Connectivity Technology:
Cable
Scanning Capability:
- 1D
- 2D
Barcode Symbology Supported:
1D:
- UPC/EAN (UPCA/UPCE/UPCE1/EAN-8/EAN-13/JAN-8/JAN-13 plus supplementals,
- ISBN (Bookland), ISSN, Coupon Code)
- Code 39 (Standard, Full ASCII, Trioptic)
- Code 128 (Standard, UCC/EAN-128, ISBT-128 Concatenated)
- Code 93
- Codabar/NW7
- Code 11 (Standard, Matrix 2 of 5)
- MSI Plessey
- I 2 of 5 (Interleaved 2 of 5 / ITF, Discrete 2 of 5, IATA, Chinese 2 of 5)
- GS1 DataBar (Omnidirectional, Truncated, Stacked, Stacked Omnidirectional, Limited, Expanded, Expanded Stacked, Inverse)
- Base 32 (Italian Pharmacode)
- PDF417 (Standard, Macro),
- MicroPDF417 (Standard,
- Composite Codes (CC-A, CC-B, CC-C)
- TLC-39
- Aztec (Standard, Inverse)
- MaxiCode
- DataMatrix/ECC 200 (Standard, Inverse)
- QR Code (Standard, Inverse, Micro)
- U.S. Postnet and Planet
- U.K. Post
- Japan Post
- Australian Post
- Netherlands KIX Code
- Royal Mail 4 State Customer
- UPU FICS 4 State Postal
- USPS 4CB
- Canadian Post (Postbar)
Image Sensor Type:
Imager
Scanner Range:
Standard Range
Field of View (Horizontal):
39°
Field of View (Vertical):
25°
Reading Angle (Pitch):
65°
Reading Angle (Roll):
360°
Image Formats:
- JPEG
- BMP
- TIFF
Drop Specification:
Withstands multiple 5 ft./1.5 m drops to concrete
Minimum Element Resolution (Code 39):
0 mil
Maximum Element Resolution (Code 39):
4.5 mil
