Zebra QN3-AUBA0E00-00 Portable Barcode Printer

Part Number: QN3-AUBA0E00-00
Model: QLn320
Add to My Shopping List Add to Compare
Discontinued See Replacement

Price Match Guarantee - We'll match any authorized retailer's price

Quantity:

Product Highlights

View All
Printer Type
Mobile
Printing Technology
Direct Thermal
Interface Options
Bluetooth, Ethernet, USB
Print Resolution
203 dpi

Product Description:

  QLn320, 3 INCH, USB, ETHERNET, BLUETOOTH, 128MB/256MB, CPCL, LCD, DT, LINERED PLATEN, 3/4 INCH MEDIA CORE SIZE. Power supply (Part# P1031365-063) not included, see accessories.
Explore all Zebra QLn320 Portable Barcode Printers
Add to Quote
Zebra QN3-AUBA0E00-00 Portable Barcode Printer
Zebra QN3-AUBA0E00-00 Portable Barcode Printer
Zebra QN3-AUBA0E00-00 Portable Barcode Printer
Zebra QN3-AUBA0E00-00 Portable Barcode Printer
Zebra QN3-AUBA0E00-00 Portable Barcode Printer
Zebra QN3-AUBA0E00-00 Portable Barcode Printer
Zebra QN3-AUBA0E00-00 Portable Barcode Printer Zebra QN3-AUBA0E00-00 Portable Barcode Printer Zebra QN3-AUBA0E00-00 Portable Barcode Printer Zebra QN3-AUBA0E00-00 Portable Barcode Printer Zebra QN3-AUBA0E00-00 Portable Barcode Printer

Full specifications (PDF)

Zebra QLn320 Portable Barcode Printer Model Overview

Boost productivity and print anywhere with drop-resistant mobile printers that offer high-quality printing, easy integration, proactive alerts and convenient charging. Trust these mobile printers to improve efficiencies throughout operations–in the warehouse, shipping and receiving and merchandising. Quickly and easily print barcode labels, receipts, tickets and more, on-site and on-demand.
Zebra QN3-AUBA0E00-00 Portable Barcode Printer Overview

Boost productivity and print anywhere with drop-resistant mobile printers that offer high-quality printing, easy integration, proactive alerts and convenient charging.

Full specifications (PDF)
Technical Information
Recommended Use:
Label Print
Print Color Capability:
Monochrome
Maximum Mono Print Speed:
4 in/s
Maximum Print Resolution (dpi):
203
Maximum Print Width:
2.90"
Barcode Symbology Supported:
  • Code 39
  • Code 93
  • UCC/EAN 128
  • Code 128
  • Codabar
  • Interleaved 2 of 5
  • UPC-A
  • UPC-E
  • EAN-13
  • EAN-8
  • PDF-417
  • Micro PDF-417
  • Maxi Code
  • QR Code
  • RSS
  • GS1 DataBar
  • Aztec Code
  • Data Matrix
  • TLC 39
  • FIM
  • POSTNET
  • Plessey
Peel Facility:
Yes
Real Time Clock:
Yes
Application/Usage:
Mobile
Features:
  • Belt Clip
  • Tear Bar
  • Mirror Printing
  • Label Odometer
  • Vertical Printing
  • Horizontal Printing
  • Dust Resistant
  • Water Resistant
  • Hand Strap
  • Shoulder Strap
Memory
Standard Memory:
128 MB
Flash Memory:
256 MB
Interfaces/Ports
Serial Port:
Yes
USB:
Yes
Network & Communication
Ethernet:
Yes
Ethernet Technology:
Fast Ethernet
Bluetooth:
Yes
Display & Graphics
Display Screen:
Yes
Display Screen Type:
LCD
Media Types & Handling
Media Type:
  • Linered Media
  • Black Mark
  • Gap
  • Roll Fed
  • Direct Thermal Label
  • Label
Media Sensor:
  • Transmissive Media Sensor
  • Label Taken Sensor
  • Reflective Media Sensor
Media Thickness:
6.50 mil
Maximum Roll Diameter:
2.60"
Maximum Label Width:
3.10"
Maximum Label Length:
32"
Label Core Size:
0.75"
Fonts & Emulation
Language Emulation:
  • CPCL
  • ZPL
  • XML
Power Description
Power Source:
Battery
Input Voltage:
7.4 V DC
Battery Information
Battery Chemistry:
Lithium Ion (Li-Ion)
Battery Included:
Yes
Battery Rechargeable:
Yes
Physical Characteristics
Form Factor:
Portable
Height:
3.3"
Width:
4.6"
Depth:
6.8"
Weight (Approximate):
1.60 lb
Miscellaneous
Package Contents:
  • QLn320 Mobile Printer
  • Software & Drivers CD
  • Battery
Platform Supported:
PC
Certifications & Standards:
  • IP54
  • FCC Part 15, Subpart B
  • EN55022 Class-B
  • EN60950
  • EN55024
  • VCCI class B
  • EN55024
  • EN61000-4-2
  • EN61000-4-3
  • EN61000-4-4
  • EN61000-4-5
  • CE
  • UL
  • TUV
  • CSA
  • IP43
  • IP54
  • Unicode
  • UTF-16
Environmentally Friendly:
Yes
Environmental Certification:
RoHS
Warranty
Limited Warranty:
1 Year
Item Numbers
GTIN: 0777786357603, 0853585466828
UPC: 777786357603, 853585466828
EAN: 0777786357603, 0853585466828
UNSPSC: 45101512
