Full specifications (PDF)
- Single or Multimode Operation
- Constant Asset Visibility
- Enterprise Wide Asset Tracking
- Configurable Power Output
- Long Range and Battery Life
- HERO Tested
- IS Certified Version
ISO/IEC 24730-2 mode is used to provide high precision locations in industrial and outdoor applications, while CCX mode is normally used in “front office” applications. Zebra’s ISO/IEC 24730-2 RTLS solutions utilize Time Difference Of Arrival (TDOA) to attain the highest possible accuracy in hostile environments. In many applications, precision within less than two meters can be provided to optimize business applications. Cisco’s Unified Wireless Network can utilize CCX to minimize installation costs and complexity by using a single wireless infrastructure. The use of either technology enables the WhereTag IV to provide enterprise-wide tracking of assets, personnel and WIP transactions.
The WhereTag IV can be programmed to “blink” RF transmissions at rates ranging from 4 seconds to multiple hours. Power output is also configurable to match the requirements of the application environment. The WhereTag IV operates in the globally accepted 2.4 GHz frequency band and utilizes Direct Sequence Spread Spectrum (DSSS) technology to maximize range and battery life. Battery life can be up to 7 years in ISO/ IEC 24730-2 mode and up to 5 years in CCX and multimode operations.
The WhereTag IV can also be triggered by a low frequency magnetic signal from a WherePort exciter. This capability is utilized to modify the pre-programmed blink rate and to indicate proximity (localization) to a specific WherePort. WherePorts can also trigger changes between ISO/IEC 24730-2 mode, Wi-Fi mode (CCX compatible), or multimode from a distance of up to 7.5 meters.
An Intrinsically Safe (IS) version is available for use in hazardous and explosive environments. The WhereTag IV IS is certified to be safe for Class 1, Division 1, Groups A-D, T6 environments.
The WhereTag IV enables Zebra Location Solutions, the leader in RTLS, to provide technology and solutions tailored to match application requirements.
Tag Mounting Options:
- WhereTag IV Snap-On Mounting Ring (The optional WhereTag IV Snap-on Mounting Ring fits onto the WhereTag IV asset tag to provide identical mounting tabs with screw and rivet holes to match the standard WhereTag III design.)
- Vehicle Rearview Mirror Mount
- Trailer, Rail Car, and ISO Container Mounts
