The Zebra MiniScan MS954 Series is a compact and durable fixed-mount laser barcode scanner designed for high-performance linear scanning of 1-D barcodes, even those that are poorly printed or low contrast. This versatile scanner features a configurable scan angle of 47° and 35°, allowing it to fit various OEM device applications. Its lightweight design makes it ideal for automated data collection where space is limited, while also functioning as a standalone scanner. With millions of installations worldwide, the MS954 ensures reliable and quick data capture for mission-critical projects, helping businesses enhance their productivity and streamline operations.
Key features:
High performance fixed-mount scanner for maximum accuracy and productivity
Configurable scan angle of 47° and 35° for flexible application needs
Working range from near contact to over 35 in./88.9 cm
Plug-and-play installation reduces development time and speeds up time to market
Durable housing with built-in RS-232 interface for easy integration
Specifications:
Light Source: Visible laser diode 650 nm
Dimensions: 1.02H x 1.93W x 2.31D inches (25.9H x 49.02W x 58.67D mm)
Weight: 1.67 oz. (47.34 g)
Scan Rate: 104 12 scans per second
Scan Pattern: Linear
Operating Temperature: -4°F to 140°F (-20°C to 60°C)
Storage Temperature: -40°F to 158°F (-40°C to 70°C)
Humidity: 5% to 95% non-condensing
Power: Input voltage 5 VDC ± 10%
Drop Rating: Functions normally after multiple 30 in. drops to concrete
Zebra MS-954-I000R Fixed Barcode Scanner Overview
The Symbol MiniScan 954 Bar Code Reader is a compact, durable, fixed-mount laser Bar Code Reader for premium linear scanning on all types of 1D bar codes, including poorly printed and low contrast symbols.
Cables, Connectors, and Adapters, Zebra, Push Button Trigger Cable, In Order For This Cable To Work You Must Purchase A Cable That Has A Trigger Jack Attachment.
Cables, Connectors, and Adapters, Zebra, RS232 Cable Assembly, 9-Pin Female Straight Host Connector With Trigger Jack, 6' Straight Cable, To Be Used With General Purpose Fixed Mount Scanners
Cables, Connectors, and Adapters, Zebra, RS232 Cable Assembly, 9-Pin Female Straight Host Connector With Trigger Jack And Beeper, 6' Straight Cable, To Be Used With General Purpose Fixed Mount Scanners
Power Device, Zebra, Level Vi AC/DC Power Supply Wall Adapter, With Captive DC Cable And US Adapter Clip AC Input, 100-240V, 0.2A DC Output, 5.2V, 1.1A, 5.7W
Power Systems & Supplies, Zebra, Level VI AC/DC Power Supply (Wall Adapter, with Captive DC Cable and Eu, Uk Adapter Clip). AC Input: 100-240V, 0.2A. DC Output: 5.2V, 1.1A, 5.7W
Item on backorder — chat for lead time
$40.55
Top Scanner Accessories Purchased With Zebra MS-954-I000R
What types of barcodes can the Zebra MS954 scanner read?
The MS954 is a 1D laser barcode scanner capable of reading all types of linear barcodes, including poorly printed and low contrast symbols. This versatile decode capability ensures high first-time read rates across standard barcode formats used in warehousing and logistics operations. We offer the MS954 for applications requiring reliable general-purpose barcode scanning.
Is the Zebra MS954 suitable for fixed-mount installation?
Yes, the MS954 is specifically designed as a compact, durable fixed-mount laser scanner ideal for OEM device integration. Its configurable scan angle provides flexible, expanded working range capabilities for installations where the scanner position is permanent. Contact us today to discuss fixed-mount barcode scanning solutions for your facility.
What connectivity options does the MS954 barcode scanner provide?
The MS954-I000R model features RS-232 serial connectivity for reliable data transmission to your host systems. This standard serial interface is widely compatible with warehouse management systems and legacy equipment commonly found in logistics environments. We offer complete integration support when you purchase from us.
How does the Zebra MS954 perform in challenging barcode conditions?
The MS954 is engineered to handle poorly printed and low contrast barcodes that would challenge standard scanners, making it ideal for warehouse environments with varying label quality. Its Class 2 standard laser technology delivers consistent performance across demanding scanning scenarios. Visit barcodesinc.com to learn more about our premium fixed-mount scanning solutions.
What is the laser classification and safety rating of the MS954?
The MS954 is classified as a Class 2 laser scanner with standard laser SL (Safe Laser) technology, meeting safety standards for workplace use. This classification indicates the scanner is safe for typical warehouse and distribution center environments when used according to manufacturer guidelines. We ensure all products available from us meet required safety certifications.
Can the MS954 be configured for different scanning angles?
Yes, the MS954 features a configurable scan angle that allows flexibility for OEM devices requiring expanded working range and varied mounting positions. This adaptability makes it suitable for different conveyor heights, shelf configurations, and automated system designs. Contact us today for technical specifications and configuration assistance for your specific application.
The Zebra MS-954-I000R Fixed Barcode Scanner is also known as
SYM-MS954I000R
or MS-954-I000R.
Full specifications (PDF)
