best-in-class print speeds The ZD620 delivers best-in-class print speeds - 8ips @ 203 dpi and 6ips @ 300 dpi - for maximum printer throughput and productivity. EASY TO USE - PRACTICALLY NO TRAINING REQUIRED New at-a-glance five LED status icons take the guesswork out of printer status The standard three-button user interface with five LED status icons replaces the typical single button/single light interface common in desktop printers. Users can instantly see what's needed to keep printers up and running, from replenishing media to resolving printer issues. Configuration is a snap with the optional color LCD and 10-button user interface It's easy to set up and configure the ZD620 with the optional 10-button user interface and color LCD. The display changes color when the printer is paused or in an error state, so users can instantly identify and resolve an issue before productivity is impacted.

DEPLOYMENT AND APPLICATION FLEXIBILITY

Backwards compatibility with virtually any existing printer With the ZD620, whether you are currently using a Zebra or competitive printer, you'll be able to use the same label formats and applications you're using today. The ZD620 supports both EPL and ZPL printer languages. And with on printer Virtual Devices, part of Zebra's Print DNA suite of tools and utilities, the ZD620 can use languages normally associated with other printer brands.

Comprehensive connectivity options

With comprehensive connection options, you can connect the ZD620 to your existing wired and wireless networks, or directly to any PC. Every ZD620 comes with Ethernet, Serial, USB 2.0 and USB Host, as well as Bluetooth Low Energy (BLE), which enables printing from any iOS device. Wireless models include fast 802.11ac Wi-Fi and Bluetooth 4.1. And using the included Print Touch tag (NFC), users can simply tap a compatible mobile device on the ZD620 to pair and print - as well as instantly access Zebra's extensive knowledge base of how-to videos.

Movable sensor for comprehensive media compatibility

While Zebra Certified Printer Supplies provide optimal printer performance, the ZD620's movable media sensor lets you use virtually any media from any manufacturer, giving you the flexibility to utilize supplies you may have on hand or continue to utilize an existing supplies provider.
Technical Information
Recommended Use:
Label/Receipt Print
Print Color Capability:
Monochrome
Maximum Mono Print Speed:
5.98 in/s
Maximum Print Resolution (dpi):
300
Maximum Print Width:
4.25"
Application/Usage:
Desktop
Mobile Device Printing:
Yes
Memory
Standard Memory:
512 MB
Interfaces/Ports
Serial Port:
Yes
Network & Communication
Ethernet:
Yes
Bluetooth:
Yes
Wireless LAN:
Yes
Near Field Communication (NFC):
Yes
Media Types & Handling
Media Type:
  • Tag
  • Label
  • Receipt
  • Black Mark
  • Reflective
  • Gap
  • Roll Fed
  • Fanfold
  • Die-cut Label
  • Continuous Roll
  • Tag Stock
  • Continuous Receipt
  • Wristband
Maximum Roll Diameter:
5"
Maximum Label Width:
4.65"
Maximum Label Length:
39.02"
Power Description
Power Source:
AC Supply
Physical Characteristics
Height:
7.6"
Width:
8"
Depth:
10.5"
Weight (Approximate):
5.50 lb
Miscellaneous
Package Contents:
  • ZD620 Thermal Transfer Printer
  • Empty Ribbon Take-up Cores (1 in. and 0.5 in.)
  • 2 x 300 m Ribbon Core Adapter for Non-Zebra Ribbon
  • AC Power Supply
  • Power Cords (EU & UK)
  • USB Cable
  • Quick Start Guide
  • Regulatory Guide
Cables Included:
  • USB
  • AC
Power Adapter Included:
Yes
Energy Star:
Yes
Country of Origin:
China
Item Numbers
UNSPSC: 43212108
