Zebra TC77HL-5MK24BG-NA Mobile Computer

Zebra TC77 - Mobile Computers, Zebra TC77, TC77 SE4750, 5MP Front/13MP Rear Camera, Android, 4GB RAM/32GB Flash, 2 SIM/, 1 Micro SD, GMS, USA/Canada/Puerto Rico, Does Not Support ARCore
  • Touch panel gives your workforce ease, along with familiar and flexible operation, thus improving overall efficiency on a daily basis
  • 4.7" LED screen is ideal for scan intensive applications
  • NFC is perfect for automated identity approval at facility section points
  • Regardless of angle orientation, the imager makes it easy to scan 1D and 2D barcodes
  • Android OS for speedier, smoother and responsive performance; offers amazing features to both users and developers
  • 4 GB RAM / 32 GB flash memory helps run applications rapidly and stores the mightiest databases
  • microSD card slot gives an extra storage option
  • Wireless connectivity provides computing versatility throughout the workplace
  • With integrated Bluetooth module, gadgets such as portable tag printers can be utilized rapidly and effortlessly without cable connections
  • Phone-size form factor allows trouble-free and easy usage with increased efficiency
Read More
$2,632.02
3-year Premium Plus ($703.60)
3-year Premium ($454.60)
No Support
Add to Quote
Zebra TC77 Mobile Computer Model Overview
The TC77 Android Touch Computer is the ultra-rugged all-touch computer for outside the four walls — a smartphone experience for simplicity, designed to withstand the toughest everyday use and a new platform offering more capabilities.

Key Features:
  • Powerful Qualcomm SD660 Architecture with long OS lifecycle - upgradable through Android R and Mobility DNA
  • Dual side scan keys with Digimarc support
  • Only multi-mode all-touch interface – No setting change switching form gloved to un-gloved finger input.
  • PowerPrecision+ replaceable battery for best-in-class, 15-hour power and manageability, fast recharge and warm swap mode
  • Ultra-rugged design virtually dust, drop, moisture and tumble proof.


At the edge of your business are your front line workers that spend their days face-to-face serving the important asset in your company — your customers. Now, there’s a device designed to take customer service to the next level by delivering everything your workers need to achieve peak efficiency, with trouble-free reliability — the TC72 and TC77 Android Touch Computers. This family builds on the highly successful TC7 Series family to create the ultimate ultra-rugged all-touch computer for all workers inside and outside the four walls — a smartphone experience for maximum simplicity, construction designed to withstand years of the toughest everyday use and abuse, and a new platform offering more capabilities than any other device in this class. The TC72 and TC77 — for a real competitive edge at the edge of your business, delivered.


Android for instant familiarity

Your workers already know how to use an Android device, virtually eliminating training time and adoption curves. And you can deliver the highly graphic interactive apps today’s workers expect


Advanced touchscreen technology

Give your workers touchscreen simplicity. The high-definition display offers plenty of real estate for graphics-intensive intuitive applications. The easy, familiar and flexible multi-touch operation works even when wet, with a gloved finger or a stylus. And with best-in-class outdoor readability, the screen is easy to read, even in bright sunlight.


Super simple data capture — from barcodes to labels and documents

Advanced scanning technology and PRZM Intelligent Imaging deliver lightning fast capture of printed and electronic 1D and 2D barcodes, including Digimarc — regardless of condition. The expanded working range and wide field of view allow workers to scan barcodes nearer and farther away, while omnidirectional scanning delivers true point and shoot performance — no need to ever align the device with the barcode. Need to capture multiple barcodes on a single label or data on a form, such as checkboxes, text fields, signatures and more? You can do it all with the press of a single button with Zebra’s SimulScan, a no-cost pre-installed Mobility DNA application


Full shift power your workers can count on

The PowerPrecision+ high capacity battery delivers up to an impressive 15 hours of power1 — plenty for the longest shift. With Warm Swap mode, swapping batteries is fast and easy — there’s no need to turn off the device or close active apps. And with fast charging, batteries are fully charged and ready to go in record time.


Complete cellular network flexibility with single device simplicity

No matter where your workers are, you can give them dependable cellular service. Simultaneous support for two carriers is ideal for workers that travel to areas better served by different carriers. And aggregated carrier support delivers faster upload and download speeds and provides first responders with access to public safety channels for mission-critical communications.


Support for the latest WiFi enhancement improves WiFi range and speed— with less power

Provide your users with faster and more reliable WiFi connections with 2x2 Multiple-User Multiple Input Multiple Output (MU-MIMO) technology. Your access points can now communicate with multiple devices simultaneously via pinpoint beamforming, boosting WiFi network capacity, speed and range. And processing is shifted from the mobile device to the access point, extending battery cycle time.


Bluetooth 5.0 for twice the speed and four times the range — with less power

An extended range of 800 ft./240 m and data speeds up to 2 Mbps increase application flexibility and performance for Bluetooth peripherals, such as printers and headsets, while Bluetooth Low Energy reduces power requirements to extend battery cycle times


New 5 MP front-facing camera supports more advanced apps

With the new front-facing camera, you get built-in support for the latest locationing technology, Visible Light Communication (VLC), which allows you to track the location of shoppers and workers using existing LED lighting infrastructure. Video calling improves service and productivity. Customers enjoy a more personal touch — and remote experts can see a repair in process to help onsite technicians resolve issues faster and increase first-time-fix rates.


Ultra high-resolution photos and videos

The 13 MP color rear camera captures highly detailed photos and videos — ideal for proof-of-condition/delivery/service, onsite technical support and more.


The highest quality voice in its class

With high-volume speakers and noise-cancellation technology, callers on both ends of every call can hear every word — even in the noisiest areas.


The ultimate in ultra-rugged proven design

When it comes to use and abuse and demanding environmental conditions, the TC72/TC77 is at the top of its class. Built to handle 8 ft./2.4 m drops to concrete and 2,000 tumbles, with IP65 and IP67 sealing, this device is virtually waterproof, drop-proof, dust-proof and tumble-proof — workers can drop it, use it outdoors in the rain, snow, freezing cold or sweltering heat and still expect reliable operation. And the Corning Gorilla Glass touch panel and imager window bring maximum scratch-resistance and shatter-proofing to two of the most vulnerable device features — the display and lens eye.


A platform to handle all your apps — today and tomorrow

The ultra-powerful processor provides superior performance on all voice and data apps. You also get built-in support for the next two versions of Android (P and Q)2 and future apps, such as artificial intelligence.


Maximize productivity with enterprise accessories

Unlike consumer smartphones, a full suite of business-class accessories improve ease of use and management. A trigger handle makes scanning easier and unique ShareCradles that charge devices and batteries simplify backroom management. And with full backwards compatibility with TC70x/ TC75x accessories, you can cost-efficiently upgrade to advanced touch computing that will better serve your bottom line.


Rich locationing support

Easily implement locationing with support for many technologies, including VLC, Bluetooth 5.0 BLE and WiFi, plus Zebra’s SmartLens and MPact Solutions.


WorryFree WiFi — dependably superior WiFi, delivered

Provide every worker with the best possible WiFi connection, every minute of every shift. This free tool delivers near instant application response times, unmatched roaming performance, plus exceptional voice quality and network diagnostics — everything you need to leverage your WiFi network to increase workforce productivity and better serve customers


PowerPrecision Console — prevent aging batteries from reducing workforce productivity

Identify and remove aging batteries from your battery pool with this free PC-based solution, before they impact workforce productivity and mobile device uptime.


End-to-end revolutionary control of the update process with LifeGuardTM for Android

Updating your enterprise-class Android mobile devices is often time-consuming, costly, complex and difficult to track. Now you can do it all with LifeGuard Analytics — free with your Zebra OneCare Support contract. See which updates are available along with priority and which devices are eligible for the update. Automatically update your devices over the air with the press of a button. And easily monitor and manage the status of updates in real time.


Easily manage access to Google Mobile Services (GMS) with Restricted Mode

StageNow’s new Restricted Mode delivers an industry first — an easy way to simply click to deactivate Google Mobile Services (GMS) that come standard with the operating system — and reactivate should you need them down the road. StageNow is free and pre-loaded on every TC72/TC77.


Improve device value with Zebra’s optional Visibility Services

Get the device management data you need to take device uptime, operational efficiency and the return on investment to the next level with Zebra’s optional Visibility Services. Asset Visibility Service (AVS) is an easy to use and easy to deploy solution that doesn’t require an Enterprise Mobility Management (EMM) system. Operational Visibility Services (OVS) is a comprehensive device management solution that leverages and adds to the information in an EMM to help you get more value out of your Zebra mobile devices. Both services are options that are available through any Zebra OneCare support contract.


TC72/TC77 Series vertical markets and applications:

 RETAIL • Price audits/changes • Store receiving • Inventory management • Voice communications • Line busting • Asset management • Click & collect MANUFACTURING • Order/returns processing • Proof of delivery • Route optimization • Inventory management • Planogram compliance • Technical documentation access (schematics/ training guides) • Customer service • Work order management • Voice communications TRANSPORTATION & LOGISTICS • Last mile delivery • Package/pallet track and trace • Proof of delivery/ pickup (signature/ photo) • Route optimization • Fleet management • Payment collection • Electronic driver logging • In-cab telematics monitoring • Voice communications WAREHOUSE • Picking/put-away • Warehouse management • Returns processing • EDI transactions • Voice communications


Zebra TC77HL-5MK24BG-NA Mobile Computer Overview

THE ULTIMATE IN ULTRA-RUGGED ENTERPRISE-CLASS ALL TOUCH COMPUTING

At the edge of your business are your front line workers that spend their days face-to-face serving the important asset in your company - your customers. Now, there's a device designed to take customer service to the next level by delivering everything your workers need to achieve peak efficiency, with trouble-free reliability - the TC72 and TC77 Android Touch Computers. This family builds on the highly successful TC7 Series family to create the ultimate ultra-rugged all-touch computer for all workers inside and outside the four walls - a smartphone experience for maximum simplicity, construction designed to withstand years of the toughest everyday use and abuse, and a new platform offering more capabilities than any other device in this class. The TC72 and TC77 - for a real competitive edge at the edge of your business, delivered.

And with best-in-class outdoor readability, the screen is easy to read, even in bright sunlight.

Super simple data capture: barcodes, labels and documents

Advanced scanning technology and PRZM Intelligent Imaging deliver lightning fast capture of printed and electronic 1D and 2D barcodes, including Digimarc - regardless of condition. The expanded working range and wide field of view allow workers to scan barcodes nearer and farther away, while omnidirectional scanning delivers true point and shoot performance - no need to ever align the device with the barcode. Need to capture multiple barcodes on a label or data on a form? You can do it all with the press of a single button with Zebra's SimulScan, a no-cost pre-installed Mobility DNA application.

Full shift power your workers can count on

The PowerPrecision+ high capacity battery delivers up to an impressive 15 hours of power1- plenty for the longest shift. With Warm Swap mode, swapping batteries is fast and easy - there's no need to turn off the device or close active apps. And with fast charging, batteries are fully charged in record time.

Complete cellular network flexibility with single device simplicity

No matter where your workers are, they can stay connected. Simultaneous support for two carriers is ideal for workers that travel to areas better served by different carriers. And aggregated carrier support delivers faster upload and download speeds. The TC77 is certified on leading public safety networks, including AT&T FirstNet and Verizon, assuring responders have the connectivity they need even when networks are overloaded in crisis situations.

THE ULTIMATE USER EXPERIENCE

Android for instant familiarity

Your workers already know how to use an Android device, virtually eliminating training time and adoption curves. And you can deliver the highly graphic interactive apps today's workers expect.

Advanced touchscreen technology

The high-definition display offers plenty of real estate for intuitive graphics-intensive applications. The easy, familiar and flexible multi-touch operation works even when wet, with a gloved finger or a stylus.

Longer WiFi range and speed - with less power

2x2 Multiple-User Multiple Input Multiple Output (MU-MIMO) technology allows access points to communicate with multiple devices simultaneously via pinpoint beamforming, boosting WiFi network capacity, speed and range. And processing is shifted from the mobile device to the access point, extending battery cycle time.

Bluetooth 5.0 for twice the speed and four times the range

An extended range of 800 ft./240 m and data speeds up to 2 Mbps increase application flexibility and performance for Bluetooth peripherals, such as printers and headset

Technical Information
Connectivity Technology:
Wireless
Scanning Capability:
  • 1D
  • 2D
Scan Engine Model:
SE4750
Image Sensor Type:
Imager
Scanner Range:
Standard Range
Google Mobile Services (GMS):
Yes
Sensor Type:
  • Light Sensor
  • Motion Sensor
  • eCompass
  • Accelerometer
  • Gyroscope
  • Pressure Sensor
Multi-SIM Supported:
Yes
Number of SIM Card Supported:
2.0
SIM Size Supported:
Nano
Features:
  • Push-to-talk
  • Gorilla Glass
  • Drop Resistant
Drop Specification:

Multiple 6 ft./1.8 m drop to concrete across full operating temperature range, multiple 8 ft./2.4 m drop to concrete at room temperature per MIL-STD 810G

Processor & Chipset
Processor Manufacturer:
Qualcomm
Processor Type:
Snapdragon
Processor Model:
660
Processor Core:
Octa-core (8 Core)
Processor Speed:
2.20 GHz
Memory
Standard Memory:
4 GB
Flash Memory:
32 GB
Memory Card Supported:
microSD
Display & Graphics
Screen Size:
4.7"
Screen Mode:
HD
Screen Resolution:
1280 x 720
Display Screen Type:
LED
Touchscreen Information
Touchscreen:
Yes
Multi-touch Screen:
Yes
Keyboard/Keypad
Buttons & Keys:

On-screen keypad and Enterprise Keyboard

Network & Communication
Wireless LAN:
Yes
Wireless LAN Standard:
IEEE 802.11 a/b/g/n/ac/d/h/i/r/k/v/w
Bluetooth:
Yes
Bluetooth Standard:
Bluetooth 5.0 BLE
Near Field Communication (NFC):
Yes
Cellular Network Supported:
GSM
Cellular Data Connectivity Technology:
  • 4G
  • 4G LTE
  • UMTS
  • HSPA
  • HSPA+
  • GPRS
  • EDGE
GPS:
Yes
Global Navigation Satellite System (GNSS) Supported:
BeiDou/Galileo/GLONASS
Interfaces/Ports
USB:
Yes
Camera
Front Camera:
Yes
Front Camera Resolution:
5 Megapixel
Rear Camera:
Yes
Rear Camera Resolution:
13 Megapixel
Software
Operating System:
Android
Upgradable Operating System:
Android 14
Power Description
Power Source:
Battery
Battery Information
Battery Capacity:
4620 mAh
Battery Chemistry:
Lithium Ion (Li-Ion)
Battery Included:
Yes
Maximum Battery Run Time:
15 Hour
Battery Voltage:
3.70 V
Environmental Conditions
Operating Temperature:
-4°F (-20°C) to 122°F (50°C)
Storage Temperature:
-40°F (-40°C) to 158°F (70°C)
Humidity (Non-condensing):
5% to 95%
Physical Characteristics
Form Factor:
Phone-size
Rugged:
Yes
Height:
6.3"
Width:
3.3"
Depth:
1.1"
Weight (Approximate):
13.30 oz
Miscellaneous
Application/Usage:
  • Retail
  • Manufacturing
  • Transportation
  • Logistics
  • Warehouse
  • Government
  • Public Safety
Ingress Protection (IP) Rating:
  • IP65
  • IP67
Environmentally Friendly:
Yes
Environmental Certification:
  • RoHS
  • REACH
Warranty
Limited Warranty:
1 Year
Additional Warranty Information:

Subject to the terms of Zebra's hardware warranty statement, the TC72/TC77 Series is warranted against defects in workmanship and materials for a period of 1 (one) year from the date of shipment. For complete warranty statement, please visit:

http://www.zebra.com/warranty

Item Numbers
UNSPSC: 43211715
