Zebra 140-8K1-00000 Barcode Label Printer

The Zebra 140-8K1-00000 Barcode Label Printer has been discontinued.
No direct replacement is available.
Please contact us for a suitable substitute.

Zebra 140Xi4 - Thermal Transfer Industrial Printer (203 dpi, Wi-Fi (card included), Ethernet, USB, Serial (RS-232), and Parallel interfaces, 5" max print width, 16MB SDRAM, Clear Media Side Door & Media Hanger). Includes power supply. Cables sold separately. See accessories.

Print Resolution

203 dpi

Print methods: Thermal transfer or direct thermal
Full-function front panel and large, multilingual, back-lit LCD display with user-programmable password protection
Clear media side door allows easy monitoring of supplies usage without opening the printer systems
32 bit 133 Mhz RISC processor
64 MB on-board linear Flash memory
16 MB SDRAM Flash memory
Internal real-time clock
Advanced label/media counters
Dual media sensors - transmissive and reflective, selectable through software or front panel
Auto calibration when printer is turned on or when printhead is closed using approximately two labels

Need a different version? See all Zebra 140Xi4 Barcode Label Printers

Discontinued Need Assistance?

Add to Quote

Zebra 140-8K1-00000 Barcode Label Printer

Overview

Full specifications (PDF)

Zebra 140Xi4 Barcode Label Printer Model Overview

Built on the proven Xi series platform that is known for rugged durability and performance, the new Zebra 140Xi4 features a 5.0" print width and brings several additional features to high-volume, mission-critical applications and environments that require 24 x 7 operations. Building on these high-performance hallmarks, the 140Xi4 now provides several new features and benefits including increased print speeds up to 14"/356 mm per second for increased batch and print/apply productivity, LCD content customizable to user needs, a large, easy to use, multilingual LCD screen, flexible connectivity options including simultaneous parallel/Ethernet with internal Ethernet included as standard in the product advanced ribbon- and media-low LCD/e-mail alerts and an intelligent printhead system.

Zebra 140-8K1-00000 Barcode Label Printer Overview

Another addition to Zebra's Xi4 product line is the 140Xi4. Built on the proven Xi series platform that is known for rugged durability and performance, the new Xi4 brings several additional features to high-volume, mission-critical applications and environments that require 24 x 7 operations.

Detailed Specs

Full specifications (PDF)

Technical Information

Recommended Use:

Label Print

Print Color Capability:

Monochrome

Maximum Mono Print Speed:

14 in/s

Maximum Print Resolution (dpi):

203

Maximum Print Width:

5.04"

Barcode Symbology Supported:

Codablock
PDF-417
Code 49
Data Matrix
QR Code
Maxi Code
TLC 39
Micro PDF
Aztec Code
RSS
GS1 DataBar
Code 11
Code 39
Code 93
UCC Case Codes
Code 128-A
Code 128-B
Code 128-C
UPC-A
UPC-E
EAN-8
EAN-13
UPC 2 or 5 Digit Extension
EAN With 2 or 5 Digit Extension
Plessey
POSTNET
Standard 2 of 5
Industrial 2 of 5
Interleaved 2 of 5
LOGMARS
MSI
Planet Code
Codabar

Real Time Clock:

Yes

Application/Usage:

Desktop

Features:

Clear Media Side Door
Mirror Printing

Memory

Standard Memory:

16 MB

Memory Technology:

SDRAM

Flash Memory:

8 MB

Interfaces/Ports

Parallel Port:

Yes

Serial Port:

Yes

USB:

Yes

Network & Communication

Ethernet:

Yes

Ethernet Technology:

Fast Ethernet

Wireless LAN:

Yes

Wireless LAN Standard:

IEEE 802.11g

Display & Graphics

Display Screen:

Yes

Display Screen Type:

LCD

Media Types & Handling

Media Type:

Black Mark
Continuous Label
Die-cut Label
Roll Fed
Fanfold

Media Sensor:

Transmissive Media Sensor
Reflective Media Sensor

Media Thickness:

12 mil

Maximum Roll Diameter:

Maximum Label Width:

5.51"

Maximum Label Length:

12.50 ft

Label Core Size:

Ribbon Core Size:

Fonts & Emulation

Language Emulation:

XML
ZPL II

Power Description

Power Source:

AC Supply

Input Voltage:

110 V AC

Physical Characteristics

Height:

15.5"

Width:

11.3"

Depth:

20.4"

Weight (Approximate):

55 lb

Miscellaneous

Package Contents:

110Xi4 Label Printer
North American Edition 120 VAC Power Cord

Cables Included:

Platform Supported:

Certifications & Standards:

Unicode
BSMI
cTUVus
CCC
CE
C-Tick
EN55022 Class B
EN55024
EN61000-3-2,3
FCC Class B
GOST-R
ICES-003 Class B
IEC 60950-1 / EN60950
KCC
NOM
S Mark
STB
UkrSEPRO
VCCI
ZIK

Warranty

Limited Warranty:

1 Year

Item Numbers

GTIN: 0783555112496, 0807027540720

UPC: 783555112496, 807027540720

EAN: 0783555112496, 0807027540720

UNSPSC: 43212108

Q&A

Questions? Get help from a
Printer Expert!

The Zebra 140-8K1-00000 Barcode Label Printer is also known as ZEB-1408K100000 or 140-8K1-00000.
