Zebra 284Z-10400-0001 Barcode Label Printer

Zebra GX42-102410-000 Barcode Label Printer A newer version of this item is available.
It is replaced by the Zebra GX42-102410-000 Barcode Label Printer.
Zebra TLP 2844-Z - Thermal transfer & direct thermal, 203 dpi, 4 ips, 4" print width, serial, USB, & ZebraNet PrintServer II interfaces, 8MB SDRAM, 4MB flash and ZPL. Includes U.S. power supply. Order cables separately. See accessories.
Printer Type
Desktop
Printing Technology
Thermal Transfer
Interface Options
Ethernet, Serial (RS-232), USB
Print Resolution
203 dpi
Max Print Width
4.25 inch
Ribbon Core Size
0.5 inch
  • A smart choice for carrying out high volume label printing in multiple areas with reduced cost of ownership
  • 203 x 203 maximum print resolution (dpi) for your convenience and easy usage
  • Produce high-quality documents with this monochrome printer to increase your productivity
  • Enjoy maximum efficiency with label print printing
  • 4.25" maximum label width for your convenience and feasible usability
  • 11" maximum label length for your convenience and feasible usability
  • Supports label media type for dependable, efficient results with maximum productivity
  • Comes with 256 KB standard memory for timely printing with added reliability
Read More

Need a different version? See all Zebra TLP 2844-Z Barcode Label Printers

Discontinued See Replacement
Add to Quote
Add to My Shopping List Add to Compare
Zebra 284Z-10400-0001 Barcode Label Printer
Zebra 284Z-10400-0001 Barcode Label Printer Zebra 284Z-10400-0001 Barcode Label Printer Zebra 284Z-10400-0001 Barcode Label Printer Zebra 284Z-10400-0001 Barcode Label Printer
Zebra 284Z-10400-0001 Barcode Label Printer
Zebra 284Z-10400-0001 Barcode Label Printer
Zebra 284Z-10400-0001 Barcode Label Printer

Full specifications (PDF)
Zebra TLP 2844-Z Barcode Label Printer Model Overview
The dynamic Zebra TLP 2844-Z features a powerful combination of proven Zebra attributes. The Zebra TLP 2844-Z offers the best in-class integration capabilities of any desktop thermal label printer in the industry. This new ZPL based model comes standard with triple communications interfaces - serial, parallel & USB. The optional internal ZebraNet PrintServer II interface provides quick and easy integration into Ethernet networks and enables the printer to unlock the power of ZebraLink .
Zebra 284Z-10400-0001 Barcode Label Printer Overview

Leading the way in versatile and affordable desktop printing - The thermal transfer TLP 2844 bar code printer brings a new level of performance to the Zebra desktop family. This space-saving, user-friendly printer delivers optimal performance in today's on-demand desktop labeling applications. The TLP 2844 is loaded with impressive features and a small price tag!

Full specifications (PDF)
Technical Information
Recommended Use:
Label Print
Print Color Capability:
Monochrome
Maximum Mono Print Speed:
4 in/s
Maximum Print Resolution (dpi):
203 x 203
Maximum Print Width:
4.09"
Barcode Symbology Supported:
  • Code 11
  • Code 39
  • Code 49
  • Code 93
  • Code 128-A
  • Code 128-B
  • Code 128-C
  • Codabar
  • Codablock
  • UPC-A
  • UPC-E
  • EAN/JAN-8
  • EAN/JAN-13
  • UCC
  • ISBT-128
  • Interleaved 2 of 5
  • Industrial 2 of 5
  • Maxi Code
  • Micro PDF-417
  • MSI
  • Plessey
  • PDF-417
  • POSTNET
  • Standard 2 of 5
  • Data Matrix
  • QR Code
  • LOGMARS
  • EAN With 2 or 5 Digit Extension
Memory
Standard Memory:
256 KB
Memory Technology:
SDRAM
Flash Memory:
512 KB
Interfaces/Ports
Serial Port:
Yes
USB:
Yes
Network & Communication
Ethernet:
Yes
Ethernet Technology:
Ethernet
Media Types & Handling
Media Type:
  • Label
  • Continuous Form
Media Sensor:
  • Reflective Media Sensor
  • Transmissive Media Sensor
Media Thickness:
7.09 mil
Maximum Roll Diameter:
5"
Maximum Label Width:
4.25"
Maximum Label Length:
11"
Label Core Size:
1.50"
Fonts & Emulation
Language Emulation:
  • ZPL II
  • ZBI
Power Description
Input Voltage:
  • 110 V AC
  • 220 V AC
Frequency:
60 Hz
Physical Characteristics
Height:
6.8"
Width:
7.8"
Depth:
9.4"
Miscellaneous
Package Contents:
  • TLP 2844-Z Label Printer
  • User Documentation: English
Additional Information:
  • Supports user-defined fonts and graphics, inlcuding custom logos
  • IBM Code Page 850 International Characters
  • Construction: High-impact, double-walled plastic enclosure
  • Dual Media Sensors:
  • Transmissive
  • Reflective
  • Ribbons:
  • Width (outside diameter): 1.3" to 4.3"
  • Length: 2,928"
Platform Supported:
PC
Certifications & Standards:
  • UL-CUL 1950
  • FCC Class B
  • VCCI Class B
  • C-Tick
  • EN 500082-1
  • EN 55022 Class B
  • CB
  • CE
  • CCC
  • NOM
  • IRAM
  • BSMI
  • GOST
System Requirements:

PC:

  • Windows 95
  • Windows 98
  • Windows NT 4.0
  • Windows 2000
  • Windows XP
Warranty
Limited Warranty:
1 Year
Item Numbers
UNSPSC: 43212108
Questions? Get help from a
Printer Expert!

How many labels will you print per day?

The Zebra 284Z-10400-0001 Barcode Label Printer is also known as ELT-284Z104000001 or 284Z104000001.
