Zebra 170Xi4 – Barcode Label Printer – 203 dpi – Thermal Transfer

Part Number: 172-801-00000-GA
Model: 170Xi4
Add to My Shopping List Add to Compare
Discontinued See Replacement

Price Match Guarantee - We'll match any authorized retailer's price

Quantity:

Product Highlights

Printer Type
Industrial
Printing Technology
Thermal Transfer
Print Resolution
203 dpi
Max Print Width
7 inch

Product Description:

  Thermal Transfer Industrial Printer (203 dpi, Ethernet, USB, Parallel, and Serial (RS-232) interfaces, 6.6" max print width, 16MB SDRAM, Clear Media Side Door & Media Hanger). Includes power supply. Cables sold separately. See accessories. . This is the TAA-compliant version of this product for government purchasers. Please Call for more information.
Explore all Zebra 170Xi4 Barcode Label Printers
Add to Quote
Zebra 172-801-00000-GA Barcode Label Printer
Zebra 172-801-00000-GA Barcode Label Printer
Zebra 172-801-00000-GA Barcode Label Printer
Zebra 172-801-00000-GA Barcode Label Printer
Zebra 172-801-00000-GA Barcode Label Printer
Zebra 172-801-00000-GA Barcode Label Printer Zebra 172-801-00000-GA Barcode Label Printer Zebra 172-801-00000-GA Barcode Label Printer Zebra 172-801-00000-GA Barcode Label Printer

Full specifications (PDF)

Zebra 170Xi4 Barcode Label Printer Model Overview

The industrial-strength Zebra 170Xi4 with 203- or 300-dpi (8 or 12 dots per mm) print resolution and a 6.6" print width at 12" per second can print large volumes of labels, promoting greater productivity with fewer roll changes. Or it can execute intricate, high-resolution print applications at a quick 8" (203 mm) per second. With its all-metal construction, this printer is ideal for tough applications including compliance labels (AIAG, ODETTE, UCC/EAN-128, etc.), product identification labels and pallet shipping/receiving labels, either on demand or in batches.
Zebra 172-801-00000-GA Barcode Label Printer Overview

The industrial-strength 170Xi4 with 203- or 300-dpi (8 or 12 dots per mm) print resolution can print large volumes of labels, promoting greater productivity with fewer roll changes. Or it can execute intricate, high-resolution print applications at a quick 8" (203 mm) per second. With its all-metal construction, this printer is ideal for tough applications including compliance labels (AIAG, ODETTE, UCC/EAN-128, etc.), product identification labels, and pallet shipping/receiving labels, either on demand or in batches.

Full specifications (PDF)
Technical Information
Recommended Use:
Label Print
Print Color Capability:
Monochrome
Maximum Mono Print Speed:
12 in/s
Maximum Print Resolution (dpi):
203
Maximum Print Width:
6.60"
Barcode Symbology Supported:
  • Codabar
  • Code 11
  • Code 128-A
  • Code 128-B
  • Code 128-C
  • UCC Case Codes
  • Code 39
  • Code 93
  • EAN-13
  • EAN-8
  • ISBT-128
  • Interleaved 2 of 5
  • Industrial 2 of 5
  • LOGMARS
  • MSI
  • Planet Code
  • POSTNET
  • Standard 2 of 5
  • EAN With 2 or 5 Digit Extension
  • UPC 2 or 5 Digit Extension
  • UPC-A
  • UPC-E
  • Aztec Code
  • Codablock
  • Code 49
  • Data Matrix
  • Maxi Code
  • Micro PDF
  • PDF-417
  • QR Code
  • RSS
  • GS1 DataBar
  • TLC 39
  • Plessey
Real Time Clock:
Yes
Application/Usage:
Desktop
Features:
  • Clear Media Side Door
  • Mirror Printing
Memory
Standard Memory:
16 MB
Memory Technology:
SDRAM
Flash Memory:
64 MB
Interfaces/Ports
Parallel Port:
Yes
Serial Port:
Yes
USB:
Yes
Network & Communication
Ethernet:
Yes
Ethernet Technology:
Fast Ethernet
Display & Graphics
Display Screen:
Yes
Display Screen Type:
LCD
Media Types & Handling
Media Type:
  • Black Mark
  • Continuous Label
  • Fanfold
  • Roll Fed
  • Die-cut Label
Media Sensor:
  • Reflective Media Sensor
  • Transmissive Media Sensor
Media Thickness:
12 mil
Maximum Roll Diameter:
8"
Maximum Label Width:
7.10"
Maximum Label Length:
12.50 ft
Label Core Size:
3"
Ribbon Core Size:
1"
Fonts & Emulation
Language Emulation:
  • XML
  • ZPL II
Power Description
Power Source:
AC Supply
Input Voltage:
110 V AC
Physical Characteristics
Height:
15.5"
Width:
13.3"
Depth:
20.4"
Weight (Approximate):
67.24 lb
Miscellaneous
Package Contents:
  • 170Xi4 Label Printer Government Compliant
  • North American Edition 120 VAC Power Cord
  • User Guide
  • Software CD
Cables Included:
AC
Platform Supported:
PC
Certifications & Standards:
  • BSMI
  • cTUVus
  • CCC
  • CE
  • C-Tick
  • EN55022 Class B
  • EN55024
  • EN61000-3-2,3
  • FCC Class B
  • GOST-R
  • ICES-003 Class B
  • IEC 60950-1 / EN60950
  • KCC
  • NOM
  • S Mark
  • STB
  • UkrSEPRO
  • VCCI
  • ZIK
  • TAA
Warranty
Limited Warranty:
1 Year
