The DS3600-XR Ultra-Rugged Scanner redefines scanning capabilities with its unrivaled performance and extended range. Engineered for the toughest environments, this scanner captures barcodes from as close as 2 inches to over 105 feet, making it a versatile solution for warehouses and manufacturing settings. With a high visibility green laser aimer that enhances accuracy, the DS3600-XR offers exceptional durability under challenging conditions. It's perfect for rapidly proliferating 2D and traditional 1D barcodes, supporting efficient inventory management and operational workflows with ease.
Key Features
Unmatched Scanning Range: Captures barcodes from 2 in. to over 105 ft.
High Visibility Aimer: 7x more visible green laser for easy targeting.
Ultra-Rugged Design: Survives drops from 10 ft. and is IP65/IP68 rated.
Long Battery Life: Over 80,000 scans on a single charge.
Multi-Code Data Formatting: Captures multiple barcodes in one scan.
Specifications
Dimensions: 7.3 in. H x 3.0 in. W x 5.2 in. D (Corded)
Weight: 10.86 oz. (Corded)
Input Voltage: 4.5 VDC min., 5.5 VDC max.
Operating Temp: Corded: -22°F to 122°F, Cordless: -4°F to 122°F
Docks and Cradles, Zebra, Sealed Forklift Cradle For 3678 Family, Charger, Bluetooth And Multi Interface, IP65 Sealed, Forklift' Mounting Bracket BrKT-mm0036W-00 Ordered Separately
Zebra EA3600, 3600 Series Ethernet Adapter, STD TCP/IP, 24 VDC, RJ45, Compatible With 3600 Series, Power Source Required. Customer To Supply 24 VDC Source Or Order Zebra Power Supply PWR-BGA12V50W0WW & Line Cords CBL-DC-388A1-01 & 23844-00-00R
Item on backorder — chat for lead time
$1,173.98
Top Mounting Hardware and Stands Purchased With Zebra DS3608-XR60003VTNA
What is the maximum scanning range of the Zebra DS3608-XR barcode scanner?
The Zebra DS3608-XR delivers industry-leading extended range performance, capable of scanning barcodes from as close as 2 inches (5 cm) to over 105 feet (32 meters). This represents more than 25% greater range than competing scanners in its class, making it ideal for warehouse and logistics operations where distance scanning is critical.
Is the Zebra DS3608-XR rugged enough for warehouse drop tests?
Yes, the DS3608-XR is built ultra-rugged and withstands drops of up to 10 feet (3 meters) onto concrete, plus 7,500 tumbles during its lifecycle. It also features dual IP65/IP68 sealing for protection against extreme temperatures and environmental hazards, making it suitable for demanding warehouse and outdoor logistics environments.
What barcode types can the Zebra DS3608-XR scan?
The DS3608-XR captures both 1D and 2D barcodes with equal proficiency, including commonly used 2D formats which it scans nearly 40% farther than competing devices. This versatility makes it compatible with traditional barcode systems as well as modern 2D implementations across supply chain operations.
How does the green laser aimer improve scanning accuracy?
The DS3608-XR features a high visibility green laser aimer that is up to 7 times more visible than standard red lasers, facilitating precise scanning in varying lighting conditions—both indoors and outdoors. This enhanced aimer visibility reduces scanning errors and improves worker productivity across different warehouse environments.
What technology platform powers the Zebra DS3608-XR?
The DS3608-XR is equipped with Zebra's DataCapture DNA technology platform, which provides intelligent firmware, software, utilities, and apps for enhanced productivity and efficiency in industrial environments. This integrated approach goes beyond basic scanning to deliver comprehensive data capture solutions for enterprise operations.
How much lighter is the DS3608-XR compared to previous Zebra extended range models?
The DS3608-XR maintains the proven ruggedness of the DS3600-ER while decreasing device weight by 10%, making it more comfortable for workers during extended use. This weight reduction, combined with its 40% increase in scanning range and enhanced aimer visibility, delivers superior ergonomics without sacrificing durability.
The Zebra DS3608-XR60003VTNA Barcode Scanner is also known as
ZEB-DS3608XR60003VTNA
or DS3608XR60003VTNA.
Full specifications (PDF)
