The DS8100 Series Handheld Imagers by Zebra integrate cutting-edge technology for unparalleled barcode scanning performance, enhancing the checkout experience in retail, hospitality, and logistics environments. With the power of an 800 MHz microprocessor and innovative PRZM Intelligent Imaging technology, these imagers can accurately read 1D and 2D barcodes in any condition, significantly reducing customer wait times. The DS8100 supports swappable power sources, providing flexibility and efficiency, while advanced manageability tools ensure optimal operational uptime, making it the ultimate choice for businesses prioritizing productivity and customer satisfaction.
Key Features
Unprecedented Scanning Performance: Captures difficult barcodes effortlessly, ensuring fast and accurate scans.
Swappable Power Options: Choose between PowerPrecision+ battery and PowerCap capacitor for operational flexibility.
Multi-code Data Formatting: Capture multiple barcodes in one scan, streamlining workflows.
DigimarcⓇ Support: Enhances checkout speed with virtually invisible barcodes.
Easy Manageability: Control devices remotely and gain insights through ScanSpeed Analytics.
Specifications
Physical Characteristics:
Dimensions: 6.6 in. H x 2.6 in. W x 4.2 in. D
Weight: Corded - 5.4 oz., Cordless - 8.3 oz.
Battery:
PowerPrecision+ Li-Ion: 2500 mAh
PowerCap Capacitor: 440 F
Operating Environment:
Temperature: 32° to 122° F / 0° to 50° C
Humidity: 5% to 95% RH, non-condensing
Performance Specifications:
Scanning Range: Up to 24 in. / 61 cm
Decode Capabilities: 1D, 2D, and Digimarc supported
Zebra DS8178-DL0F007ZZWW Barcode Scanner Overview
THE ULTIMATE IN PERFORMANCE, INNOVATION AND MANAGEABILITY
The checkout stand is the last chance you have to leave shoppers with a good impression. The quality of the checkout experience is heavily dependent upon the performance of the scanner you choose. Now, you can leave every shopper with the ultimate last impression with the DS8100 Series handheld imager.
The DS8100 Series rises above conventional imagers to deliver unprecedented scanning performance on virtually every 1D and 2D barcode, keeping your checkout lines moving and your cashiers free to deliver a more personal checkout experience. The DS8100 Series - because when it comes to the checkout experience in your store, only the best will do.
Power Device, Zebra, Level Vi Efficiency AC/DC Power Supply Brick Used To Power Single-Slot Cradle Or Four-Slot Battery Charger, DC Cable (CBL-DC-388A1-01) And Country-Specific AC Line Cord Are All Sold Separately.
Power Device, Zebra, DC Line Cord Allowing Connection Of PWRBGA12V50W0WW Level Vi Power Supply To All Data Capture System Products And SAC3600-4001Cr Except DS36XX/LI36XX
What barcode types can the Zebra DS8178 scanner read?
The Zebra DS8178 is a 1D/2D area imager that delivers scanning performance on virtually every 1D and 2D barcode in any condition. It's designed as a general-purpose scanner capable of reading both traditional linear barcodes and 2D formats like QR codes, making it ideal for retail, warehouse, and logistics applications.
How long does the battery last on the Zebra DS8178?
The DS8178 can scan continuously for over 24 hours with Zebra's PowerPrecision+ smart battery. Alternatively, you can use the interchangeable Zebra PowerCap supercapacitor, which requires as little as a 35-second charge. The PowerPrecision+ battery includes a self-reporting feature that warns you when the battery is near the end of its life so you can order a replacement before it fails.
Is the Zebra DS8178 a cordless or corded scanner?
The Zebra DS8178 is a cordless handheld scanner with Bluetooth connectivity, designed to keep checkout lines moving and allow cashiers to deliver a more personal checkout experience. Its wireless design eliminates cable constraints while maintaining reliable connectivity across your enterprise.
Does the DS8178 support driver's license parsing?
Yes, the Zebra DS8178-DL0F007ZZWW model includes driver's license (DL) parsing capability, which allows it to capture and parse data from driver's licenses and other ID documents. This makes it suitable for applications requiring identity verification and age-gated transactions.
What industries and applications is the Zebra DS8178 designed for?
The DS8178 is built for diverse industries including retail point-of-sale and inventory management, hospitality check-in and ticketing, transportation and logistics shipping/receiving and product tracking, light manufacturing component tracking, and government applications. Its versatile area imager technology and cordless design make it adaptable to warehouse operations, backroom receiving, and picking applications.
What software tools are included with the Zebra DS8178?
The Zebra DS8178 comes with complimentary industry-preferred software tools designed for easy deployment and management across your entire enterprise. These tools help streamline scanner configuration and integration into your existing systems. Contact us today to learn more about available software solutions and how we can help optimize your barcode scanning infrastructure.
The Zebra DS8178-DL0F007ZZWW Barcode Scanner is also known as
ZEB-DS8178DL0F007Z01
or DS8178DL0F007ZZWW.
