Zebra 170XiIIIPlus – Barcode Label Printer – 300 dpi, 305 dpi – Thermal Transfer

Part Number: 170-741-00200
Model: 170XiIIIPlus
Add to My Shopping List Add to Compare
Discontinued See Replacement

Price Match Guarantee - We'll match any authorized retailer's price

Quantity:

Product Highlights

View All
Printer Type
Industrial
Printing Technology
Thermal Transfer
Interface Options
Ethernet, Serial (RS-232), USB
Print Resolution
300 dpi, 305 dpi

Product Description:

  Thermal Transfer Industrial Printer (300 dpi, Ethernet, USB, Serial (RS-232), and Parallel interfaces, 6.6" max print width, 16MB SDRAM, Rewinder, Clear Media Side Door & Media Hanger). Includes power supply. Cables sold separately. See accessories.
Explore all Zebra 170XiIIIPlus Barcode Label Printers
Add to Quote
Zebra 170-741-00200 Barcode Label Printer
Zebra 170-741-00200 Barcode Label Printer
Zebra 170-741-00200 Barcode Label Printer
Zebra 170-741-00200 Barcode Label Printer Zebra 170-741-00200 Barcode Label Printer

Full specifications (PDF)

Zebra 170XiIIIPlus Barcode Label Printer Model Overview

The industrial-strength 170XiIIIPlus can print large volumes of high resolution labels up to 6.6 inches (168mm) wide at eight inches per second. With its all metal construction, the 170XiIIIPlus printer is ideal for tough applications including compliance labels (AIAG, ODETTE, UCC/EAN-128, etc.), product identification labels, pallet shipping/receiving labels either on demand or in batches. The 170XiIIIPlus is designed to deliver maximum performance and reliability in the most demanding industrial applications. The 170XiIIIPlus features 16MB RAM, 4MB Flash, & standard parallel, serial, and USB 2.0 interface ports. All units ship with one user's manual.
Zebra 170-741-00200 Barcode Label Printer Overview

Providing superior performance, longevity, and solid vaulue, the 170XiIIIPlus offers rugged durability, dependability, and unparalleled reliablility in high-volume, mission-critical and specialty labeling solutions. Insuring investment protection are key features and options, such as 203 and 300 dpi resolution for paper,synthetic, and specialty stocks; a 32 bit processor for fast throughput and processing; increased memory for label formats, graphics, fonts and data; and early warning notification for printhead maintenance support. 170XiIIIPlus printer also offer more connectivity options then competitors, including XML-enabled printing, ZebraNet wireless and wired print servers, and USB 2.0. Its easy to see why 170XiIIIPlus printer take high performance to an all new level.

Full specifications (PDF)
Technical Information
Recommended Use:
Label Print
Maximum Mono Print Speed:
8 in/s
Maximum Print Resolution (dpi):
300
Maximum Print Width:
6.60"
Barcode Symbology Supported:
  • Codabar
  • Code 11
  • Code 93
  • Code 39
  • EAN-8
  • EAN-13
  • Industrial 2 of 5
  • Interleaved 2 of 5
  • LOGMARS
  • MSI
  • Planet Code
  • Plessey
  • POSTNET
  • Standard 2 of 5
  • UPC 2 or 5 Digit Extension
  • EAN With 2 or 5 Digit Extension
  • UPC-A
  • UPC-E
  • Code 128-A
  • Code 128-B
  • Code 128-C
  • UCC Case Codes
  • ISBT-128
  • Codablock
  • Code 49
  • Data Matrix
  • Maxi Code
  • PDF-417
  • QR Code
  • RSS
  • TLC 39
  • Micro PDF
  • Aztec Code
Rewinder:
Yes
Memory
Standard Memory:
16 MB
Memory Technology:
SDRAM
Flash Memory:
4 MB
Network & Communication
Ethernet:
Yes
Ethernet Technology:
Ethernet
Display & Graphics
Display Screen:
Yes
Display Screen Type:
LCD
Media Types & Handling
Media Type:
  • Continuous Form
  • Die-cut Label
  • Black Mark
Media Sensor:
  • Reflective Media Sensor
  • Transmissive Media Sensor
Media Thickness:
120 mil
Maximum Roll Diameter:
8"
Maximum Label Width:
6.60"
Maximum Label Length:
39"
Label Core Size:
3"
Ribbon Core Size:
1"
Fonts & Emulation
Language Emulation:
ZPL II
Software
Software Included:

Software included:

  • Ztools Utilities
  • ZPL II Programming Guide
  • BAR-ONE Lite/Platinum demo
  • JefForm Central ERP Solution
  • Windows Drivers
  • ZebraNet WebView and Alert Utilities
  • Adobe Acrobat
  • Direct Zebra Web Access
  • Zebra Link Solutions
Power Description
Input Voltage:
  • 110 V AC
  • 220 V AC
Physical Characteristics
Height:
15.5"
Width:
13.2"
Depth:
19.5"
Miscellaneous
Package Contents:
  • 170Xiii Plus Label Printer
  • Xi IIIPlus User's Guide
  • Utility & Driver CD
  • ZebraNet Connectivity CD
  • North American Edition Power Cord
Cables Included:
AC
Additional Information:

Temperatures:

  • Operating temperature 41° F to 104° F Thermal transfer
  • Operating temperature 32° F to 104° F Direct thermal

Media Sensors:

  • Reflective
  • Transmissive
Platform Supported:
PC
Certifications & Standards:
  • Class B
  • FCC Class B
  • EN55024: 1998
  • R.O.C. CNS 13438
  • Canadian ICES-003
  • Australia AS/NZS 3548
  • EN55022: 1998 Class B
  • Argentina 92/98 Phase 3
  • EN61000-3-2,3 W/amendment A12
  • IEC 950/EN60950: 1992 W/amendments 1 thru 4 (CB Scheme
  • Bi-National UL 60950 3rd edition/CSA CAN/CSA-C22.2 No. 60950-00 Third Edition
Warranty
Limited Warranty:
1 Year
Item Numbers
GTIN: 0732387102915
UPC: 732387102915
EAN: 0732387102915
UNSPSC: 43212108
