Connectivity Technology:
Cable
Scanning Capability:
- 1D
- 2D
Barcode Symbology Supported:
1D :
- Code 39
- Code 128
- Code 93
- Codabar/NW7
- Code 11
- MSI Plessey
- UPC/EAN
- I 2 sur 5
- Coréen 3 sur 5
- GS1 DataBar
- Base 32 (Pharmacie italienne)
- PDF417
- Micro PDF417
- Codes composites
- TLC-39
- Aztèque
- DataMatrix
- MaxiCode
- Code QR
- Micro QR
- Han Xin
- Codes postaux
- securPharm
- DotCode
- Doted DataMatrix
- OCR-A
- OCR-B
- MICR
- US devise
Light Source:
LED
Image Sensor Type:
Imager
Scan Mode:
Trigger
Scan Pattern:
Area
Scanner Range:
Standard Range
Scanning Distance:
10.98"
Features:
- Checkpoint EAS
- Beep
- Notification LED
Cable Type Included:
USB
Field of View (Horizontal):
52°
Field of View (Vertical):
33°
Reading Angle (Skew):
60°
Reading Angle (Pitch):
60°
Reading Angle (Roll):
360°
Image Formats:
- BMP
- JPEG
- TIFF
Maximum Ambient Light:
107700 lux
Drop Specification:
- Designed to withstand multiple drops at 5.0 ft. / 1.5 m to concrete
Minimum Print Contrast:
15%
Minimum Element Resolution (Code 39):
3 mil
Maximum Element Resolution (Code 39):
20 mil
Minimum Element Resolution (DataMatrix):
10 mil
Minimum Element Resolution (PDF417):
6.7 mil
Image Sensor Resolution:
1280 x 800
Illumination Type:
LED
Illumination Color:
Red
Air Electrostatic Discharge (+/-):
15kV
