Wasp WPS1500 – Barcode Scanner – Scanner with Cable and Stand

Part Number: 633809008351
3-year Premium Plus ($54.70)
No, stay at premium support package
$349.00

Price Match Guarantee - We'll match any authorized retailer's price

Quantity:

Product Highlights

View All
Connectivity Technology
Cable
Scanning Capability
1D2D
Barcode Symbology Supported
Symbologies:Auto discriminates all standard 1D codes including GS1 DataBar linear codes. Aztec Code; Data Matrix; MaxiCode; QR Code. Australian Post; British Post; Canadian Post; China Post; IMB; Japanese Post; KIX Post; Planet Code; Portuguese Post; Postnet; Royal Mail Code; (RM4SCC); Swedish Post; GS1 DataBar Composites; GS1 DataBar Expanded Stacked; GS1 DataBar Stacked; GS1 DataBar Stacked Omnidirectional; MicroPDF417; PDF417; optional support for Digimarc Barcodes/GS1 DW Code
Light Source
LED

Product Description:

  Barcode Scanners, Wasp WPS1500, Corded, Omni-Directional, Decodes 1D and 2D codes, USB Keyboard, Black, 1MP optics, Green spot technology. Kit Includes: Barcode Scanner With Integrated Stand, USB Cable and Scanner Programming Guide

Wasp WPS1500 Omni-Directional Barcode Scanner Model Overview

The Wasp WPS 1500 Omnidirectional Barcode Scanner is a versatile and high-performance tool designed for seamless data collection in various environments, including retail, warehousing, healthcare, and commercial services. Its omnidirectional scanning capability enhances productivity by quickly reading both 1D and 2D barcodes on printed labels, mobile coupons, loyalty cards, and more. Equipped with 1MP optics and green spot technology for good-read feedback, the WPS 1500 ensures precision and efficiency in every scan.


Key Features
  • High-performance, omnidirectional scan pattern for increased productivity
  • Ideal for retail POS, warehouse applications, and healthcare
  • Scans popular 1D and 2D barcodes on a variety of surfaces
  • 1MP optics for excellent performance with mobile devices
  • Green spot technology for easy good-read feedback

Specifications
  • Optic & Performance: 1 Megapixel; 1280 x 800 pixels
  • Scan Angle: Pitch: +/- 65°; Roll: 360°; Skew: +/-75°
  • Drop Durability: 4.0 ft. (1.2 m)
  • Operating Temperature: 0 to 40 °C / 32 to 104 °F
  • Connectivity: USB Keyboard, USB COM, RS-232
  • Weight: Tilting Stand: 240 g; Fixed Riser: 164 g; Wall Mount: 170 g
  • Dimensions: Tilting Riser: 6.0 x 7.5 x 13.8 cm
  • Humidity: 5%~95% (Non-condensing)
  • E-SD Protection: 16 kV
  • Color: Black & White
Wasp 633809008351 Barcode Scanner Overview
Wasp WPS1500 Omni-Directional Barcode Scanner The Wasp WPS1500 Omni-Directional Barcode Scanner is a high-performance scanner ideal for retail point-of-sale (POS) and warehouse applications. Utilizing a digital imaging scan engine, the WPS1500 is capable of reading both 1D and 2D barcodes with ease. Unique technology optimizes light levels and provides the ability to read barcodes from mobile phones, tablets, and computer displays. For busy retail environments, the WPS1500 can be used in hands-free and handheld mode. Checkout personnel by simply waving the barcode label or tag across the face of the scanner. Regardless of barcode label orientation, the WPS1500 Omni-Directional scan engine will quickly read the barcode and assist in the rapid check out of your customers. The WPS1500 omni-directional barcode scanner can also be used to scan invoices or pick lists and is a perfect addition to any warehouse. Its rugged housing can withstand repeated 4 ft. drops to concrete, and is sealed against moisture and dust (IP52 rated). For noisy environments, the WPS1500 provides Green Spot visual feedback, perfect for confirming a positive scan or for precise targeting of a single barcode from a group of barcodes. The Wasp WPS1500 includes a 2-year manufacturer's warranty covering material defects. If you would like to upgrade this coverage, WaspProtect extended service plans cover accidental breakage and can provide coverage beyond the original warranty.
Technical Information
Connectivity Technology:
Cable
Scanning Capability:
  • 1D
  • 2D
Barcode Symbology Supported:

Symbologies:

  • Auto discriminates all standard 1D codes including GS1 DataBar linear codes. Aztec Code; Data Matrix; MaxiCode; QR Code. Australian Post; British Post; Canadian Post; China Post; IMB; Japanese Post; KIX Post; Planet Code; Portuguese Post; Postnet; Royal Mail Code; (RM4SCC); Swedish Post; GS1 DataBar Composites; GS1 DataBar Expanded Stacked; GS1 DataBar Stacked; GS1 DataBar Stacked Omnidirectional; MicroPDF417; PDF417; optional support for Digimarc Barcodes/GS1 DW Code
Light Source:
LED
Scan Pattern:
Omni-directional
Scanning Distance:
11.80"
Features:
  • Beep
  • Notification LED
Cable Type Included:
USB
Stand Included:
Yes
Reading Angle (Skew):
75°
Reading Angle (Pitch):
65°
Reading Angle (Roll):
360°
Image Formats:
  • BMP
  • JPEG
Maximum Ambient Light:
86100 lux
Drop Specification:

4.0 ft. (1.2 m)

Minimum Print Contrast:
25%
Minimum Element Resolution (Code 39):
5 mil
Maximum Element Resolution (Code 39):
20 mil
Minimum Element Resolution (DataMatrix):
13 mil
Maximum Element Resolution (DataMatrix):
24 mil
Minimum Element Resolution (PDF417):
6.5 mil
Maximum Element Resolution (PDF417):
16 mil
Image Sensor Resolution:
1280 x 800
Interfaces/Ports
Host Interface:
  • USB
  • IBM 46XX
  • Serial
Environmental Conditions
Operating Temperature:
32°F (0°C) to 104°F (40°C)
Storage Temperature:
-40°F (-40°C) to 158°F (70°C)
Humidity (Non-condensing):
5% to 95%
Physical Characteristics
Form Factor:
Hands-free
Rugged:
Yes
Color Family:
Dual Color
Product Color:
  • Black
  • White
Durability:
  • Drop Resistant
  • Dust Resistant
  • Water Resistant
Miscellaneous
Package Contents:
  • Wasp WPS1500 Omni-Directional Barcode Scanner with integrated stand
  • USB cable
  • Scanner programming guide
Ingress Protection (IP) Rating:
IP52
Application/Usage:
  • Retail
  • Warehouse
  • Healthcare
  • Commercial Service
  • Loyalty Program
  • Ticketing
  • Self-checkout
  • Assembly Line
  • Packing
  • Laboratory
  • Pharmacy
Platform Supported:
  • Smartphone
  • Tablet
  • PC
Environmental Compliance:
  • China Restriction of Hazardous Substances (China RoHS)
  • Restriction of Hazardous Substances (RoHS)
Warranty
Limited Warranty:
2 Year
Item Numbers
GTIN: 0633809008351
UPC: 633809008351
EAN: 0633809008351
UNSPSC: 43211701
