Zebra DS5502 Accessory

Zebra DS5502  -  Browse our selection of Zebra DS5502 Accessories. For help choosing the right Accessories, reach out to our expert team via phone or use our Online chat.
Full specifications (PDF)

Price Match Guarantee

Found a better price? We'll match it within 60 days of your purchase.

Chat Now for Qty Discount
Add to Quote
Add to My Shopping List Add to Compare
Starting at:
$41.80
Get help from a Barcoding Expert!

What type of Barcode are you scanning?

Zebra DS5502 Accessory
Zebra DS5502 Accessory

Category

Zebra DS5502 Accessory Options

Full specifications (PDF)

Zebra DS5502 Accessory Model Overview

This document is a technical accessory guide for the DS55 Series of scanners from Zebra Technologies. It includes information on the various communication cables, mounting brackets, and power supplies that are available for use with the DS55 Series.

Key Highlights:
  • The DS55 Series of scanners from Zebra Technologies are designed for use in a variety of applications, including retail, hospitality, and transportation and logistics.
  • The scanners can be used with a range of communication cables, including USB and RS232 options, as well as mounting brackets for different installation scenarios.
  • The DS55 Series of scanners can be powered using a range of power supplies, including options for the US, India, and various international markets.


Zebra Confidential. For recipient’s internal use only


Document Update date: 6/10/24


USB Cables


CBL-U10255-01

USB Cable: 24 in. Straight

►RJ50 mod-jack connector on scanner side

►Standard USB/A connector on host side

►24 inch Long Straight Cable

►Optimal for Kiosk Integration


CBL-U20255-01

USB Cable: 24 in. Straight, right angle connector

►RJ50 mod-jack connector on scanner side with right angle connector.

►Standard USB/A connector on host side

►24 inch Long Straight Cable

►Optimal for Kiosk Integration

►Right angle connector on cable allows scanner to be installed in tighter/constrained locations.


CBL-U10755-01

USB Cable: 7 ft. Straight

►RJ50 mod-jack connector on scanner side

►Standard USB/A connector on host side

►7 ft. (2.1 M) length Straight Cable


CBL-U20755-01

USB Cable: 7 ft. Straight, right angle connector

►RJ50 mod-jack connector on scanner side with right angle connector.

►Standard USB/A connector on host side

►7 ft. (2.1 M) length Straight Cable

►Right angle connector on cable allows scanner to be installed in tighter/constrained locations.


RS232 Cables


CBL-R10755-01

RS232 Cable:STD-DB9 Female, TxD on 2, 7 ft. Straight

►RJ50 mod-jack connector on scanner side

►DB9 Female connector on host side

►7 ft. (2.1 M) length Straight Cable


CBL-R20755-01

RS232 Cable:STD-DB9 Female, 7 ft. Straight, right angle connector

►RJ50 mod-jack connector on scanner side with right angle connector.

►DB9 Female connector on host side

►7 ft. (2.1 M) length Straight Cable

►Right angle connector on cable allows scanner to be installed in tighter/constrained locations.


BRKT-MM0055C-04

3-in-1 Multi-Mount, Black

►Mount can be used as: - wall mount - computer display mount - presentation stand

►The magnetic mounting face securely holds the DS55 Series scanner in place, while letting the scanner swivel to either side as needed.

►It’s easy to lift the scanner off to scan an item in handheld mode, then pop it back on.


STND-GS0055C-04

Gooseneck Intellistand, Black


STND-GS0055C-0W

Gooseneck Intellistand, White


20-60136-02R

Gooseneck Intellistand, legacy DS457

►Stand used with the DS457, but is compatible with the DS55 using the M3 x 0.5 mounting bosses.

►Includes screws for mounting DS55 to the stand


KT-65578-01R

Miniscan Adjustable Mounting Bracket

►Provides easier mounting of DS55 in a kiosk or other confined space locations


KT-152342-01

MS320x Mounting Bracket Adapter

►Allows DS55 to use same mount as existing MS320x installations

►Bracket adapts DS55 to fit into holes for MS320x


KT-145344-01

POS Stand/Mounting Bracket

►Walkie-talkie style clip attaches to wall/counter and allows for easy fixed mounting and removal of DS55

►DS55 is positioned at a 20° angle when attached to clip

►DS55 bracket is Jet black color


PWR-WUA5V4W0US

Power Supply (US)

►Used when connecting communication cables labeled above as "Requires external power supply".

►For use in US, CA, MX, JP, TW.

►5.2V, 1.1A, 5.7W

►Provides US DOE Level VI compliance for power efficiency.


PWR-WUA5V4W0IN

Power Supply (India)

►Used when connecting communication cables labeled above as "Requires external power supply".

►For use in India.

►5.2V, 5.7W

►Provides US DOE Level VI compliance for power efficiency.


PWR-WUA5V4W04C

Power Supply (EU, UK, Brazil, Australia, China)

►Used when connecting communication cables labeled above as "Requires external power supply".

►Includes AC adapter clips for use in EU, Australia and China.

►5.2V, 5.7W

►Provides US DOE Level VI compliance for power efficiency.
