Zebra LP 2824 – Barcode Label Printer – 203 dpi – Direct Thermal – Cutter, Real-Time Clock

Part Number: 2824-21402-0031
Model: LP 2824
Add to My Shopping List Add to Compare
Discontinued See Replacement

Price Match Guarantee - We'll match any authorized retailer's price

Quantity:

Product Highlights

View All
Printer Type
Desktop
Printing Technology
Direct Thermal
Interface Options
Ethernet
Print Resolution
203 dpi

Product Description:

  Direct thermal, 203 dpi, 4 ips, 2" print width, Ethernet Print Server II interface, 256KB RAM, 1MB Flash. Include US power supply, Cutter, Standard Fonts, Real Time Clock
Explore all Zebra LP 2824 Barcode Label Printers
Add to Quote
Zebra 2824-21402-0031 Barcode Label Printer
Zebra 2824-21402-0031 Barcode Label Printer
Zebra 2824-21402-0031 Barcode Label Printer
Zebra 2824-21402-0031 Barcode Label Printer Zebra 2824-21402-0031 Barcode Label Printer

Full specifications (PDF)

Zebra LP 2824 Barcode Label Printer Model Overview

With its competitive electronic platform, the Zebra LP 2824 delivers high quality barcode label printing at 3.5 inches per second and supports a range of options and accessories for flexible printing solutions. All units ship with one user's manual.
Zebra 2824-21402-0031 Barcode Label Printer Overview

The LP 2824 excels in delivering printing solutions for business and professional offices, including retail point of sale, shelf labeling, product marking, health care specimen labeling and patient tracking, inventory and asset management, small office or home office mailing, shipping, and file folder labeling.

Full specifications (PDF)
Technical Information
Recommended Use:
Label Print
Print Color Capability:
Monochrome
Maximum Mono Print Speed:
4 in/s
Maximum Print Resolution (dpi):
203 x 203
Maximum Print Width:
2.20"
Barcode Symbology Supported:
  • Code 39
  • Code 128-A
  • Code 128-B
  • Code 128-C
  • Codabar
  • Interleaved 2 of 5
  • UPC-A
  • UPC-E
  • UPC-A with 2 and 5 Add-on
  • EAN-13
  • EAN-8
  • EAN-8 With 2 or 5 Digit Extension
  • EAN-13 With 2 or 5 Digit Extension
  • POSTNET
  • Japan Postal
  • Plessey
  • German Post Code
  • MSI-3
  • Maxi Code
  • Micro PDF-417
  • Macro PDF-417
  • Data Matrix
  • RSS-14
  • Code 93
Memory
Standard Memory:
256 KB
Flash Memory:
1 MB
Interfaces/Ports
Serial Port:
Yes
Network & Communication
Ethernet:
Yes
Ethernet Technology:
Fast Ethernet
Media Types & Handling
Media Type:
  • Roll Fed
  • Fanfold
  • Die-cut Label
  • Continuous Form
  • Tag Stock
  • Continuous Receipt
  • Linerless
Media Thickness:
7.09 mil
Maximum Roll Diameter:
5"
Maximum Label Width:
2.36
Maximum Label Length:
11"
Fonts & Emulation
Language Emulation:
ASCII EPL2
Power Description
Input Voltage:
110 V AC
Frequency:
60 Hz
Miscellaneous
Additional Information:
  • Included Features: Cutter
  • Real Time Clock
  • Core diameter: 1" (25.4 mm) or 1.5" (38 mm)
  • Media thickness: 0.003" (.075 mm) to 0.007" (0.18 mm)
  • Maximum label and liner length (optional): 22" (558 mm)
  • Print Length:
  • 11" (279 mm) with standard memory
  • 22" (584 mm) with expanded memory
  • Media sensors:
  • Transmissive
  • Reflective
  • Fonts and Graphics:
  • Standard Fonts: 5 bitmapped, expandable 8x
  • Soft font storage in Flash memory
  • DOS Code Pages Supported: 437, 850, 851, 852, 855, 857, 860, 861, 862, 863, 865, 866, 869, 737
  • Windows Code Pages Supported: 1250, 1251, 1252, 1253, 1254, 1255, 1256, 1257
Platform Supported:
PC
Certifications & Standards:
  • UL
  • FCC
  • VCCI
  • VCCI/PSE
  • C-TICK
  • CCC/SRRC
  • NOM
  • CSA
  • CE
  • GOST-R
Item Numbers
UNSPSC: 45101512

Recommended Accessories

Category

  • Barcode Label Rewinder (1)
  • Cables To Go (2)
  • Cables, Connectors, and Adapters (3)
  • Computer Accessories (3)
  • Print Server (3)
  • Printer Accessories (14)

Recommended Accessories for Model: Zebra 2824-21402-0031 Barcode Label Printer

Top Barcode Label Rewinder Purchased With Zebra 2824-21402-0031

Top Cables To Go Purchased With Zebra 2824-21402-0031

Top Cables, Connectors, and Adapters Purchased With Zebra 2824-21402-0031

Top Computer Accessories Purchased With Zebra 2824-21402-0031

Top Print Server Purchased With Zebra 2824-21402-0031

Top Printer Accessories Purchased With Zebra 2824-21402-0031

See All Printer Accessories for Zebra 2824-21402-0031 Barcode Label Printer >
Questions? Get help from a
Printer Expert!

How many labels will you print per day?

The Zebra 2824-21402-0031 Barcode Label Printer is also known as ZEB-2824214020031 or 2824214020031.
