Zebra QN3-AUNA0E00-09 Portable Barcode Printer

The Zebra QN3-AUNA0E00-09 Portable Barcode Printer has been discontinued.
No direct replacement is available.
Please contact us for a suitable substitute.
Zebra QLn320 - Mobile Label Printer, Zebra QLn320, Direct Thermal, 203 dpi, 4ips, Wireless/Ethernet, XML/CPCL/ZPL/Belt Clip, Radio
Printer Type
Mobile
Printing Technology
Direct Thermal
Interface Options
Ethernet, Wi-Fi
Print Resolution
203 dpi
Max Print Width
3.25 inch
  • Direct Thermal Printer provides you with all the features that you need to print quickly and easily
  • 203 maximum print resolution (dpi) for better reliance and added usability
  • The printer is capable of printing sharp and detailed monochrome documents quickly
  • Enjoy maximum efficiency with label print printing
  • Tabletop form factor for your printing convenience and better reliance
  • Optimize your workflows by sharing the resources of the printer via Ethernet connectivity
  • Enjoy the freedom of wireless connectivity. With Wi-Fi, you will get things done faster.
  • 3.11" maximum label width for your convenience and feasible usability
  • 32.01" maximum label length for dependable, desired results
  • Supports linered label media type for better reliance and maximum usability
Read More
Discontinued Need Assistance?
Add to Quote
Zebra QLn320 Portable Barcode Printer Model Overview
Boost productivity and print anywhere with drop-resistant mobile printers that offer high-quality printing, easy integration, proactive alerts and convenient charging. Trust these mobile printers to improve efficiencies throughout operations–in the warehouse, shipping and receiving and merchandising. Quickly and easily print barcode labels, receipts, tickets and more, on-site and on-demand.
Zebra QN3-AUNA0E00-09 Portable Barcode Printer Overview

ZEBRA'S QLN FAMILY OF DIRECT THERMAL MOBILE LABEL AND RECEIPT PRINTERS

Zebra's popular QL™ family of direct thermal mobile label and receipt printers has built a highly satisfied following based upon its proven drop-resistant durability; user-friendly, productivity-boosting features; and easy integration. As Zebra's third generation of QL printers, the QLn™ series extends these QL-platform benefits to the "nth" power - whether you choose the QLn220™ for print widths up to 2 inches or the QLn320™ for 3-inch-wide printing.

The printers' over-molding and tempered-glass display - coupled with their seamless, one-piece design - make them more durable than ever before. These printers can boost your operation's productivity through their larger, sharper, easier-to-navigate display; faster, higher-quality printing; a variety of proactive alerts that help keep working printers in employees' hands; and many convenient charging accessories. And, your IT department will find the QLn printers more intuitive to integrate into existing platforms thanks to Zebra's Link-OS® environment. Other features such as Zebra® Global Printing and improved network performance - including 802.11n wireless LAN capability for more robust and reliable connectivity and throughput - also make integration easier.

With Zebra's Link-OS environment - an innovative operating system combining a powerful Multiplatform Software Development Kit (SDK) and software applications - the QLn printers are easy to integrate, manage and maintain from any location around the globe. Enabled with Print Touch™, these Link-OS printers offer web page launching features using Near Field Communication (NFC), making it easy to access Zebra's extensive knowledge base of how-to videos and product support.

Easier to Integrate, Manage, and Maintain

New features make it easier to integrate the QLn printer into your existing network and manage it from anywhere in the world - saving you IT time and costs.

Easier to Integrate

Move your business forward without the cost or stress of upgrades. Backwards compatibility with QL and QL Plus™ models lets you upgrade to the QLn printer without changing media or label formats. The inclusion of the legacy CPCL programming language also allows mixed networks of QL / QL Plus and QLn products.

Be assured of full compatibility with many other Zebra printers thanks to Zebra's ZPL® programming language. And with ZBI 2.x™, directly connect your printers with legacy host systems and peripheral devices, such as scanners and scales.

Maintain robust and reliable connectivity, even for your largest data transfers, with Wi-Fi®-certified connectivity. Zebra's 802.11n solution has dual-band support (5 GHz and 2.4 GHZ) and is fully compatible with 802.11a and 802.11b/g standards, so you can easily move business operations to the less-crowded 5 GHz band.

Technical Information
Recommended Use:
Label Print
Print Color Capability:
Monochrome
Maximum Mono Print Speed:
4 in/s
Maximum Print Resolution (dpi):
203
Maximum Print Length:
32"
Maximum Print Width:
2.80"
Barcode Symbology Supported:
  • Code 39
  • Code 93
  • UCC/EAN 128
  • Code 128
  • Codabar (NW-7)
  • Interleaved 2 of 5
  • UPC-E
  • UPC-A
  • 2 and 5 Digits Add-on
  • EAN-8
  • EAN-13
  • PDF417
  • Macro PDF-417
  • Maxi Code
  • QR Code
  • GS1 DataBar (RSS)
  • AZTEC
  • MSI PLESSEY
  • FIM
  • POSTNET
  • Data Matrix
  • TLC 39
Peel Facility:
Yes
Application/Usage:
  • Retail
  • Manufacturing
  • Transportation & Logistic
Features:
  • Belt Clip
  • Mirror Printing
  • Label Odometer
  • Vertical Printing
  • Horizontal Printing
  • Dust Resistant
  • Water Resistant
Mobile Device Printing:
Yes
Ingress Protection (IP) Rating:
  • IP43
  • IP54
Fonts Included:
  • 25 bitmapped
  • 1 smooth
  • scalable (CG Triumvirate Bold Condensed)
Memory
Standard Memory:
128 MB
Interfaces/Ports
Serial Port:
Yes
USB:
Yes
Network & Communication
Ethernet:
Yes
Ethernet Technology:
Fast Ethernet
Bluetooth:
Yes
Wireless LAN:
Yes
Wireless LAN Standard:
IEEE 802.11n
Near Field Communication (NFC):
Yes
Display & Graphics
Display Screen:
Yes
Display Screen Type:
LCD
Cutter
Cutter:
Yes
Cutter Type:
Tear Bar
Media Types & Handling
Media Type:
  • Linered Label
  • Black Bar
  • Gap
  • Direct Thermal Label
  • Die-cut Label
  • Linerless
  • Receipt
  • Black Mark
Media Sensor:
  • Label Taken Sensor
  • Black Mark Sensor
  • Gap Sensor
Media Thickness:
6.50 mil
Maximum Roll Diameter:
1.37"
Maximum Label Width:
3.11"
Maximum Label Length:
32.01"
Fonts & Emulation
Language Emulation:
  • CPCL
  • EPL
  • ZPL
  • ZBI 2.0
Power Description
Power Source:
Battery
Battery Information
Battery Included:
Yes
Battery Capacity:
2450 mAh
Environmental Conditions
Operating Temperature:
32°F (0°C) - 122°F (50°C)
Operating Relative Humidity:
10% - 90%
Storage Temperature:
-13°F (-25°C) - 158°F (70°C)
Storage Relative Humidity:
10% - 90%
Physical Characteristics
Form Factor:
Tabletop
Height:
3.3"
Width:
4.6"
Depth:
6.8"
Weight (Approximate):
1.60 lb
Miscellaneous
Package Contents:
  • QLn320 Direct Thermal Printer
  • Battery
Compatibility:
  • Apple iPod
  • Apple iPad
  • Apple iPhone
Platform Supported:
  • PC
  • Android
  • iOS
Certifications & Standards:
  • FCC Part 15, Subpart B
  • EN55022 Class-B
  • EN60950
  • EN55024
  • VCCI class B
  • EN61000-4-2
  • EN61000-4-3
  • EN61000-4-4
  • EN61000-4-5
  • CE
  • UL
  • TUV
  • CSA
Warranty
Limited Warranty:
1 Year
Item Numbers
UNSPSC: 45101512
Questions? Get help from a
Printer Expert!

How many labels will you print per day?

The Zebra QN3-AUNA0E00-09 Portable Barcode Printer is also known as ZEB-QN3AUNA0E0009
