Zebra 10036764 RFID Label

Part Number: 10036764
Model: RFID Labels
Add to My Shopping List Add to Compare
Discontinued See Replacement
Item on backorder — chat for lead time

Price Match Guarantee - We'll match any authorized retailer's price

Quantity:

Product Highlights

View All
Total Number of Labels
1500
Core Diameter
3"
Adhesive Type
Permanent
Shape
Rectangle

Product Description:

  RFID Labels, Zebra Z-Perform 1500T, General Purpose, 4" x 3" (101.6mm x 76.2mm), Thermal Transfer, Permanent Adhesive, Not Perforated, Zebra ZBR2000 Inlay, 3" Core, 8" OD. 1500 Labels/Roll, 1 Roll Per Case, Priced Per Case. Compatible With RXi4/ZT400R/ZT600/ZE500R.
Explore all Zebra ZBR2000 RFID Inlays
Add to Quote
Zebra 10036764 RFID Label
Zebra 10036764 RFID Label
Zebra 10036764 RFID Label
Zebra 10036764 RFID Label
Zebra 10036764 RFID Label Zebra 10036764 RFID Label Zebra 10036764 RFID Label

Full specifications (PDF)

Zebra ZBR2000 RFID Inlay Model Overview

The Zebra ZBR2000 RFID tags are for general use and have applications in transportation, logistics, manufacturing, and healthcare for 4'' wide applications. Their primary utility is in boxes and pallets for product identification and asset tracking.

This general-purpose inlay measures 0.31 (H) x 3.74 (W) inches and is suitable for case, pallet, asset tracking, and 4-inch wide labeling applications. It meets auburn ARC specs: A, B, C, D, F, G, I, K, L, M, N, Q.

These tags have a very high sensitivity, allowing them to offer reading ranges of over 17 meters in open spaces. They incorporate the NXP UCODE 8 chip with a 128-bit EPC memory and 96 bits of factory-locked TID (48 unique bits). The reading sensitivity is -23 dBm, and the writing sensitivity is -18 dBm. Their dimensions are 95 mm x 8 mm.

Key Specifications:
  • Technology: UHF
  • Frequency: UHF FCC 902-928 MHz, UHF ETSI 865-868 MHz
  • Product Type: Inlays and Tags
  • Chip: NXP UCODE 8
  • EPC memory: 128 bits
  • Mounting: Glass, Wood, Non Metal, Plastic
  • ISO: ISO/IEC 18000-63, EPC Gen2 V2
  • Size: 95mm x 8mm - 3.74in x 0.31in


Zebra 10036764 RFID Label Overview
Zebra's General Purpose RFID label offering includes a variety of inlay types and works on most non-metallic surfaces, such as plastic and corrugate. Typical applications include labeling of cases, pallets, products and healthcare specimens. Zebra's RFID labels have been tested and optimized to work with Zebra's RFID printers and readers. Due to the many variables that can affect read range, we recommend testing in your envrionment to determine which label works best in your application.
Full specifications (PDF)
Product Information
Total Number of Labels:
1500
Core Diameter:
3"
Adhesive Type:
Permanent
Shape:
Rectangle
Print Technology:
  • Thermal Transfer
  • Direct Thermal
Features:
Coated Paper
Physical Characteristics
Product Material:
Paper
Miscellaneous
Compatibility:
Zebra Printers:
  • RXi4
  • ZT400R
  • ZT600R
  • ZE500R

Item Numbers
UNSPSC: 55121608
The Zebra 10036764 RFID Label is also known as ZEB-10036764 or 10036764.
