Zebra Q4B-LUCAV000-Z0 Portable Barcode Printer

Part Number: Q4B-LUCAV000-Z0
Model: QL 420
Add to My Shopping List Add to Compare
Discontinued Need Assistance?

Price Match Guarantee - We'll match any authorized retailer's price

Quantity:

Product Highlights

Printer Type
Mobile
Printing Technology
Direct Thermal
Interface Options
Wi-Fi
Print Resolution
203 dpi

Product Description:

  Direct thermal, linered platen, 203 dpi, 4" print width, 2MB SRAM, 2MB Flash, LCD, 802.11b-Cisco 352 PCMCIA-NA, VAR and ZPL. Includes battery, belt clip & user's manual. Order battery charger & cables separately. See accessories. Power supply (Part# CC16614-G4) not included, see accessories.
Explore all Zebra QL 420 Portable Barcode Printers
Add to Quote
Zebra Q4B-LUCAV000-Z0 Portable Barcode Printer
Zebra Q4B-LUCAV000-Z0 Portable Barcode Printer
Zebra Q4B-LUCAV000-Z0 Portable Barcode Printer
Zebra Q4B-LUCAV000-Z0 Portable Barcode Printer Zebra Q4B-LUCAV000-Z0 Portable Barcode Printer

Full specifications (PDF)

Zebra QL 420 Portable Barcode Printer Model Overview

The QL 420 direct thermal mobile printer has been designed with the most advanced technology in rubberized over-molding to maintain both rugged construction and minimal weight. With center-loading media, smart battery monitoring and an optional LCD, it provides user-friendly options to keep your business moving. All units ship with one user's manual.
Zebra Q4B-LUCAV000-Z0 Portable Barcode Printer Overview

The QL 420 direct thermal mobile printer has been designed with the most advanced technology in rubberized overmolding to maintain both rugged construction and minimal weight. With center-loading media, smart battery monitoring, it provides user-friendly options to keep your business moving.

Full specifications (PDF)
Technical Information
Recommended Use:
Label Print
Maximum Mono Print Speed:
3 in/s
Maximum Print Resolution (dpi):
203
Maximum Print Width:
4.09"
Barcode Symbology Supported:
  • Codabar
  • Code 128
  • Code 93
  • Code 39
  • EAN-13
  • EAN-8
  • Interleaved 2 of 5
  • MSI
  • Plessey
  • POSTNET
  • UCC/EAN 128
  • UPC-A
  • UPC-E
  • EAN-18
  • FIM
  • Maxi Code
  • PDF-417
Application/Usage:
Mobile
Features:
  • LCD Display
  • Belt Clip
Print Technology:
Direct Thermal /Thermal Transfer
Memory
Standard Memory:
2 MB
Flash Memory:
2 MB
Network & Communication
Wireless LAN:
Yes
Display & Graphics
Display Screen:
Yes
Display Screen Type:
LCD
Media Types & Handling
Media Type:
  • Roll Fed
  • Die-cut Label
  • Linerless
  • Receipt
  • Fanfold
Media Sensor:
  • Transmissive Media Sensor
  • Reflective Media Sensor
Media Thickness:
6.50 mil
Maximum Roll Diameter:
2.60"
Maximum Label Width:
4.12"
Maximum Label Length:
20"
Label Core Size:
8"
Fonts & Emulation
Language Emulation:
ZPL
Battery Information
Battery Chemistry:
Lithium Ion (Li-Ion)
Battery Included:
Yes
Battery Capacity:
4200 mAh
Physical Characteristics
Form Factor:
Portable
Height:
7.5"
Width:
6"
Depth:
3"
Miscellaneous
Package Contents:
  • QL 420 Mobile Label Printer
  • Lithium ion battery
Additional Information:
  • Media Handling: Direct Thermal/ Linered Platen
  • Reflective & Transmissive sensor
  • Ancillary Items: VAR (adds UMAN/accessories cd)
  • QuickLink module: 802.11b (Cisco 352 PCMCIA) North America
  • Character Set: US/Canadian English/Latin 1 & 5 (Including Turkish)
Platform Supported:
PC
Certifications & Standards:
  • FCC Class B
  • CE Class B
  • CSA
  • CB
  • NOM
  • C-Tick
Warranty
Limited Warranty:
1 Year
Item Numbers
UNSPSC: 43212108
