Zebra 140-8E1-00200 Barcode Printer


0.0

(No reviews)

Be the first to

Write a Review
Zebra 140Xi4 - Thermal transfer Industrial Printer (203 dpi, Wi-Fi Ready (Radio Card Not Included), Ethernet, USB, Serial (RS-232), and Parallel interfaces, 5" max print width, 16MB SDRAM, Rewinder and Peeler, Clear Media Side Door & Media Hanger). Includes power supply. Cables sold separately. See accessories.

Built on the proven Xi series platform that is known for rugged durability and performance, the new Zebra 140Xi4 features a 5.0" print width and brings several additional features to high-volume, mission-critical applications and environments that require 24 x 7 operations. Building on these high-performance hallmarks, the 140Xi4 now provides several new features and benefits including increased print speeds up to 14"/356 mm per second for increased batch and print/apply productivity, LCD content customizable to user needs, a large, easy to use, multilingual LCD screen, flexible connectivity options including simultaneous parallel/Ethernet with internal Ethernet included as standard in the product advanced ribbon- and media-low LCD/e-mail alerts and an intelligent printhead system.

Technical Information

  • Maximum Mono Print Speed: 14 in/s
  • Peel Facility: Yes
  • Maximum Print Resolution: 203 dpi
  • Print Color: Monochrome
  • Maximum Print Width: 5.04"
  • Recommended Use: Label Print
  • Features:
    • Clear Media Side Door
    • Peel Facility
    • Real Time Clock
    • Rewind
    • Mirror Printing
  • Barcode Symbology Supported:
    • Codabar
    • Code 11
    • Code 128-A
    • Code 39
    • Code 93
    • EAN-13
    • EAN-8
    • ISBT-128
    • Industrial 2 of 5
    • Interleaved 2 of 5
    • LOGMARS
    • MSI
    • Planet Code
    • Plessey
    • Standard 2 of 5
    • UPC 2 or 5 Digit Extension
    • EAN With 2 or 5 Digit Extension
    • UPC-A
    • UPC-E
    • Aztec Code
    • Codablock
    • Code 49
    • Data Matrix
    • Maxi Code
    • Micro PDF
    • PDF-417
    • QR Code
    • RSS
    • TLC 39
    • POSTNET
    • Code 128-B
    • Code 128-C
    • UCC Case Codes
    • GS1 DataBar

General Information

  • Product Type: Direct Thermal/Thermal Transfer Printer
  • Product Series: Xi4
  • Brand Name: Zebra
  • Manufacturer: Zebra Technologies Corporation
  • Product Model: 140Xi4
  • Product Name: 140Xi4 Label Printer

Physical Characteristics

  • Height: 15.5"
  • Width: 11.3"
  • Depth: 20.4"
  • Form Factor: Desktop
  • Weight (Approximate): 55.12 lb

Interfaces/Ports

  • USB: Yes
  • Serial Port: Yes
  • Parallel Port: Yes

Other

  • Platform Supported: PC
  • Package Contents:
    • 140Xi4 Label Printer
    • North American Edition 120 VAC Power Cord
    • User Guide
    • Software CD
    • 140Xi4 Label Printer
    • North American Edition 120 VAC Power Cord
    • User Guide
    • Software CD
  • Certifications & Standards:
    • BSMI
    • cTUVus
    • CCC
    • CE
    • C-Tick
    • EN55022 Class B
    • EN55024
    • EN61000-3-2,3
    • FCC Class B
    • GOST-R
    • ICES-003 Class B
    • IEC 60950-1 / EN60950
    • KCC
    • NOM
    • S Mark
    • STB
    • UkrSEPRO
    • VCCI
    • ZIK

Media Types & Handling

  • Maximum Label Width: 5.51"
  • Maximum Label Length: 12.50 ft
  • Media Type:
    • Continuous Label
    • Black Mark
    • Roll Fed
    • Die-cut Label
    • Fanfold
    • Label
  • Media Thickness: 12 mil
  • Label Core Size: 3"
  • Ribbon Core Size: 1"
  • Maximum Roll Diameter: 8"

Network & Communication

  • Ethernet: Yes
  • Wireless LAN: Yes
  • Ethernet Technology: Fast Ethernet

Memory

  • Standard Memory: 16 MB
  • Memory Technology: SDRAM
  • Flash Memory: 8 MB

Fonts & Emulation

  • Language Emulation:
    • ZPL II
    • XML

Power Description

  • Input Voltage: 110 V AC

Display & Graphics

  • Display Screen Type: LCD

Warranty

  • Limited Warranty: 1 Year

Full specifications (PDF)

Full specifications (PDF)

Brand Zebra
Model 140Xi4
Interface Options Wireless
Max Roll Outer Diameter 8
Print Method Thermal Transfer
Print Speed 14
Max Label Width 5.51
Print Resolution 203 dpi
Maximum Print Width 5.04
Printer Type Industrial
Label Core 3 inches
Printer Mobility Not Mobile
