Wasp WDI9600 – Barcode Scanner – Cable Only

Part Number: 633809009013
Model: Parts
to get Free Ground Shipping on your order.
3-year Premium Plus ($93.70)
3-year Premium ($39.00)
No Support
Add to My Shopping List Add to Compare
$189.00
In Stock

Price Match Guarantee - We'll match any authorized retailer's price

Quantity:

Product Highlights

View All
Connectivity Technology
Cable
Scanning Capability
1D
Barcode Symbology Supported
1D/Linear Codes: Auto discriminates all standard 1D codes including GS1 DataBar™ linear codes
Light Source
Laser

Product Description:

  Barcode Scanners, Wasp WDI9600, Laser Scanner With USB Cable, Corded, Linear Imager, Decodes 1D/Linear Codes, USB Cable, Black/Yellow, IP52, USB type C connectivity, Disinfectant-Ready Enclosure. Kit Includes: 1D Barcode Scanner, 6' USB Cable, Scanner Programming Guide, and 2 Year Warranty
Add to Quote
Wasp 633809009013 Barcode Scanner
Wasp 633809009013 Barcode Scanner
Wasp 633809009013 Barcode Scanner
Wasp 633809009013 Barcode Scanner
Wasp 633809009013 Barcode Scanner
Wasp 633809009013 Barcode Scanner Wasp 633809009013 Barcode Scanner Wasp 633809009013 Barcode Scanner Wasp 633809009013 Barcode Scanner Wasp 633809009013 Barcode Scanner

Wasp 633809009013 Barcode Scanner Overview

Wasp WDI9600 USB Laser Barcode Scanner The new Wasp WDI9600 USB Laser barcode scanner is a multipurpose linear imager designed to provide best-in-class reading performance with an exceptional depth of field. The WDI9600s soft line viewfinder technology enables the operator to effortlessly read both high density and low-resolution barcodes, as well as hard-to-read, poor quality, and damaged barcodes without human intervention. The viewfinder technology enables operators to maximize productivity while reducing accidental reads in a multiple barcode environment. Adding to the WDI9600s versatility, barcodes can be scanned directly from mobile device screens or through plexiglass panels. Ease of use is a hallmark of the WDI9600 which includes unique motionix technology that provides operators the flexibility to easily transition between handheld and stand-mounted operations. The scanner easily reads fast moving barcodes, including barcodes at awkward angles or in poorly lit or very bright lighting. The reader features a disinfectant-ready enclosure which can withstand harsh chemical cleaning. For added convenience, the WDI9600 can directly interface with USB-based solutions.
Technical Information
Connectivity Technology:
Cable
Scanning Capability:
1D
Barcode Symbology Supported:

1D/Linear Codes: Auto discriminates all standard 1D codes including GS1 DataBar™ linear codes

Light Source:
Laser
Image Sensor Type:
CCD
Scan Rate:
400 scan/s
Scan Mode:
Trigger
Scan Pattern:
Linear
Scanning Distance:
57.87"
Features:
  • Notification LED
  • Beep
  • 3GL
  • Scan Button
Cable Type Included:
USB
Reading Angle (Skew):
65°
Reading Angle (Pitch):
65°
Reading Angle (Roll):
45°
Maximum Ambient Light:
130000 lux
Drop Specification:

Withstands repeated drops from 6.0 ft (1.8 m) onto a concrete surface.

Minimum Print Contrast:
15%
Minimum Element Resolution (Code 39):
5 mil
Maximum Element Resolution (Code 39):
20 mil
Illumination Type:
LED
Interfaces/Ports
Host Interface:
USB
Power Description
Input Current:
350 mA
Standby Current:
60 mA
Environmental Conditions
Operating Temperature:
32°F (0°C) to 122°F (50°C)
Storage Temperature:
-40°F (-40°C) to 158°F (70°C)
Humidity (Non-condensing):
0% to 95%
Physical Characteristics
Form Factor:
Handheld
Color Family:
Dual Color
Product Color:
  • Black
  • Yellow
Durability:
Chemical Resistant
Width:
6.5"
Depth:
2.7"
Length:
4.3"
Weight (Approximate):
5.75 oz
Miscellaneous
Package Contents:
  • WDI9600 USB Laser Barcode Scanner
  • 6' USB cable
  • Scanner programming guide
  • 2-year warranty
Ingress Protection (IP) Rating:
IP52
Application/Usage:
  • Retail
  • Light/Clean Manufacturing
  • Healthcare
  • Laboratory
  • Pharmacy
  • Ticketing
  • Entertainment
  • Commercial Service
Platform Supported:
Smartphone
Environmental Compliance:
  • China Restriction of Hazardous Substances (China RoHS)
  • Restriction of Hazardous Substances (RoHS)
Warranty
Limited Warranty:
2 Year
Item Numbers
GTIN: 0633809009013
UPC: 633809009013
EAN: 0633809009013
UNSPSC: 43211701
