Zebra – Barcode Scanner

Part Number: LS7808-SR22009SCR
Model: Parts and Accessories
Add to My Shopping List Add to Compare
Discontinued Need Assistance?

Price Match Guarantee - We'll match any authorized retailer's price

Quantity:

Product Highlights

View All
Connectivity Technology
Cable
Barcode Symbology Supported
UPC-AUPC-EUPC EIEAN-13EAN-8JAN-8JAN-13UPC/EAN with supplementalsCode 39Code 39 Full ASCIIInterleaved 2 of 5Discrete 2 of 5Code 128UCC/EAN 128ISBT 128Code 93Code 11Codabar (NW7)RSS Variants
Light Source
Laser
Maximum Scan Resolution
5 mil

Product Description:

  LS7808 Horizontal Slot Scanner, Stainless Steel/Twilight Black Bezel, Sapphire Glass, EAS antenna, RSM Ready Out-of-the Box, Quick Reference Guide.
Explore all Zebra Parts Accessories
Add to Quote
Zebra LS7808-SR22009SCR Barcode Scanner
Zebra LS7808-SR22009SCR Barcode Scanner
Zebra LS7808-SR22009SCR Barcode Scanner Zebra LS7808-SR22009SCR Barcode Scanner

Zebra Parts Accessory Model Overview

Products and parts from Zebra.
Zebra LS7808-SR22009SCR Barcode Scanner Overview

The advanced Symbol LS7808 horizontal slot scanner from Motorola delivers exceptionally high first-pass read rates for faster checkout times and better customer service. The Symbol LS7808 represents the latest development in our three decade leadership in designing Bar Code Reader and our pioneering work in horizontal slot scanner technologies. The omni-directional scan pattern reads the bar code regardless of orientation, eliminating the need to precisely align products to the scanner. Advanced software algorithms reconstruct poorly printed and damaged codes, further increasing performance and speeding customers through the point of sale. For added reliability in more demanding environments, Motorola offers a scratchproof, sapphire glass/ stainless steel option.

Technical Information
Connectivity Technology:
Cable
Barcode Symbology Supported:
  • UPC-A
  • UPC-E
  • UPC EI
  • EAN-13
  • EAN-8
  • JAN-8
  • JAN-13
  • UPC/EAN with supplementals
  • Code 39
  • Code 39 Full ASCII
  • Interleaved 2 of 5
  • Discrete 2 of 5
  • Code 128
  • UCC/EAN 128
  • ISBT 128
  • Code 93
  • Code 11
  • Codabar (NW7)
  • RSS Variants
Light Source:
Laser
Maximum Scan Resolution:
5 mil
Depth of Field:
  • 0" - 6"@100% UPC/EAN
Scan Pattern:
Omni-directional
Interfaces/Ports
Host Interface:
Multi-interface
Power Description
Input Voltage:
5 V DC
Physical Characteristics
Form Factor:
In-counter
Height:
3.1"
Width:
6"
Depth:
6"
Weight (Approximate):
1.90 lb
Miscellaneous
Package Contents:
  • Symbol LS808 Bar Code Reader
  • EAS antenna
  • Quick Reference Guide
Additional Information:

Supported Interfaces:

  • Serial
  • IBM 468X/469X
  • Keyboard Wedge
  • USB

    • Certifications & Standards:

    Electrical Safety:

    • UL 60950-1
    • CSA C22.2 No. 60950-1
    • EN 60950-1
    • IEC 60950-1

    Laser Safety:

    • 21CFR1040.10 Class IIa
    • EN 60825-1
    • IEC60825-1 Class1

    EMI/RFI:

    • FCC Part 15 Class B
    • ICES-003 Class B
    • EN 55022 Class B
    • EN 55024

    Environmental:

    • RoHS
    • 2005 Sunrise
    • WEEE
    Environmentally Friendly:
    Yes
    Warranty
    Limited Warranty:
    3 Year
    Item Numbers
    UNSPSC: 43211701
    Get help from a Barcoding Expert!

    What type of Barcode are you scanning?

    The Zebra LS7808-SR22009SCR Barcode Scanner is also known as SYM-LS7808SR22009SCR
