Zebra 140-8K1-00100 Barcode Label Printer

The Zebra 140-8K1-00100 Barcode Label Printer has been discontinued.
No direct replacement is available.
Please contact us for a suitable substitute.
Zebra 140Xi4 - 5" DT/TT TABLETOP, 203DPI, ZEBRANET B/G PRINTSERVER RADIO CARD INCLUDED, RS-232 SERIAL, PARALLEL, USB 2.0, INTERNAL ZEBRANET 10/100, CUTTER WITH CATCH TRAY, 16MB WITH ZPL II AND XML
Print Resolution
203 dpi
  • A smart choice for carrying out high volume label printing in multiple areas with reduced cost of ownership
  • 203 maximum print resolution (dpi) for your convenience and easy usage
  • Produce high-quality documents with this monochrome printer to increase your productivity
  • Delivers high-speed, hassle-free labeling solution for your business needs
  • Print your documents from the comfort of your couch with Wireless LAN connectivity enabled
  • 5.51" maximum label width to easily accommodate your needs with added productivity
  • 12.50 ft maximum label length for dependable, desired results
  • Supports black mark media type for dependable, efficient results with maximum productivity
  • Features multi-functional knives for conveniently cutting the paper to provide you with the desired shape
  • Direct Thermal/Thermal Transfer Printer with desktop application/usage provides maximum usability with better reliance
Read More

Need a different version? See all Zebra 140Xi4 Barcode Label Printers

Discontinued Need Assistance?
Add to Quote
Add to My Shopping List Add to Compare
Zebra 140-8K1-00100 Barcode Label Printer
Zebra 140-8K1-00100 Barcode Label Printer Zebra 140-8K1-00100 Barcode Label Printer Zebra 140-8K1-00100 Barcode Label Printer Zebra 140-8K1-00100 Barcode Label Printer Zebra 140-8K1-00100 Barcode Label Printer
Zebra 140-8K1-00100 Barcode Label Printer
Zebra 140-8K1-00100 Barcode Label Printer
Zebra 140-8K1-00100 Barcode Label Printer
Zebra 140-8K1-00100 Barcode Label Printer

Full specifications (PDF)
Zebra 140Xi4 Barcode Label Printer Model Overview
Built on the proven Xi series platform that is known for rugged durability and performance, the new Zebra 140Xi4 features a 5.0" print width and brings several additional features to high-volume, mission-critical applications and environments that require 24 x 7 operations. Building on these high-performance hallmarks, the 140Xi4 now provides several new features and benefits including increased print speeds up to 14"/356 mm per second for increased batch and print/apply productivity, LCD content customizable to user needs, a large, easy to use, multilingual LCD screen, flexible connectivity options including simultaneous parallel/Ethernet with internal Ethernet included as standard in the product advanced ribbon- and media-low LCD/e-mail alerts and an intelligent printhead system.
Zebra 140-8K1-00100 Barcode Label Printer Overview

Another addition to Zebra's Xi4 product line is the 140Xi4. Built on the proven Xi series platform that is known for rugged durability and performance, the new Xi4 brings several additional features to high-volume, mission-critical applications and environments that require 24 x 7 operations. Building on these high-performance hallmarks, the Xi4 now provides several new features and benefits.

Full specifications (PDF)
Technical Information
Recommended Use:
Label Print
Print Color Capability:
Monochrome
Maximum Mono Print Speed:
14 in/s
Maximum Print Resolution (dpi):
203
Maximum Print Width:
5.04"
Barcode Symbology Supported:
  • Code 11
  • Code 39
  • Code 93
  • Code 128-A
  • Code 128-B
  • Code 128-C
  • UCC Case Codes
  • UPC-A
  • UPC-E
  • EAN-13
  • EAN-8
  • UPC 2 or 5 Digit Extension
  • EAN With 2 or 5 Digit Extension
  • Plessey
  • POSTNET
  • Standard 2 of 5
  • Industrial 2 of 5
  • Interleaved 2 of 5
  • LOGMARS
  • MSI
  • Planet Code
  • Codabar
  • Codablock
  • Code 49
  • PDF-417
  • Data Matrix
  • Maxi Code
  • QR Code
  • TLC 39
  • Micro PDF-417
  • Aztec Code
  • RSS
  • GS1 DataBar
  • Micro PDF
Real Time Clock:
Yes
Application/Usage:
Desktop
Features:
  • Clear Media Side Door
  • Mirror Printing
Memory
Standard Memory:
16 MB
Memory Technology:
SDRAM
Flash Memory:
8 MB
Interfaces/Ports
Parallel Port:
Yes
Serial Port:
Yes
USB:
Yes
Network & Communication
Ethernet:
Yes
Ethernet Technology:
Fast Ethernet
Wireless LAN:
Yes
Wireless LAN Standard:
IEEE 802.11g
Display & Graphics
Display Screen:
Yes
Display Screen Type:
LCD
Cutter
Cutter:
Yes
Media Types & Handling
Media Type:
  • Black Mark
  • Continuous Label
  • Die-cut Label
  • Fanfold
  • Roll Fed
Media Handling:
1 x Catch Tray
Media Sensor:
  • Transmissive Media Sensor
  • Reflective Media Sensor
Media Thickness:
12 mil
Maximum Roll Diameter:
8"
Maximum Label Width:
5.51"
Maximum Label Length:
12.50 ft
Label Core Size:
3"
Ribbon Core Size:
1"
Fonts & Emulation
Language Emulation:
  • XML
  • ZPL II
Power Description
Power Source:
AC Supply
Input Voltage:
110 V AC
Physical Characteristics
Height:
15.5"
Width:
11.3"
Depth:
20.4"
Weight (Approximate):
55 lb
Miscellaneous
Package Contents:
  • 140Xi4 Label Printer
  • User's Guide
  • Software & Driver CD
  • North American Edition 120 VAC Power Cord
Cables Included:
AC
Platform Supported:
PC
Certifications & Standards:
  • Unicode
  • BSMI
  • cTUVus
  • CCC
  • CE
  • C-Tick
  • EN55022 Class B
  • EN55024
  • EN61000-3-2,3
  • FCC Class B
  • GOST-R
  • ICES-003 Class B
  • IEC 60950-1 / EN60950
  • KCC
  • NOM
  • S Mark
  • STB
  • UkrSEPRO
  • VCCI
  • ZIK
Environmentally Friendly:
Yes
Environmental Certification:
China RoHS
Warranty
Limited Warranty:
1 Year
Item Numbers
UNSPSC: 43212108
Questions? Get help from a
Printer Expert!

How many labels will you print per day?

The Zebra 140-8K1-00100 Barcode Label Printer is also known as ZEB-1408K100100 or 140-8K1-00100.
