Zebra 116-8K1-00001 Barcode Label Printer

The Zebra 116-8K1-00001 Barcode Label Printer has been discontinued.
No direct replacement is available.
Please contact us for a suitable substitute.
Zebra 110Xi4 - 110XI4 600 SER/PAR/USB 10/100 B/G PRINT SER 3-MEDIA SPNDL
  • A smart choice for carrying out high volume label printing in multiple areas with reduced cost of ownership
  • 600 maximum print resolution (dpi) for better reliance and added usability
  • The printer is capable of printing sharp and detailed monochrome documents quickly
  • Label Print gives dependable results with maximum productivity
  • Print your documents from the comfort of your couch with Wireless LAN connectivity enabled
  • 4.50" maximum label width to easily accommodate your needs with added productivity
  • 12.50 ft maximum label length to easily accommodate your needs with added productivity
  • Supports black mark media type for maximum feasibility and better accommodation of your requirements
  • Direct Thermal/Thermal Transfer Printer with industrial application/usage provides reliable, feasible printing solution
  • Clear Media Side Door feature for maximum efficiency and convenience
Read More

Need a different version? See all Zebra 110Xi4 Barcode Label Printers

Discontinued Need Assistance?
Add to Quote
Add to My Shopping List Add to Compare
Zebra 116-8K1-00001 Barcode Label Printer
Zebra 116-8K1-00001 Barcode Label Printer Zebra 116-8K1-00001 Barcode Label Printer Zebra 116-8K1-00001 Barcode Label Printer Zebra 116-8K1-00001 Barcode Label Printer Zebra 116-8K1-00001 Barcode Label Printer Zebra 116-8K1-00001 Barcode Label Printer Zebra 116-8K1-00001 Barcode Label Printer
Zebra 116-8K1-00001 Barcode Label Printer
Zebra 116-8K1-00001 Barcode Label Printer
Zebra 116-8K1-00001 Barcode Label Printer
Zebra 116-8K1-00001 Barcode Label Printer
Zebra 116-8K1-00001 Barcode Label Printer
Zebra 116-8K1-00001 Barcode Label Printer

Full specifications (PDF)
Zebra 110Xi4 Barcode Label Printer Model Overview
The Zebra 110Xi4 is the go to workhorse printer and is built on the legacy of the Xi series of products. With a 4.0" print width, the Zebra 110Xi4 was developed to improve overall operational productivity and efficiency in a variety of environments. These improvements include an increased print speeds up to 14"/356 mm per second for increased batch and print/apply productivity, a large, easy to use, multilingual LCD screen with content that is customizable to user needs, flexible connectivity options including simultaneous parallel/Ethernet with internal Ethernet included as standard, with intelegent low ribbon- and media-low alerts, you will know exaclty when printing supplies need to be replaced with LCD/e-mail alerts. The Zebra 110Xi4 is the printer you can rely on to print the you labels you need!
Zebra 116-8K1-00001 Barcode Label Printer Overview

Built for high-volume applications and harsh environments, Zebra's Xi Series label printers deliver superior print quality and reliability. Boost productivity with faster print and connection speeds, and reduce downtime with early warning.

Full specifications (PDF)
Technical Information
Recommended Use:
Label Print
Print Color Capability:
Monochrome
Maximum Mono Print Speed:
14 in/s
Maximum Print Resolution (dpi):
600
Maximum Print Width:
4"
Barcode Symbology Supported:
  • Code 11
  • Code 39
  • Code 93
  • Code 128
  • Code 128-A
  • Code 128-B
  • Code 128-C
  • Code 128 UCC
  • UPC-A
  • UPC-E
  • EAN-8
  • EAN-13
  • UPC 2 or 5 Digit Extension
  • EAN With 2 or 5 Digit Extension
  • Plessey
  • POSTNET
  • Standard 2 of 5
  • Industrial 2 of 5
  • Interleaved 2 of 5
  • LOGMARS
  • MSI
  • Planet Code
  • Codablock
  • PDF-417
  • Code 49
  • Data Matrix
  • Maxi Code
  • QR Code
  • TLC 39
  • Micro PDF
  • Aztec Code
  • GS1 DataBar
  • RSS
Application/Usage:
Industrial
Features:
  • Clear Media Side Door
  • Media Supply Spindle
  • Mirror Printing
  • Element Energy Equalizer
Memory
Standard Memory:
16 MB
Memory Technology:
SDRAM
Flash Memory:
8 MB
Interfaces/Ports
Parallel Port:
Yes
Serial Port:
Yes
USB:
Yes
Network & Communication
Ethernet:
Yes
Ethernet Technology:
Fast Ethernet
Wireless LAN:
Yes
Wireless LAN Standard:
IEEE 802.11g
Display & Graphics
Display Screen:
Yes
Display Screen Type:
LCD
Media Types & Handling
Media Type:
  • Black Mark
  • Continuous Form
  • Roll Fed
  • Die-cut Label
  • Fanfold
Media Sensor:
  • Transmissive Media Sensor
  • Reflective Media Sensor
Media Thickness:
12 mil
Maximum Roll Diameter:
8"
Maximum Label Width:
4.50"
Maximum Label Length:
12.50 ft
Label Core Size:
3"
Ribbon Core Size:
1"
Fonts & Emulation
Language Emulation:
  • ZPL II
  • XML
Power Description
Power Source:
AC Supply
Input Voltage:
  • 110 V AC
  • 220 V AC
Physical Characteristics
Height:
15.5"
Width:
10.3"
Depth:
20.4"
Weight (Approximate):
50 lb
Miscellaneous
Package Contents:
  • 110Xi4 Label Printer
  • North American Edition, 120 VAC Cord
  • Radio card
  • Software and Drivers CD
  • Programming Guide for ZPL II, WML, and Mirror
Platform Supported:
PC
Certifications & Standards:
  • BSMI
  • cTUVus
  • CCC
  • CE
  • C-Tick
  • EN55022 Class B
  • EN55024
  • EN61000-3-2,3
  • FCC Class B
  • GOST-R
  • ICES-003 Class B
  • IEC 60950-1 / EN60950
  • KCC
  • NOM
  • S Mark
  • STB
  • UkrSEPRO
  • VCCI
  • ZIK
  • Unicode
Warranty
Limited Warranty:
1 Year
Item Numbers
GTIN: 0682017484952
UPC: 682017484952
EAN: 0682017484952
UNSPSC: 43212108
Questions? Get help from a
Printer Expert!

How many labels will you print per day?

The Zebra 116-8K1-00001 Barcode Label Printer is also known as ZEB-1168K100001 or 116-8K1-00001.
