Zebra QN3-AUCA0E00-00 Portable Barcode Printer

The Zebra QN3-AUCA0E00-00 Portable Barcode Printer has been discontinued.
No direct replacement is available.
Please contact us for a suitable substitute.

Zebra QLn320 - 3 INCH, USB, 128MB/256MB, CPCL, ZPL, LCD, ENGLISH, BLUETOOTH 3.0, DIRECT THERMAL/LINERED PLATEN, US, CANADA, ETHERNET SUPPORT, BELT CLIP

Print Resolution

203 dpi

Direct Thermal Printer provides you with all the features that you need to print quickly and easily
203 maximum print resolution (dpi) for your convenience and easy usage
Produce high-quality documents with this monochrome printer to increase your productivity
Enjoy the optimal performance in today's on-demand labeling applications
Bring convenience, value, and feature to any mobile environment
Share the printer easily and efficiently with various other systems with the help of built-in Ethernet port
3.10" maximum label width for dependable, desired results
32" maximum label length for your convenience and feasible usability
Supports linerless media type for better reliance and maximum usability
Direct Thermal Printer with mobile application/usage provides reliable, feasible printing solution

Need a different version? See all Zebra QLn320 Portable Barcode Printers

Discontinued Need Assistance?

Chat Now for Qty Discount

Add to Quote

Zebra QN3-AUCA0E00-00 Portable Barcode Printer

Overview

Full specifications (PDF)

Zebra QLn320 Portable Barcode Printer Model Overview

Boost productivity and print anywhere with drop-resistant mobile printers that offer high-quality printing, easy integration, proactive alerts and convenient charging. Trust these mobile printers to improve efficiencies throughout operations–in the warehouse, shipping and receiving and merchandising. Quickly and easily print barcode labels, receipts, tickets and more, on-site and on-demand.

Zebra QN3-AUCA0E00-00 Portable Barcode Printer Overview

Boost productivity and print anywhere with drop-resistant mobile printers that offer high-quality printing, easy integration, proactive alerts and convenient charging.

Detailed Specs

Full specifications (PDF)

Technical Information

Recommended Use:

Label Print

Print Color Capability:

Monochrome

Maximum Mono Print Speed:

4 in/s

Maximum Print Resolution (dpi):

203

Maximum Print Width:

2.90"

Barcode Symbology Supported:

Code 39
Code 93
UCC/EAN 128
Code 128
Codabar
Interleaved 2 of 5
UPC-A
UPC-E
EAN-13
EAN-8
PDF-417
Micro PDF-417
Maxi Code
QR Code
RSS
GS1 DataBar
Aztec Code
Data Matrix
TLC 39
FIM
POSTNET
Plessey

Peel Facility:

Yes

Real Time Clock:

Yes

Application/Usage:

Mobile

Features:

Belt Clip
Tear Bar
Mirror Printing
Label Odometer
Vertical Printing
Horizontal Printing
Dust Resistant
Water Resistant
Hand Strap
Shoulder Strap

Memory

Standard Memory:

128 MB

Flash Memory:

256 MB

Interfaces/Ports

Serial Port:

Yes

USB:

Yes

Network & Communication

Ethernet:

Yes

Ethernet Technology:

Fast Ethernet

Bluetooth:

Yes

Display & Graphics

Display Screen:

Yes

Display Screen Type:

LCD

Media Types & Handling

Media Type:

Linerless
Black Mark
Gap
Roll Fed
Direct Thermal Label
Label

Media Sensor:

Transmissive Media Sensor
Label Taken Sensor
Reflective Media Sensor

Media Thickness:

6.50 mil

Maximum Roll Diameter:

2.60"

Maximum Label Width:

3.10"

Maximum Label Length:

32"

Label Core Size:

0.75"

Fonts & Emulation

Language Emulation:

CPCL
ZPL
XML

Power Description

Power Source:

Battery

Input Voltage:

7.4 V DC

Battery Information

Battery Chemistry:

Lithium Ion (Li-Ion)

Battery Included:

Yes

Battery Rechargeable:

Yes

Physical Characteristics

Form Factor:

Portable

Height:

3.3"

Width:

4.6"

Depth:

6.8"

Weight (Approximate):

1.60 lb

Miscellaneous

Package Contents:

QLn320 Mobile Printer
Software & Drivers CD
Battery

Platform Supported:

Certifications & Standards:

IP54
FCC Part 15, Subpart B
EN55022 Class-B
EN60950
EN55024
VCCI class B
EN55024
EN61000-4-2
EN61000-4-3
EN61000-4-4
EN61000-4-5
CE
UL
TUV
CSA
IP43
IP54
Unicode
UTF-16

Environmentally Friendly:

Yes

Environmental Certification:

RoHS

Warranty

Limited Warranty:

1 Year

Item Numbers

UNSPSC: 45101512

Reviews

Q&A

Accessories

Service Contracts

Questions? Get help from a
Printer Expert!

The Zebra QN3-AUCA0E00-00 Portable Barcode Printer is also known as ZEB-QN3AUCA0E0000 or QN3-AUCA0E00-00.
