Zebra R12-801-00000-R0 RFID Printer

A newer version of this item is available.
It is replaced by the Zebra ZT61042-T0101A0Z RFID Printer.

Zebra R110Xi4 - RFID Printer, UHF, Direct Thermal/Thermal Transfer, USB/Serial/Parallel/Ethernet Connection, ZebraNet Internal Print Server, 203 dpi, LCD. Cables Sold Separately.

Interface Options

Ethernet

Print Resolution

203 dpi

Direct Thermal/Thermal Transfer Printer is a reliable label/receipt printing solution with maximum efficiency
203 maximum print resolution (dpi) for your convenience and easy usage
Produce high-quality documents with this monochrome printer to increase your productivity
Designed for today's dynamic enterprise applications
Share the printer easily and efficiently with various other systems with the help of built-in Ethernet port
4.50" maximum label width for your convenience and feasible usability
12.50 ft maximum label length for your convenience and feasible usability
Supports black mark media type for better reliance and maximum usability
Direct Thermal/Thermal Transfer Printer with desktop application/usage provides reliable, feasible printing solution
Comes with 16 MB standard memory to make you productive with the direct thermal/thermal transfer printer?s smooth performance

Need a different version? See all Zebra R110Xi4 RFID Printers

Discontinued See Replacement

Add to Quote

Overview

Full specifications (PDF)

Zebra R110Xi4 RFID Printer Model Overview

The Zebra R110Xi4 RFID printer/encoder is optimized for high-volume operations, giving users the ability to print and encode a variety of UHF radio frequency identification smart labels for a multitude of applications. The R110Xi4 is designed with innovative, industry-leading features to meet the demands of current and future applications, and leverages the built-to-last Xi4 printer platform for robust performance. The R110Xi4 also features RFID media flexibility, RFID inlay position flexibility which allows the use of media converted for other brand printers and supports widest range of transponder designs and sizes.

Zebra R12-801-00000-R0 RFID Printer Overview

With Zebra's R110Xi4 RFID printer/encoder optimized for high-volume operations you can print and encode a variety of UHF radio frequency identification smart labels for a multitude of applications. As Zebra's third-generation RXi printer/encoder, the R110Xi4 is designed with innovative, industry-leading features to meet the demands of current and future applications, and leverages the built-to-last Xi4 printer platform for robust performance.

Detailed Specs

Full specifications (PDF)

Technical Information

Recommended Use:

RFID Label Print

Print Color Capability:

Monochrome

Maximum Mono Print Speed:

14 in/s

Maximum Print Resolution (dpi):

203

Maximum Print Width:

Barcode Symbology Supported:

Code 11
Code 39
Code 93
Code 128-A
Code 128-B
Code 128-C
UCC Case Codes
ISBT-128
UPC-A
UPC-E
EAN-13
EAN-8
UPC 2 or 5 Digit Extension
EAN With 2 or 5 Digit Extension
Plessey
POSTNET
Standard 2 of 5
Industrial 2 of 5
Interleaved 2 of 5
LOGMARS
MSI
Codabar
Planet Code
Codablock
PDF-417
Code 49
Data Matrix
QR Code
Maxi Code
TLC 39
Micro PDF
RSS
GS1 DataBar
Aztec Code
EAN

Encoding Technology:

RFID Encoder

Real Time Clock:

Yes

Application/Usage:

Desktop

Memory

Standard Memory:

16 MB

Memory Technology:

SDRAM

Flash Memory:

8 MB

Interfaces/Ports

Parallel Port:

Yes

Serial Port:

Yes

USB:

Yes

Network & Communication

Ethernet:

Yes

Ethernet Technology:

Fast Ethernet

RFID:

Yes

Display & Graphics

Display Screen:

Yes

Display Screen Type:

LCD

Media Types & Handling

Media Type:

Black Mark
Die-cut Label
Notch

Media Sensor:

Reflective Media Sensor
Transmissive Media Sensor

Media Thickness:

12 mil

Maximum Roll Diameter:

Maximum Label Width:

4.50"

Maximum Label Length:

12.50 ft

Label Core Size:

Ribbon Core Size:

Fonts & Emulation

Language Emulation:

XML
ZPL II

Power Description

Input Voltage:

120 V AC

Physical Characteristics

Height:

15.5"

Width:

10.3"

Depth:

20.4"

Miscellaneous

Package Contents:

R110Xi4 RFID Label Printer
North American Edition 120 VAC Power Cord
User Guide
Sotware CD

Cables Included:

Platform Supported:

Warranty

Limited Warranty:

1 Year

Item Numbers

GTIN: 0024606567057, 0783555031834

UPC: 024606567057, 783555031834

EAN: 0024606567057, 0783555031834

UNSPSC: 43212108

Q&A

Questions? Get help from a
Printer Expert!

The Zebra R12-801-00000-R0 RFID Printer is also known as ZEB-R1280100000 or R12-801-00000-R0.
