Zebra Q3D-LU1A0000-02 Portable Barcode Printer

Zebra QL320 Plus Portable Barcode Printer Model Overview

The updated QL320 Plus direct thermal mobile printer has been designed with the most advanced technology in rubberized over-molding to maintain both rugged construction and minimal weight. With center-loading media, smart battery monitoring and an optional LCD, it provides user-friendly options to keep your business moving. All units ship with one user's manual.

Zebra Q3D-LU1A0000-02 Portable Barcode Printer Overview

Mobile printers well-suited for applications ranging from pallet labeling, product identification, and work-in-process tickets, to price marking, shelf labeling and more.

Detailed Specs

Full specifications (PDF)

Technical Information

Recommended Use:

Label Print

Print Color Capability:

Monochrome

Maximum Mono Print Speed:

4 in/s

Maximum Print Resolution (dpi):

203

Maximum Print Width:

2.90"

Barcode Symbology Supported:

Codabar
Code 128
Code 39
Code 93
EAN-13
EAN-8
Interleaved 2 of 5
MSI
Plessey
PostBar
UCC/EAN 128
UPC-A
UPC-E
EAN-18
FIM
Maxi Code
PDF-417
Aztec Code
Data Matrix
QR Code
RSS
GS1 DataBar

Peel Facility:

Yes

Application/Usage:

Mobile

Features:

Belt Clip
Water Resistant
Low Battery Indicator
Repeat Printing

Print Technology:

Direct Thermal

Memory

Standard Memory:

16 MB

Flash Memory:

8 MB

Interfaces/Ports

USB:

Yes

Display & Graphics

Display Screen:

Yes

Display Screen Type:

LCD

Media Types & Handling

Media Type:

Direct Thermal Label
Linered Media
Black Bar
Black Mark
Die-cut Label
Receipt
Roll Fed

Media Thickness:

6.50 mil

Maximum Roll Diameter:

2.63"

Maximum Label Width:

3.12"

Label Core Size:

1.38"

Fonts & Emulation

Language Emulation:

CPCL
EPL
XML
ZPL
EPL2

Power Description

Power Source:

Battery

Input Voltage:

7.4 V DC

Battery Information

Battery Chemistry:

Lithium Ion (Li-Ion)

Battery Included:

Yes

Battery Rechargeable:

Yes

Physical Characteristics

Form Factor:

Portable

Color Family:

Gray

Product Color:

Gray

Height:

8"

Width:

4.6"

Depth:

3.1"

Weight (Approximate):

1.65 lb

Miscellaneous

Package Contents:

QL 320 Plus Mobile Label Printer
Battery
Belt Clip

Platform Supported:

PC

Certifications & Standards:

IP14
IP54
FCC
CE Class B
CSA
CB Scheme
NOM
C-Tick

Warranty

Limited Warranty:

1 Year

Item Numbers

GTIN: 0808736408882

UPC: 808736408882

EAN: 0808736408882

UNSPSC: 45101512
